IDC-7328
Vishay Dale
High Current, Surface Mount Inductors
FEATURES
•
•
•
•
High energy storage
Low resistance
Tape and reel packaging for automatic handling
Compliant to RoHS directive 2002/95/EC
ELECTRICAL SPECIFICATIONS
Inductance Range:
1.0 µH to 1000 µH, tested at 1.0 V
RMS
Inductance Tolerance:
20 %, tighter tolerance available
upon request
Operating Temperature:
- 40 °C to + 125 °C
Resistance to Solder Heat:
260 °C for 10 s
MECHANICAL SPECIFICATIONS
Core:
Ferrite
Wire:
Enamelled copper wire
Base:
LCP
Terminals:
Nickel bronze
Adhesive:
Epoxy resin
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE (µH)
1.0
2.2
3.3
5.6
10
15
22
33
47
68
100
150
220
330
470
680
1000
TOLERANCE
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
TEST FREQUENCY L (kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR MAX. (Ω)
0.009
0.014
0.018
0.020
0.031
0.036
0.047
0.066
0.086
0.13
0.19
0.25
0.38
0.56
0.85
1.1
1.8
I
SAT
(A)
20.0
16.0
14.0
12.0
10.0
8.0
7.0
5.5
4.5
3.5
3.0
2.6
2.4
1.9
1.4
1.2
1.0
I
RMS
(A)
8.6
7.1
6.2
5.3
4.3
4.0
3.5
3.0
2.6
2.3
1.8
1.5
1.2
1.0
0.82
0.72
0.56
Notes
• Inductance drop = 10 % typ. at I
SAT
•
ΔT
= 40 °C typ. at I
RMS
DIMENSIONS
in inches [millimeters]
A
Max.
B
Max.
D
Max.
E
G
F
H
J
I
A (Max.)
0.730 [18.54]
B (Max.)
0.600 [15.24]
D (Max.)
0.280 [7.11]
E
0.100 [2.54]
F
0.100 [2.54]
G
0.500 [12.70]
H
0.115 [2.92]
I
0.490 [12.45]
J
0.110 [2.79]
DESCRIPTION
IDC-7328
MODEL
10 µH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
D
PRODUCT
FAMILY
Document Number: 34008
Revision: 13-May-09
C
7
3
SIZE
2
8
E
R
1
0
0
M
TOL
PACKAGE
CODE
INDUCTANCE
VALUE
For technical questions, contact:
