MODULAR JACKS AND PLUGS
KYCON
GDLF
Series
S
GDLF Series
Ordering Information
8
8
Number of
Contacts
50
Plating
Options
Shield Number of
Options Positions
GDLF Series
Right Angle Modular Jack
with Ferrite
Features
• 0.520" Height
LR78160
Series
GDLF - Right Angle Modular Jack with Ferrite
Shield Options
S - Short Shield with Flat Grounding Flaps
S3 - Extended Shield with Flat Grounding Flaps
SA - Short Shield with 20º Angled Grounding Flaps
S3A - Extended Shield with 20º Angled Grounding Flaps
Number of Positions
6 - 6 Opening (Only Available with Shield Option "S")
8 - 8 Opening
Number of Contacts
4 - 4 Contacts
6 - 6 Contacts
8 - 8 Contacts
Plating
50 - 50µ" Gold Plating
Ferrite Specifications
Test Freq.
Impedance
1 Mhz
1 ohm
7 ohms
10 Mhz
13 ohms
30 Mhz
• Shielding Options Available
• Ferrite Block for High Frequency Noise Filtering
• Grounding Flaps Available
• Snap-In Retention Tabs
• Gold Plated Contacts
• CSA/NRTL Certified File No. LR78160
Test Freq.
50 Mhz
100Mhz
Impedance
16 ohms
21 ohms
GDLF Series Dimensions
Dimensions in mm
Performance Specifications
Materials and Finish
Housing Material
PBT Thermoplastic, UL94V-0, Black Color
Shield Material
Copper Alloy, Nickel Plated
Contact Material
Phosphor Bronze
Contact Plating
Standard - 50u" Gold over Nickel on Contacts
Selective Gold Plating on Contact Area.
GDLF-S-66-50, GDLF-S-64-50
18.34
2.67
15.75
13.83
3.50±0.40
1.27
13.19
Pin 1
0.50
5.25
3.05
2.54
8.89
8.12
5.07
10.16
13.72
Electrical Characteristics
Insulation Resistance
500 Megohms Min
Dielectric Withstanding Voltage
1000V AC for 1 Minute
Contact Resistance
20 Milliohms Max
Current Rating
1.5 Amps
8.89
2.54
6.35
1.27
1
3
2
3.81
5
6-Ø0.90
4
6
2-Ø3.25
2-Ø1.60
3.05
10.16
13.72
(Top View)
Recommended PCB Layout
2002
70
KYCON, Inc. • Tel: +1 408-494-0330 • US: 1-888-KYCON-22 • Fax: +1 408-494-0325 • www.kycon.com
FERRITE D-SUBMINIATURE CONNECTORS
KYCON
Directory
Right Angle
KF22 - 0.318" footprint
KF44 - 0.590" footprint
KF66 - High Density 0.350" footprint
KF42 - Dual Port
28
29
30
31
KYCON continues
its leadership in
Ferrite D-Subs by
offering a complete
line of styles,
sizes, and pin
configurations.
Features:
• Applications include Computer
Peripherals, Data Processing,
Telecommunications, Industrial Controls,
and Local Area Networks
• High performance ferrite filter with
superior high frequency attenuation
characteristics
• Minimal effect on fundamental
waveforms
• EMI/RFI noise suppression in data
communication lines
• Cost effective way to meet FCC and VDE
Class B requirements
• Does not require any more board space
than a standard D-Sub
• No need to redesign board layout to
accommodate separate filter placement
• UL Recognized File No. E140125
Vertical
KF85 - Low Profile
KF86 - High Density
KF88 - High Profile
32
33
34
Technical Information:
Ferrite filters provide an easy and efficient way of reducing both radiated and conducted
interference. KYCON uses a medium permeability nickel zinc ferrite material that is most
effective at attenuating frequencies above 30MHz.
Attenuation =20 log
10
Where Z
S
= Source Impedance
Z
F
= Ferrite Impedance
Z
L
= Load Impedance
[Z
s
+Z
F
+Z
L
]
dB
[Z
s
+Z
L
]
With the above impedance values calculated at the interference frequency.
Typical Impedance of KYCON Ferrite D-Sub
1000
2.8mm Plate Tested
Impedance (Ohm)
100
S
F
L
LR78160
10
1
1
10
100
1000
Frequency (MHz)
KYCON Tech Support:
1-888-KYCON-22
or E-mail: sales@kycon.com
2002
The above chart is typical performance data for a 2.8mm thick ferrite plate at room
temperature. Impedance will be reduced by increased temperature (down approx. 15%
at 100°C at 25MHz) and by increased DC bias (down approx. 15% at 1 amp at 25MHz).
Also, impedance varies with ferrite thickness. Please contact our technical support for
data specific to your application.
