DZ23C2V4
THRU
DZ23C75
300
mW
Zener Diode
2.4 to
75
Volts
SOT-23
A
D
Features
•
Lead Free Finish/RoHS Compliant ("P" Suffix
designates
RoHS Compliant. See ordering information)
Dual zeners in common cathode configuration.
300mW power dissipation rating.
Ideally suited for automatic insertion.
•
•
•
•
•
•
•
vz for both diodes in one case is
5%.
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Halogen
free available upon request by adding suffix "-HF"
C
B
Absolute Maximum Ratings
Symbol
Parameter
Rating
Unit
F
E
P
D
Power dissipation
Thermal Resistance, Junction to Ambient Air
300
mW
o
G
H
J
R
thJA
T
STG
L
420
-65 to +150
C/W
o
C
K
Storage Temperature Range
DIMENSIONS
*Pin Configuration - Top View
DIM
A
B
C
D
E
F
G
H
J
K
L
INCHES
MIN
.110
.083
.047
.035
.070
.018
.0005
.035
.003
.015
.007
MAX
.120
.104
.055
.041
.081
.024
.0039
.044
.007
.020
.020
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
.20
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
.50
NOTE
Revision:
C
www.mccsemi.com
1 of 4
2013/01/01
DZ23C2V4-DZ23C75
50
MCC
Micro Commercial Components
Tj=25
O
C
Iz, ZENER CURRENT (mA)
40
TM
Pd, POWER DISSIPATION (mW)
400
C2V7
C3V9
C5V6
C6V8
C2V4
C3V3
C4V7
300
C8V2
30
200
20
100
10
Test Current Iz
5.0mA
0
0
100
T
A
, AMBIENT TEMPERATURE, (
O
C)
200
0
0
1
2
3
4
5
6
7
8
9
10
Vz, ZENER VOLTAGE(V)
Fig.1 POWER DERATING CURVE
Fig.2 ZENER BREAKDOWN CHARACTERISTICS
30
10
Tj=25
O
C
Iz, ZENER CURRENT (mA)
Iz, ZENER CURRENT (mA)
C10
C12
C15
20
8
Tj=25
O
C
C39
C47
C43
C51
C62
C75
C56
C68
6
Test Current Iz
5mA
C18
C22
10
Test Current Iz
5mA
C27
C33
4
C36
2
0
0
10
20
30
40
0
0
10
20
30
40
50
60
70
80
90
100
Vz, ZENER VOLTAGE(V)
Vz, ZENER VOLTAGE(V)
Fig.3 ZENER BREAKDOWN CHARACTERISTICS
Fig.4 ZENER BREAKDOWN CHARACTERISTICS
1000
C
T
, TOTAL CAPACITANCE (pF)
Tj=25 C
V
R
= 1V
V
R
= 2V
O
100
V
R
= 1V
V
R
= 2V
10
1
10
100
Vz, NOMINAL ZENER VOLTAGE(V)
Revision:
C
www.mccsemi.com
3 of 4
Fig.5 TOTAL CAPACITANCE VS NOMINAL ZENER VOLTAGE
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel:
3Kpcs/Reel
