Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
GT 5
GT 13
GT16 Series
— Subminiature Connectors for coaxial cables —
GT 16
PO5G
Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
<
Several types and configurations: In-line, board mounted.
Multi-position and color/ keying variations.
>
GT 11
GT 17
GT 19
GT 26
GT 27
GT 3
GT 6W
GT 7
Features
Space-saving Design
Compact and light weight comparing with HRS GT5 series.
Excellent High Frequency Performance
Refer to V.S.W.R. data on the following pages.
GT 10 GT 18W GT 15
Applications
In-car communication, car sensors(temperature, pressure), automotive audio systems, GPS antenna systems,
RACS antenna audio/video antenna systems, CRT displays, medical and measuring instrumentation LAN
systems.
GT 8
GT 9
GT 25
GT 22
53
GT16 Series
GT 5
GT16 Series
F Connectors (Common Use)
Center terminal
7.6
0.8
4
Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
PO5G
GT 16
GT 13
GT 17
GT 11
GT 19
Part Number
GT16-2428SCF
GT16-30SCF
HRS No.
766-0001-2
766-0055-1
Conductor Size
AWG#24-28
AWG#30
Material
Phosphor bronze
Phosphor bronze
Finish
Tin plating
Tin plating
Packaging
10,000 pcs/reel
10,000 pcs/reel
RoHS
YES
Insulator (Common Use)
GT 7
GT 6W
GT 3
GT 27
GT 26
Part Number
GT16-SC
HRS No.
766-0002-5
Material
PBT
Color
White
Packaging
1 piece
RoHS
YES
GT 15 GT 18W GT 10
M Connectors (Common Use)
Center Terminals
9.25
0.8
4
GT 8
GT 25
GT 9
GT 22
Part Number
GT16-2428PCF
GT16-30PCF28
HRS No.
766-0006-6
766-0015-7
Conductor Size
AWG#24-28
AWG#30-28
Material
Brass
Brass
Finish
Tin plating
Tin plating
Packaging
10,000 pcs/reel
10,000 pcs/reel
RoHS
YES
54
0.2
0.2
GT16 Series
GT 5
Insulator (Common Use)
GT 13
6.3
4.1
GT 16
PO5G
GT 11
GT 17
Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
Part Number
GT16-PC
HRS No.
766-0007-9
Material
PBT
Finish
White
Packaging
1 piece
RoHS
YES
GT 19
After-Market F Part Connect(No retainer required type)
Housing
GT 26
GT 27
17
4
5.25
GT 3
GT 6W
GT 7
Part Number
GT16-1S-HU
GT16-1S-HU(P)
HRS No.
766-0004-0
766-0067-0
Material
PBT
PBT
Finish
Light Gray
Black
Packaging
1 piece
1 piece
RoHS
YES
GT 10 GT 18W GT 15
Outer terminal
15.7
7.2
GT 8
GT 9
GT 25
Part Number
GT16-/1.6-2.9SC
GT16-/0.7-1.5SC
GT16-/1.1-2.2SC
HRS No.
766-0003-8
766-0056-4
766-0088-0
Applicable Cable
Material
1.5D-2V or equivalent Phosphor bronze
0.8D-2V or equivalent Phosphor bronze
1.0D-2V or equivalent Phosphor bronze
Finish
Tin plating
Tin plating
Tin plating
Packaging
1 piece
1 piece
1 piece
RoHS
YES
GT 22
55
GT16 Series
GT 5
After-Market Parts M Connector(No retainer required type)
Housing
25.5
9.5
13.5
GT16 -1S - HU
9.5
Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
GT 11
PO5G
GT 16
GT 13
B
Fully mated connector
assemblies
GT 17
Part Number
GT16-1P-HU
GT16-1P-HU(P)
HRS No.
766-0009-4
766-0068-3
Material
PBT
PBT
Finish
Light Gray
Black
Packaging
1 piece
1 piece
RoHS
YES
Outer terminals
16.6
8.1
GT 27
GT 26
GT 19
Part Number
GT16-/1.6-2.9PC
GT16-/0.7-1.5PC
HRS No.
766-0008-1
766-0016-0
Applicable Cable
Material
1.5D-2V or equivalent Phosphor bronze
0.8D-2V or equivalent Phosphor bronze
Color
Tin plating
Tin plating
Packaging
1 piece
1 piece
GT 3
RoHS
YES
GT 6W
Printed Circuit Board Type (SMT Type)
9.5
Vaccum
pick-up area
B
Recommended Board Mounting Pattern
7
1.2
2.8
GT 7
9.5
GT 15 GT 18W GT 10
15.5
10
1.2
3.8
B
Fully mated connector assemblies
5
( 22.5 )
GT16 -1S -HU
( 4.5 )
B
Recommended Temperature Profile
GT 8
GT 9
250
230
180
130
GT 25
0
60sec max
56
GT 22
Material
Color/Finish Packaging
RoHS
PPS(Housing)
Light Gray
Phosphor bronze (Innner Terminal)
Tin plating
Phosphor bronze (Outer Terminal)
Tin plating
1 piece
GT16-1P-H 766-0005-3
PPS (Insulator)
Natural
Phosphor bronze (Shield plate) Tin plating
Brass (Metal fitting)
Tin plating
YES
PPS(Housing)
Black
Phosphor bronze (Innner Terminal)
Tin plating
Phosphor bronze (Outer Terminal)
Tin plating
1 piece
GT16-1P-H(P) 766-0066-8
PPS (Insulator)
Natural
Phosphor bronze (Shield plate) Tin plating
Brass (Metal fitting)
Tin plating
Part Number
HRS No.
4.1
14
11.5
18
0.7
3
GT16 Series
GT 5
Genuine Market Parts F Connectors
Housing (Retainer Stopper Specification)
7.5
17.5
GT 13
GT 16
Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
11.6
10.1
PO5G
GT 11
GT 17
Part Number
GT16C-1S-HU
GT16C-1S-HU(A)
GT16C-1S-HU(B)
HRS No.
766-0010-3
766-0060-1
766-0061-4
Material
PBT
PBT
PBT
Finish
Light Gray
Brown
Green
Packaging
1 piece
1 piece
1 piece
RoHS
YES
GT 19
Note :
This product is used in conjunction with retainer GT16C-1P/S-R (CL766-0011-6) which is a separate item.
GT 26
Outer terminal (Retainer Stopper Specification)
GT 27
15.7
7.2
GT 3
GT 6W
GT 7
Part Number
GT16C-/1.6-2.9SC
GT16C-/0.7-1.5SC
GT16C-/1.1-2.2SC
HRS No.
766-0012-9
766-0057-7
766-0089-3
Applicable Cable
Material
1.5D-2V or equivalent Phosphor bronze
0.8D-2V or equivalent Phosphor bronze
1.0D-2V or equivalent Phosphor bronze
Finish
Tin plating
Tin plating
Tin plating
Packaging
1 piece
1 piece
1 piece
RoHS
GT 10 GT 18W GT 15
YES
Retainer
R2.6
1.25
2.15
11.2
GT 8
GT 9
5.6
GT 25
Part Number
GT16C-1P/S-R
HRS No.
766-0011-6
Material
PBT
Finish
Dark Gray
Packaging
1 piece
RoHS
YES
GT 22
57
