3-1618276-4

Description
POWER/SIGNAL RELAY, SPST, MOMENTARY, 12VDC (COIL), 10A (CONTACT), PANEL MOUNT-THREADED
CategoryMechanical and electronic products    relay
File Size108KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3-1618276-4 Online Shopping

Suppliers Part Number Price MOQ In stock
3-1618276-4 - - View Buy Now

3-1618276-4 Overview

POWER/SIGNAL RELAY, SPST, MOMENTARY, 12VDC (COIL), 10A (CONTACT), PANEL MOUNT-THREADED

3-1618276-4 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresSWITCH FUNCTION SPDT ALSO AVAILABLE
Maximum coil voltage (DC)12 V
Maximum contact current (AC)10 A
Maximum contact current (DC)10 A
Contact/Output Power TypeAC/DC
Manufacturer's serial number1618276
Installation featuresPANEL MOUNT-THREADED
Relay actionMOMENTARY
Relay functionSPST
Relay typePOWER/SIGNAL RELAY
surface mountNO
Termination typeWIRE
Base Number Matches1
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Relays
>
Product Feature Selector
> Product Details
K61C781 Product Details
High Voltage Relays
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
K61C781
(3-1618276-4)
T E I nternal N umber: 3 - 1 6 1 8 2 7 6 - 4
Product Highlights:
l
C ontact Arrangement = 1 Form B, SPST-NC , 1 N/C , 1
Form A, SPST-NO, 1 N/O, 1 Form C , SPDT, 1 C /O
l
Power Switching = Make Only, No
l
C ontact C urrent Rating = 0 - 10 Amps.
l
Not RF Rated
l
C oil Voltage = 12 VDC
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Termination Style
= Turret Terminal
Electrical Characteristics:
l
C ontact C urrent Rating (Amps.)
= 0 – 10
l
RF Rated
= No
l
C oil Voltage (VDC )
= 12
l
Voltage, Max. (VDC )
= 0 – 35000
l
C urrent, C arry Only = Yes
Termination Related Features:
l
High Voltage C onnection (Power)
= Flying Leads
l
High Voltage C onnection (C oil)
= Turret Terminals
l
Auxiliary C ontacts
= Without
Body Related Features:
l
Mount Style
= Threaded
Configuration Related Features:
l
C ontact Arrangement
= 1 Form B, SPST-NC , 1 N/C , 1 Form A,
SPST-NO, 1 N/O, 1 Form C , SPDT, 1 C /O
l
Power Switching
= Make Only, No
l
High Voltage C onnection Length (mm [in])
= 914.4 [36]
l
Economizer
= Without
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Other:
l
Brand = Kilovac
