Product data sheet
Characteristics
GV2ME08
TeSys GV2-Circuit breaker-thermal-magnetic -
2.5...4 A - screw clamp terminals
Product availability: Stock - Normally stocked in distribution facility
Main
Commercial Status
Range of product
Device short name
Product or component
type
Circuit breaker
application
Poles description
Network type
Utilisation category
Network frequency
Breaking capacity
Commercialised
TeSys GV2
GV2ME
Circuit breaker
Motor protection
3P
Category A conforming to IEC 60947-2
AC-3 conforming to IEC 60947-4-1
50/60 Hz conforming to IEC 60947-4-1
Icu = 100 kA at 500 V AC 50/60 Hz conforming to
IEC 60947-2
Icu = 100 kA at 440 V AC 50/60 Hz conforming to
IEC 60947-2
Icu = 100 kA at 400/415 V AC 50/60 Hz conforming
to IEC 60947-2
Icu = 100 kA at 230/240 V AC 50/60 Hz conforming
to IEC 60947-2
Icu = 3 kA at 690 V AC 50/60 Hz conforming to IEC
60947-2
100 % at 400/415 V AC 50/60 Hz conforming to IEC
60947-2
100 % at 440 V AC 50/60 Hz conforming to IEC
60947-2
75 % at 690 V AC 50/60 Hz conforming to IEC
60947-2
100 % at 230/240 V AC 50/60 Hz conforming to IEC
60947-2
100 % at 500 V AC 50/60 Hz conforming to IEC
60947-2
2.5...4 A
Thermal-magnetic
51 A
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
AC
[Ics] rated service
short-circuit breaking
capacity
Thermal protection
adjustment range
Trip unit technology
Magnetic tripping
current
Complementary
Mounting mode
Mounting support
Mounting position
Motor power kW
By clips
By screws
Rail
Horizontal
Vertical
2.2 kW at 690 V AC 50/60 Hz
2.2 kW at 500 V AC 50/60 Hz
3 kW at 690 V AC 50/60 Hz
1.5 kW at 500 V AC 50/60 Hz
1.5 kW at 400/415 V AC 50/60 Hz
1.1 kW at 400/415 V AC 50/60 Hz
Pushbutton
690 V AC 50/60 Hz conforming to IEC 60947-2
690 V AC 50/60 Hz conforming to IEC 60947-2
Control type
[Ue] rated operational voltage
[Ui] rated insulation voltage
Mar 27, 2014
1
[Ith] conventional free air thermal current
[Uimp] rated impulse withstand voltage
Power dissipation per pole
Mechanical durability
Electrical durability
Operating rate
Rated duty
Connections - terminals
4 A conforming to IEC 60947-4-1
6 kV conforming to IEC 60947-2
2.5 W
100000 cycles
100000 cycles for AC-3 at 440 V
25 cyc/h
Continuous conforming to IEC 60947-4-1
Screw clamp terminals 2 cable(s) 0...0.01 in² (1...4 mm²) - cable stiffness : flexible
- with cable end
Screw clamp terminals 2 cable(s) 0...0.01 in² (1.5...6 mm²) - cable stiffness :
flexible - without cable end
Screw clamp terminals 2 cable(s) 0...0.01 in² (1...6 mm²) - cable stiffness : solid
15.04 lbf.in (1.7 N.m) - on screw clamp terminals
Shocks 30 Gn for 11 ms conforming to IEC 60068-2-27
Vibrations 5 Gn, 5...150 Hz conforming to IEC 60068-2-6
Yes conforming to IEC 60947-1
Yes conforming to IEC 60947-4-1
3.5 in (89 mm)
1.77 in (45 mm)
3.08 in (78.2 mm)
0.57 lb(US) (0.26 kg)
Tightening torque
Mechanical robustness
Suitability for isolation
Phase failure sensitivity
Height
Width
Depth
Product weight
Environment
Standards
EN 60204
IEC 60947-1
IEC 60947-2
IEC 60947-4-1
NF C 63-120
NF C 63-650
NF C 79-130
UL 508
VDE 0113
VDE 0660
CSA C22.2
ATEX
BV
CCC
CEBEC
CSA
DNV
EZU
GL
GOST
RINA
SETI
TSE
UL
LROS
TH
IP20 conforming to IEC 60529
IK04
-4...140 °F (-20...60 °C)
-40...176 °F (-40...80 °C)
1760 °F (960 °C) conforming to IEC 60695-2-1
6561.68 ft (2000 m)
Product certifications
Protective treatment
IP degree of protection
IK degree of protection
Ambient air temperature for operation
Ambient air temperature for storage
Fire resistance
Operating altitude
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Product availability
22367 - MANUAL STR PROTECTOR - GV2
I11
00785901211952
1
0.58
Stock - Normally stocked in distribution facility
2
Returnability
Country of origin
Y
FR
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 0631 -
Available
Need no specific recycling operations
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Contractual warranty
Period
18 months
