High Power Resistors
Type MPC Series
Type MPC Series
Characteristics -
Electrical
Resistance Values:
Resistance Tolerance:
Temp. Coefficient of Resistance:
Rated Power @ 70°C:
Equivalent Parallel Capacitance
(100 MHz):
Maximum Operating Voltage:
Withstanding Voltage:
A range of non inductive thick film
power resistors complementing the
T0220
packaged
MPR
series
(20 Watt heat sink styles), being
vertically mounted and suitable to
dissipate power from 3 Watts up to
10 Watts. Available in values from
1R0 to 200K ohms they are the
idea solution for small snubber
circuits, the output side of high
speed pulse generators and low
inductive resistor requirements in
switch mode power supplies.
R10 to 200K
1%, 5%
±100ppm/°C
3 to 10 Watts nominal
1.0pf
300V AC
5000V
-55°C to +125°C
20 x rated current up to 8 ms ( ΔR ± 0.5%)
Operating Temperature Range:
Overload Current:
Characteristics -
Mechanical
Test Condition MILR83401
Life (Rated Power):
Life (Moisture Load):
Temperature Cycling:
40°C, rated power, 90 min ON
30 min OFF, 1000 hrs.
60°C, 90 - 95% RH, rated power
90 min ON 30 min OFF, 1000 hrs.
Room temp > -55°C 30 min > RT
10 min ± 120°C 30 min > RT 10 min
5 cycles
UL94V-O rated
350°C Solderpot, 3 secs.
DC 100V, 1 min
10 - 50 Hz, 1 min, 20G, X-Y-Z 1 hr.
ΔR± ( 0.25% + 0.05 ohm)
Over 1000M ohm
ΔR± (0.25% + 0.05 ohm)
Specification
ΔR± ( 1.0% + 0.05 ohm)
ΔR± ( 1.0% + 0.05 ohm)
ΔR± ( 0.25% + 0.05 ohm)
Flammability:
Soldering Heat:
Insulation Resistance:
Vibration:
Key Features
■
■
■
■
■
■
■
■
High Power Density
Easy to Mount
Non Inductive
Stable at 100ppm/°C
Temperature Range
-55°C to +125°C
High Power up to
10 Watts
Voltage Proof 5000V dc
Non Flammable
Power Derating Curve
100
80
60
40
20
0
-55
-40
-20
0 20 40
60 70 80
100
120 125
Ambient Temperature (°C)
Overload Characteristics
Percent Rated Power
20 x Nominal
Power Rating
Power
0
8
Time (milliseconds)
Literature No. 1773248
Issued: 02-08
Dimensions are shown for
reference purposes only.
Dimensions are in
millimetres unless
otherwise specified.
Specifications subject to
change.
tycoelectronics.com
passives.tycoelectronics.com
High Power Resistors
Type MPC Series
Dimensions
A
2.540
27.68
25.40
3.175
1.905
1.270
0.864
0.508
B
0.254
0.660
Size
A
B
MPC3
10.16
5.08
MPC5
12.7
5.08
MPC7
19.05
12.70
MPC10
25.4
20.32
Product Marking
Value (Ohms)
1
Code
2
5
10
20
50
100 200 500
1K
2K
5K
10K 20K 50K 100K200K
503 104 204
1R0 2R0 5R0 100 200 500 101 201 501 102 202 502 103 203
How to Order
MPC
Common Part
52
Power Rating / Size
32 - 3 Watts
MPC - Thick Film
Planar Resistor
52 - 5 Watts
See code in table above
75 - 7 Watts
108 - 10 Watts
F ±1%
J ±5%
1K0
Resistance Value
J
Tolerance
NB: Due to the wide range of available values/tolerances etc.some variants may not be tooled for production.
It is possible that a small tooling charge may be levied dependant on order quantity or potential. Please check.
Literature No. 1773248
Issued: 02-08
Dimensions are shown for
reference purposes only.
Dimensions are in
millimetres unless
otherwise specified.
Specifications subject to
change.
tycoelectronics.com
passives.tycoelectronics.com
