Power Inductors - Shielded
ctparts.com
CTIHLP73F Series
From .15 µH to 10 µH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Parts are only available ±20% inductance tolerance only
*Irms will cause the coil temp. rise approximately
ΔT=40°C
without core loss.
**Isat will cause L0 to drop approximately 20% typ.
Inductance
(µH)
.15
.22
.33
.47
.68
.82
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(mΩ)
2.5
2.8
3.9
4.2
5.5
8.0
10
15
20
30
40
60
68
105
*Irms
Typ.
(A)
26
23
20
17.5
15.5
13
11
9.0
8.0
6.0
5.5
4.5
4.0
3.0
**Isat
Typ.
(A)
38
36
30
26
23
20
16
14
12
10
6.5
6.0
5.5
4.5
CTIHLP73F-R15M
CTIHLP73F-R22M
CTIHLP73F-R33M
CTIHLP73F-R47M
CTIHLP73F-R68M
CTIHLP73F-R82M
CTIHLP73F-1R0M
CTIHLP73F-1R5M
CTIHLP73F-2R2M
CTIHLP73F-3R3M
CTIHLP73F-4R7M
CTIHLP73F-6R8M
CTIHLP73F-8R2M
CTIHLP73F-100M
Compliant
RoHS
PHYSICAL DIMENSIONS
Size
A
B
Max.
7.8
0.31
C
6.86±0.5
0.27±0.02
D
7.0
0.28
E
2.1±0.5
F
1.6±0.5
G
Max.
3.0
0.12
H
Max.
3.2
0.13
mm
6.47±0.5
inches
0.25±0.02
0.08±0.02 0.06±0.02
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
PDA, Notebook, Desktop, Server applications. High
current POL converters. Low profile, high current power supplies.
Battery powered devices. DC/DC converters in distributed power
systems. DC/DC converter for Field Programmable Gate Array
(FPGA).
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100 kHz,
1.0VDC
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
A
E
F
XXX
C
B
G H
Marking:
Inductance code
D
RECOMMENDED LAND PATTERN
Unit: mm
8.7Ref.
3.5Ref.
3.7
Ref.
