DF3A8.2LFU
TOSHIBA Diodes for Protecting against ESD Epitaxial Planar Type
DF3A8.2LFU
Diodes for Protecting against ESD
Unit: mm
•
•
•
The mounting of two devices on an ultra-compact package allows the
number of parts and the mounting cost to be reduced.
The zener voltage corresponds to the E24 Series.
Low Terminal capacitance (between Cathode and Anode)
: C
T
= 5.0 pF (typ.)
Maximum Ratings
(Ta = 25°C)
Characteristics
Power dissipation
Junction temperature
Storage temperature range
Symbol
P
T
j
T
stg
Rating
100
125
−55
~ 125
Unit
mW
°C
°C
JEDEC
JEITA
TOSHIBA
―
―
1-2P1A
Electrical Characteristics
(Ta = 25°C)
Characteristics
Zener voltage
Dynamic impedance
Knee dynamic impedance
Reverse current
Terminal capacitance
(between Cathode and Anode)
Symbol
V
Z
Z
Z
Z
ZK
I
R
C
T
I
Z
=
5 mA
I
Z
=
5 mA
I
Z
=
0.5 mA
V
R
=
5 V
V
R
=
0 V, f
=
1 MHz
Test Condition
Weight: 0.006 g (typ.)
Min
7.8
⎯
⎯
⎯
⎯
Typ.
8.2
⎯
⎯
⎯
5.0
Max
8.6
60
100
0.5
⎯
Unit
V
Ω
Ω
µA
pF
Guaranteed Level of ESD Immunity
Test Condition
IEC61000-4-2
(Contact discharge)
ESD Immunity Level
±
6kV
Criterion: No damage to device elements
Marking
FU
Equivalent Circuit
(top view)
1
2004-09-06
DF3A8.2LFU
