To our valued customers:
For over 25 years, Aim Electronics and Cambridge Products have been providing our electronics
distributors and OEM customers with cost-effective, high-quality solutions for connectivity. Since
becoming part of Emerson in 2000, we have continued the tradition of offering these separately
branded product lines to our customers. However, we believe that now is the right time to bring
them together and leverage our strengths into one product line offer.
This catalog marks the first step of combining the power and the product lines of AIM and Cambridge
under the name of
Emerson Network Power Connectivity Solutions.
We will be making this transition
over a period of time and you will continue to see the AIM and Cambridge names used; however, the
overriding message will be that of
Emerson Network Power Connectivity Solutions.
We believe this name
not only reflects our traditional industry focus, but also better communicates the additional resources
that we can supply as part of Emerson Network Power.
Although our name is changing, our commitment to product quality and to excellent service to our
customers will not. Our combined connectivity product line will continue to focus on the installer and
OEM market for data networks, satellite, security systems, telemetry and CATV. This catalog details
our offering of coaxial connectors, cable assemblies, structured cabling solutions, tools, fiber optics
and CATV components to support your application needs and those of your customers. As part of
Emerson Network Power Connectivity Solutions,
our goal is to continue to expand our product
offerings and capabilities to continue to meet your changing needs.
Thank you for allowing us the opportunity to serve you.
Best Regards,
Brian Mason
President
Emerson Network Power
Connectivity Solutions
™
E M E R S O N. C O N S I D E R I T S O LV E D
.
Connectivity Solutions
Table of Contents
Table of Contents
RF Connectors & Adapters
75 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Crimp-On 75 Ohm 3-Piece BNC Connectors . . . . . . . . . . . . . . . . . . . . . . .5
Crimp-On 75 Ohm 2-Piece BNC Connectors . . . . . . . . . . . . . . . . . . . . . . .6
Twist-On 75 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
75 Ohm BNC Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
True 75 Ohm
3-Piece Crimp-On Coinnectors . . . . . . . . . . . . . . . . . . . .7
Twist-On 50 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Chassis Mount 50 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . .8
BNC Terminators & Attennator Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2-Piece Crimp-On 50 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . .9
3-Piece Crimp-On 50 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . .9
6-Piece Screw-On 50 Ohm BNC Connectors . . . . . . . . . . . . . . . . . . . . . . .9
50 Ohm BNC Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
50 Ohm ‘N’ Connectors, Adapters & Terminators . . . . . . . . . . . . . . . . . .11
Mini-UHF Connectors & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
UHF Connectors & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Crimp-On 2 & 3 Piece TNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Twist-On TNC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
TNC Terminators & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SMA Connectors & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Strain Relief Boots & Hoods for Coaxial Connectors . . . . . . . . . . . . . . .15
Stainless Steel Wallplates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
‘F’ Connectors & Adapters
Weatherproof ‘F’ Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
‘F’ 56 Series Connectors for RG-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
‘F’ 59 Series Connectors for RG-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
‘F’ Connectors for RG-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
‘F’ Series Splice Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
‘F’ Connector - Chassis & PCB Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
‘F’ Series Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
‘F’ Voltage Blocks & Attenuator Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Quick Selector–Connector to EMERSON Tool Guide
. . . . . . . . . . .20, 21
Audio/Video Connectors & Adapters
RCA Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
RCA Gold Series Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Weatherproof ‘F’ Compression Connectors . . . . . . . . . . . . . . . . . . . .16, 23
RCA Standard Series Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.5 mm Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Microphone Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Audio Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
1/4" Mono & Stereo Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Banana Plugs & Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
D-Subminiature Connectors & Modular Adapters
D-Sub Crimp Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
D-Sub Hoods with Grommets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
98 & 99 Series Crimp Style D-Sub Connectors . . . . . . . . . . . . . . . . . . . .26
94 Series Crimp Style High Density D-Sub Connectors . . . . . . . . . . . .26
D-Sub Pins & Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
D-Sub Termination Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
D-Sub Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
D-Sub Stainless Steel Wallplates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
97 & 95 Series Solder Style D-Sub Connectors . . . . . . . . . . . . . . . . . . . .28
95 Series Solder Style High Density D-Sub Connectors . . . . . . . . . . . .28
IDC Headers & D-Sub Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
D-Sub Hoods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
D-Sub Modular Adapter Kits (1- & 2-Piece Hood) . . . . . . . . . . . . . . . . .29
Centronics Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Computer & LAN Cables
Premium Multi-Coax Monitor Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
VGA/SVGA Monitor Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Universal Series Bus Cables (USB Ver. 2.0) . . . . . . . . . . . . . . . . . . . . . . .30
IEEE 1284 Parallel Printer Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Bi-Directional Parallel Printer Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Serial DB9 Extension Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
D-Sub Switch Boxes & Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Serial Modem Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
AC Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
D-Sub Gender Changers & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Coaxial Cables
Deluxe RCA Audio Cables with Gold Connectors . . . . . . . . . . . . . . . . . .33
RCA Audio/Video/Speaker Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Wallplate with Gold RCA Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Audio Cables & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Super VHS Video Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
HDMI & DVI Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
75 Ohm ‘F’ to ‘F’ Hook-Up Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Silver Satin Flat Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Coaxial LAN & Video Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Custom Made Coaxial Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36, 37
Fiber Optic Cables
Single & Multi-Mode Fiber Optic Patch Cables . . . . . . . . . . . . . . . . . . .38
Network Cable Assemblies
Category 5E & 6 Patch Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Bulk Cable
Silver Satin Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Cat5E & Cat6 Stranded Patch Cable Wire . . . . . . . . . . . . . . . . . . . . . . . .40
Connectivity Solutions
Tel: 1-800-327-8663
•
Fax: 1-800-282-3952
•
www.EmersonNetworkPower.com/connectivity
3
Table of Contents
Connectivity Solutions
Modular Plugs & Adapters
Modular Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
RJ45 Snagless Boots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Telephone Butt Splices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Modular Couplers & Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Modular Termination Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Voice & Data Structured Cabling
Category 5E & 3 Keystone Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Keystone Inserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Keystone Wallplates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Category 5E Patch Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
110 Blocks & Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
66 Block & Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Wire Management Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Hinged Patch Panel Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Modular Surface Mount Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Modular Telephone Wallpates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
TV/CATV Devices
CATV Splitters - 5 MHz to 900 MHz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
CATV Power Passing Splitters - 5 MHz to 900Mhz . . . . . . . . . . . . . . . . .45
CATV Drop Taps - 5 MHz to 1000 MHz . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Power Passing Drop Taps - 5 MHz to 900 MHz . . . . . . . . . . . . . . . . . . .46
Blocking Coupler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Digital Couplers/Drop Taps by Viewsonics® . . . . . . . . . . . . . . . . . . . . . .46
CATV 12 & 16-Way Splitters - 5 MHz to 1 GHz by Viewsonics® . . . . .47
CATV Digital Splitters - 5 MHz to 1 GHz by Viewsonics® . . . . . . . . . . .47
CATV Digital Amplifiers - 54 MHz to 1 GHz by Viewsonics® . . . . . . . .47
CATV Coaxial Amplifiers - 54 MHz to 900 MHz, 5 MHz to 500 MHz . .48
‘F’ Attenuator Pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
CATV Modulator & Combiner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
TV/CATV/Satellite - F-81 Wallplates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
TV/CATV/VCR - Matching Transformers . . . . . . . . . . . . . . . . . . . . . . . . . .49
CATV/SATV Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Tools & Test Equipment
Network Installer Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Cable & Network Test Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Cable Tester Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Pro-Series 110 & 66 Impact Punch Down Tools . . . . . . . . . . . . . . . . . . .51
Impact & Non-Impact Punch Down Tools . . . . . . . . . . . . . . . . . . . . . . . .51
Modular Plug Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Wire Stripping Tools & Cutters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
D-Sub Crimping & Termination Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
D-Sub Insertion Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
‘F’ Coaxial Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Economy ‘F’ Series Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Heavy Duty ‘F’ Hex Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Universal Coaxial Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Standard Series Ratchet Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . .55
Offset Ratchet Crimping Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Self-Adjusting Coax Strippers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
3-Step & 2-Step Coax Strippers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Nylon Cable Ties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Tool & Work Bench Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Power Supplies & Adapters
AC Surge Protectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
AC/DC Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
AC Power Converters for Foreign Travel . . . . . . . . . . . . . . . . . . . . . . . . .58
AC/DC Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59-64
Aim & Cambridge Cross-Reference
. . . . . . . . . . . . . . . . . . . . . . . . . .64, 65
Coaxial Connector Termination Instructions
. . . . . . . . . . . . . . . . . . . . .66
4
Connectivity Solutions
Tel: 1-800-327-8663
•
Fax: 1-800-282-3952
•
www.EmersonNetworkPower.com/connectivity
Connectivity Solutions
RF Connectors & Adapters
We have been offering a complete line of quality RF connectors for over 25 years.
Available in 50 and 75 ohm versions, these connectors are designed to offer the
highest quality data transmission for audio, video and data applications, and are
available in BNC, ‘N’ UHF, Mini-UHF, TNC, SMA and ‘F’ versions. If you are
looking for preassembled RF cables, our custom cable department offers the
capability to build any assembled or molded cable to your custom length or
configuration using any of these connectors and more.
75 Ohm BNC Connectors
Electrical Characteristics
Impedance
Working voltage
Frequency range
Contact resistance
(.000050 gold)
Insulation resistance
Dielectric withstanding
voltage
Corona Level
5,000 megohms minimum
1,500 volts, RMS at sea level
375 volts minimum at 70,000 ft.
75 Ohm
500 volts, RMS at sea level
0-2 GHz with low reflection
Outer-0.2 milliohms
Center-2.1 milliohms
Crimp-On 75 Ohm 3-Piece BNC Connectors
Crimp BNC (M)
3 Piece
Environmental Characteristics
Recommended
temperature range
Vibration
Shock
Moisture resistance
-55 C to +85 C
MIL-Std. 202
MIL-Std. 202, 100Gs
MIL-Std. 202
Part No.
28-91007 (CPMC782)
28-91027 (CPMC785)
28-91037 (CPMC7810)
28-91047 (CPMC783)
28-91057 (CPMC7818)
28-91457
28-91477
28-91507
CPMC7820
Mechanical Characteristics
Durability
Force to engage/disengage
Coupling nut retention
Cable retention
500 Cycles (.000050 gold)
3 lbs. maximum
60 lbs. maximum
60 lbs. with 95% braid
coverage - RG58c/u cable
Compatible Cable
Belden 1505A,
RG-59, RG-62
Belden RG-6
Belden 1506A,
RG-59TFE & RG-62TFE
Belden 8281, 9141, 9231
Belden 8218, 1855A, 735A
Belden 9248, 1694A
Belden 8221, 8241,
8263, 8279, 9244
Belden 82259, 89259
RG-179, RG-187
Crimper
24-9959P
24-8856P
24-9958P
24-8859P
24-9912P
24-8856P
24-8789P
24-8789P
24-9912P
Stripper
24-7732P
24-7733P
24-7733P
24-7733P
24-7734P
24-7733P
24-7736P
24-7736P
24-7733P
Materials
Body
Contact
Spring washer
Insulator
Plating
Zinc
Brass
Berilium copper
Teflon
Body - Nickel
Contact - Gold
Solder or Crimp BNC (M)
3 Piece
Tool No.
Part No. Cable Type
28-90237 RG-59 & 62
24-8789P
28-90257 RG-59 & 62TFE 24-9958P
(M) = Male Plug (F) = Female Socket
Connectivity Solutions
Tel: 1-800-327-8663
•
Fax: 1-800-282-3952
•
www.EmersonNetworkPower.com/connectivity
5
Power technology
京公网安备 11010802033920号
EEWORLD
