M SERIES OUTPUT MODULES
• AC Modules have High Current Thyristors with 100 Amp
Surge Capability
• Plug into mounting boards for 0.6" modules
• Zero or Random Turn-On Available in AC Modules
• 4kV Optical isolation (1500 VAC Isolation for
FET DC Output Modules)
• UL Recognized, CSA Certified, CE Compliant
• Industry standard packaging and Color Coding
Black (AC Output) Red (DC Output)
SPECIFICATIONS (1)
Input
Part Number
Nominal Voltage VDC
Minimum Voltage VDC (2)
Maximum Voltage VDC
Drop-out Voltage
Maximum Current (3)
Resistance (4)
M-OAC5
5.0
2.75
8.0
1.0
20
220
M-OAC5A
5.0
2.75
8.0
1.0
20
220
M-OAC5AH
5.0
2.75
8.0
1.0
20
220
M-OAC5AR
5.0
2.75
8.0
1.0
20
220
M-OAC5R
5.0
2.75
8.0
1.0
20
220
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage (5)
Max Off-State Leakage (6)
Static Off-State dv/dt (7)
Maximum Rated On-State Current (8)
Minimum On-State Current
Max Surge Current (9)
On-State Voltage Drop or Resistance (10)
Maximum Turn-On Time [msec] (13)
Maximum Turn-Off Time [msec] (13)
Input/Output Isolation Voltage (14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
5.0 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
0.1
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
0.1
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
SPECIFICATIONS (1)
Input
Part Number
Nominal Voltage VDC
Minimum Voltage VDC (2)
Maximum Voltage VDC
Drop-out Voltage
Maximum Current (3)
Resistance (4)
M-OAC24
24
18
32
1.0
13
2000
M-OAC24A
24
18
32
1.0
13
2000
M-ODC5
5.0
2.75
8.0
1.0
18
250
M-ODC5A
5.0
2.75
8.0
1.0
18
250
M-ODC5F
5.0
2.75
8.0
1.0
18
250
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage (5)
Max Off-State Leakage (6)
Static Off-State dv/dt (7)
Maximum Rated On-State Current (8)
Minimum On-State Current
Max Surge Current (9)
On-State Voltage Drop or Resistance (10)
Maximum Turn-On Time [msec] (13)
Maximum Turn-Off Time [msec] (13)
Input/Output Isolation Voltage (14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
120 VAC
12 VAC
140 VAC
400 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
240 VAC
24 VAC
280 VAC
600 Vpeak
0.1mArms
200 V/usec
3.5 Arms
50 mArms
100 Apeak
1.6 V
8.33
8.33
4000
8
-30 to 80°C
-40 to 80°C
47 to 63
1.1 oz. (31.2g)
5-48 VDC
3.0 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-150 VDC
3.0 VDC
250 VDC
250 VDC
10 uA
N/A
1.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
3.0 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.025
0.05
4000
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
SPECIFICATIONS (1)
Input
Part Number
Nominal Voltage VDC
Minimum Voltage VDC (2)
Maximum Voltage VDC
Drop-out Voltage
Maximum Current (3)
Resistance (4)
M-ODC5MA
5.0
2.75
8.0
1.0
18
250
M-ODC5MC
5.0
2.75
8.0
1.0
18
250
M-ODC5ML
5.0
2.75
8.0
1.0
18
250
M-ODC24
24
18
32
1.0
13
2000
M-ODC24A
24
18
32
1.0
13
2000
Output
Nominal Line Voltage
Minimum Line Voltage
Maximum Line Voltage
Max Off-State Voltage (5)
Max Off-State Leakage (6)
Static Off-State dv/dt (7)
Maximum Rated On-State Current (8)
Minimum On-State Current
Max Surge Current (9)
On-State Voltage Drop or Resistance (10)
Maximum Turn-On Time [msec] (13)
Maximum Turn-Off Time [msec] (13)
Input/Output Isolation Voltage (14)
Input/Output Capacitance
Operating Temperature Range
Storage Temperature Range
Line Frequency Range
Weight
5-150 VDC
1.0 VDC
200 VDC
200 VDC
10 uA
N/A
3.0 A
1.0 mA
10 A
0.25 Ohms
1.0
0.05
1500
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-90 VDC
1.0 VDC
100 VDC
100 VDC
10 uA
N/A
5.0 A
1.0 mA
10 A
0.10 Ohms
1.0
0.05
1500
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
50 VDC
50 VDC
50 VDC
10 uA
N/A
1.0 A
10 mA
10 A
0.05 Ohms
1.0
0.05
1500
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-48 VDC
60 VDC
60 VDC
60 VDC
10 uA
N/A
3.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
5-150 VDC
250 VDC
250 VDC
250 VDC
10 uA
N/A
1.0 A
10 mA
5.0 A
1.5 V
0.1
0.75
4000
8
-30 to 80°C
-40 to 80°C
DC
1.1 oz. (31.2g)
General Notes:
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
.
Specifications apply to an ambient temperature of -30 to 80 °C unless otherwise noted.
Without external LED status indicator. Add 1.7 volts for external LED if utilized.
At nominal input voltage, without external LED status indicator.
+/-10% at 25°C.
Maximum 1 minute duration for OAC modules when applied as a DC voltage rather than a peek AC voltage.
At maximum line voltage, 25°C for OAC modules, and 80°C for ODC modules.
Minimum DV/DT per EIA/NARM RS433, method RS397, DV/DT ratings do not apply to DC output models
At 40°C, derate OAC modules 58 mA/°C to 80°C, derate ODC. ODCxMC and ODCxML modules 50 mA/°C
to 80°C. CSA rating of OAC modules is 3.0 Arms at 40°C.
At 25°C for 1 second maximum duration: 1 AC cycle for AC modules, 1 second for DC modules.
At maximum rated on-state current and 25°C.
At maximum line voltage, maximum rated output current, nominal input voltage and 25°C. Switching speed
of OAC modules is based upon 60 Hz line frequency.
At 25°C for 1 second maximum duration.
1/3 H.P. at 240 VAC, 1/8 H.P. at 120 VAC.
MECHANICAL SPECIFICATIONS
AGENCY APPROVALS
E46203
38595
Rev. 121311
