PIN RECEPTACLES

for 1,22 - 1,63 diameter pins (#13 contact)

and 1,14 - 1,65 diameter pins (#23 contact)

PR

E

CI

M

ON

S

I

CHI

A

PINS

NE

D

0364

0,46

3,05 DIA.

3,56

0363

3,0 DIA.

1,27

2,97

4,57

0365

0,66

3,05 DIA.

2,54

4,83

2,49 DIA.

6,48

5,66

0366

3,48 DIA.

2,84 DIA.

KNURL

2,62 DIA.

0,38

0,94

1,27

3,4

6,35

2,49 DIA.

5,41

2,54 DIA.

7,37

2,77 DIA.

2,24 DIA.

HOLE

0364-0-15-XX-13-XX-10-0

Solder mount in 2,54 min. mounting hole

Also available on 16mm wide carrier

tape: 1,300 parts per 330mm reel.

Order as: 0364-0-57-XX-13-XX-10-0

0363-0-15-XX-23-XX-10-0

Solder mount in 2,59 min.

mounting hole

0365-0-15-XX-23-XX-10-0

Hex press-fit in 2,67

plated thru hole

0366-0-15-XX-13-XX-10-0

Press-fit in 2,77 mounting hole

0372

0,30

3,0 DIA.

3,4

2,54 DIA.

5,72

0362

0,30

2,92 DIA.

2,79

or

3,3

2,54 DIA.

7,44

0367

3,18 DIA.

2,54 DIA.

0,86

2,54

3,56

4,83

9324

3,02 DIA.

0,79

1,93 2,97

5,08

2,77 DIA.

2,64 DIA.

6,35

0,81

SQUARE

2,41

2,24 DIA.

HOLE

2,24 DIA.

HOLE

1,04 DIA.

3,68

0372-0-15-XX-13-XX-10-0

Solder mount in 2,59 min. mounting hole

Also available on 24mm wide carrier

tape: 950 parts per 330mm reel.

Order as: 0372-0-57-XX-13-XX-10-0

0362-0-15-XX-X3-XX-10-0

Solder mount in 2,59 min.

mounting hole

0367-0-15-XX-23-XX-10-0

Square press-fit in 1,02

plated thru hole

9324-0-15-XX-23-XX-04-0

Press-fit in 2,69 mounting hole

0492

3,02 DIA.

2,69 DIA.

2,77 DIA.

2,62 DIA.

0,79

1,93 3,56

5,08

6,86

0381

2,79 DIA.

2,72 DIA.

1,32

1,22

2,79

6,48

7,37

2,49 DIA.

4034

3,12 DIA.

2,84 DIA.

0,79

0,76 2,79

9,53

15,24

2,59 DIA.

3044

2,97 DIA.

0,79

2,79

2,59 DIA.

6,6

7,87

1,04 DIA.

3,18

1,73 DIA.

1,02 DIA.

3,18

2,54

0492-0-15-XX-13-XX-04-0

Press-fit in 2,69 mounting hole

0381-0-15-XX-23-XX-10-0

Press-fit in 2,64 mounting hole

4034-0-15-XX-23-XX-04-0

Press-fit in 2,77 mounting hole

3044-0-15-XX-23-XX-04-0

Solder mount in 2,64 min.

mounting hole

SPECIFICATIONS

SHELL MATERIAL:

Brass Alloy 360, 1/2 Hard

CONTACT MATERIAL:

Beryllium Copper Alloy 172, HT

DIMENSION IN INCHES

TOLERANCES ON:

LENGTHS:

±0,13

DIAMETERS: ±0,05

ANGLES:

± 2°

ORDER CODE: XXXX - X - 15 - XX - XX - XX - XX - 0

BASIC PART #

SPECIFY SHELL FINISH:

01

5,08μm TIN/LEAD OVER NICKEL



80

5,08μmTIN OVER NICKEL (RoHS)



15

0,25μm GOLD OVER NICKEL (RoHS)

2002/95/EC

SPECIFY CONTACT FINISH:

01

5,08μm TIN/LEAD OVER NICKEL



80

5,08μm TIN OVER NICKEL (RoHS)



27

0,76μm GOLD OVER NICKEL (RoHS)

RoHS

SELECT CONTACT

#13 or #23

CONTACT (DATA ON PAGE 226)
