DG5805S: DescriptionSingle Color LED, Green, Water Clear, T-1 3/4, 5mm, ROHS COMPLIANT, PLASTIC PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size660KB，30 Pages; ManufacturerStanley Electric Co

Download Datasheet Parametric Compare View All

DG5805S Overview

Single Color LED, Green, Water Clear, T-1 3/4, 5mm, ROHS COMPLIANT, PLASTIC PACKAGE-2

DG5805S Parametric

Parameter Name	Attribute value
Maker	Stanley Electric Co
package instruction	ROHS COMPLIANT, PLASTIC PACKAGE-2
Reach Compliance Code	unknown
color	GREEN
Configuration	SINGLE
Maximum forward current	0.025 A
Lens type	WATER CLEAR
Nominal luminous intensity	800.0 mcd
Installation features	RADIAL MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	7.6 mm
method of packing	BULK
peak wavelength	522 nm
shape	ROUND
size	5 mm
surface mount	NO
T code	T-1 3/4
Terminal pitch	2.5 mm
perspective	40 deg
Base Number Matches	1

Preview

Download Datasheet

View All

58□5S Series

Features

Package

φ5

Round shape type,

DB,DC,DG

: Water Clear epoxy

YPY,FY

: Pale Yellow Clear epoxy

: Pale Orange Clear epoxy

: Pale Red Clear epoxy

・Outer

Dimension

φ5

Flush Mount Round shape type

・Operation

temperature range.

Storage Temperature

:-40℃½100℃

Operating Temperature

:-40℃½85℃

・No

lead package and lead–free soldering compatible

・RoHS

compliant

Single Color

φ5

Flush Mount Round Shape Type

Product features

Dominant wavelength

Blue

Blue Green

Green

Yellow Green

Yellow

Orange

Red

DB,DC,DG

YPY,FY,FA,FR

470nm (DB)

505nm (DC)

525nm (DG)

572nm (YPY)

590nm (FY)

605nm (FA)

626nm (FR)

Half Intensity Angle

: 40 deg.

: 50 deg.

Die materials

Rank grouping parameter

Soldering methods

ESD

Packing

DB,DC,DG : InGaN, YPY,FY,FA,FR : AlGaInP

Sorted by luminous intensity per rank taping

TTW (Through The Wave) soldering and manual soldering

InGan : Less than 1kV(HBM),

Bulk : 200pcs(MIN.)

AlGaInP : More than 2kV(HBM)

Recommended Applications

Amusement Equipment, Electric Household Appliances, OA/FA, Other General Applications

2005.3.31

Page 1

DG5805S Related Products

	DG5805S	DC5805S	DB5805S
Description	Single Color LED, Green, Water Clear, T-1 3/4, 5mm, ROHS COMPLIANT, PLASTIC PACKAGE-2	Single Color LED, Blue Green, Water Clear, T-1 3/4, 5mm, ROHS COMPLIANT, PLASTIC PACKAGE-2	Single Color LED, Blue, Water Clear, T-1 3/4, 5mm, ROHS COMPLIANT, PLASTIC PACKAGE-2
package instruction	ROHS COMPLIANT, PLASTIC PACKAGE-2	ROHS COMPLIANT, PLASTIC PACKAGE-2	ROHS COMPLIANT, PLASTIC PACKAGE-2
Reach Compliance Code	unknown	unknown	unknown
color	GREEN	BLUE GREEN	BLUE
Configuration	SINGLE	SINGLE	SINGLE
Maximum forward current	0.025 A	0.025 A	0.025 A
Lens type	WATER CLEAR	WATER CLEAR	WATER CLEAR
Nominal luminous intensity	800.0 mcd	800.0 mcd	240.0 mcd
Installation features	RADIAL MOUNT	RADIAL MOUNT	RADIAL MOUNT
Number of functions	1	1	1
Number of terminals	2	2	2
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Optoelectronic device types	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
total height	7.6 mm	7.6 mm	7.6 mm
method of packing	BULK	BULK	BULK
peak wavelength	522 nm	502 nm	467 nm
shape	ROUND	ROUND	ROUND
size	5 mm	5 mm	5 mm
surface mount	NO	NO	NO
T code	T-1 3/4	T-1 3/4	T-1 3/4
Terminal pitch	2.5 mm	2.5 mm	2.5 mm
perspective	40 deg	40 deg	40 deg
Base Number Matches	1	1	1
Maker	Stanley Electric Co	Stanley Electric Co	-
