OBSOLETE PRODUCT
Contact factory for replacement model
HPR7XXC
FEATURES
ROHS COMPLIANT
EFFICIENCY >80%
SIP PACKAGE
HIGH POWER DENSITY: >16 WATTS/INCH
3
5 W
ATT
U
NREGULATED
SIP DC/DC C
ONVERTER
LOW COST
SINGLE AND DUAL OUTPUTS
INTERNAL INPUT AND OUTPUT FILTERING
SIX-SIDED SHIELDING
DESCRIPTION
The HPR7XXC Series provides high power densities where
space is critical. The small SIP package measures only
2.2" x .3" x .4" (56 x 9 x 10 mm). Designed for high density
boards, the package is non-conductive, which presents advantages
over painted metal enclosures.
The series includes many different voltage models (other input
and output voltages are available upon request), all set in a low
thermal resistance molding compound, called Iso-ThermoFlex ,
which provides excellent heat dissipation of internal components.
The use of surface mount devices and manufacturing processes,
combined with the encapsulation process, assure the user that the
product is more environmentally rugged than any other DC/DC
converter of its type.
Operation down to no load will not impact the reliability of the
series, although this product has a 10mA minimum load for
specification purposes. It is recommended that all pins be used
for current carrying capacity even though duplicate pin-outs are
internally connected.
The HPR7XXC has 500VDC isolation barrier between input and
output, offering the designer maximum flexibility in grounding
options and polarity configurations. The outstanding MTTF,
superior reliability, and low cost make it an excellent choice for
any high power-density applications.
MECHANICAL
2.210 + 0-.10
(56.13)
PIN CONNECTIONS: Duals
1. +VIN
2. +VIN
6. -VIN
7. -VIN
9. -VIN
14. +VOUT
15. COM
19. COM
20. -VOUT
TOP
VIEW
0.340 + .010
(8.64)
PIN CONNECTIONS: Singles
1. +VIN
2. +VIN
7. -VIN
9. -VIN
14. +VOUT
15. +VOUT
19. -VOUT
20. -VOUT
FRONT
VIEW
0.030 + -.010
(0.76)
0.020 + .002
(0.51)
0.400 + .010
(10.16)
0.140 + .020
(3.56)
CL
0.050 + .015
(1.27)
6. -VIN
0.140 + .020
(3.56)
0.010 + .002
(0.25)
0.155 + -.15
(3.94)
RIGHT SIDE
VIEW
BOTTOM
VIEW
1 2
6 7
9
14 15
19 20
All dimensions are in inches (millimeters)
GRID: 0.100 inches (2.54 millimeters)
PIN PLACEMENT TOLERANCE: ±0.015"
HPR7XXC
REV. B (MPS)
12/2008
Page 1
ELECTRICAL CHARACTERISTICS
Specifications typical at T
A
= +25°C, nominal input voltage, rated output current unless otherwise specified.
NOMINAL
INPUT
VOLTAGE
(VDC)
5
5
5
5
12
12
12
15
15
RATED
OUTPUT
VOLTAGE
(VDC)
5
±5
±12
±15
5
±12
±15
5
±15
RATED
OUTPUT
CURRENT
(mA)
1000
±500
±208
±167
1000
±208
±167
1000
±167
INPUT CURRENT
NO LOAD
RATED LOAD
(mA)
70
70
70
70
25
25
25
20
20
(mA)
1250
1250
1190
1190
490
490
490
407
392
REFLECTED
RIPPLE
CURRENT
(mAp-p)
15
15
15
15
15
15
15
15
15
EFFICIENCY
(%)
80
80
84
84
80
85
85
82
85
MODEL
HPR700C
HPR703C
HPR704C
HPR705C
HPR706C
HPR710C
HPR711C
HPR712C
HPR717C
Note: Other input to output voltage options may be available. Please consult factory.
COMMON SPECIFICATIONS
Specifications typical at T
A
= +25°C, nominal input voltage, rated output current unless otherwise specified.
PARAMETER
INPUT
Voltage Range
CONDITIONS
MIN
TYP
MAX
UNITS
V
DC
V
DC
V
DC
Voltage Rise Time
ISOLATION
Rated Voltage
Test Voltage
Resistance
Capacitance
Leakage Current
OUTPUT
Rated Power
Voltage Setpoint Accuracy
Temperature Coefficent
Ripple & Noise
Voltage
4.75
5
5.25
11.4
12
12.6
14.2
15
15.8
See Application Note: "Capacitive Loading Effects on Start-Up of DC/DC Converters"
60 Hz, 10 seconds
500
500
1
55
5
V
ISO
= 240VAC, 60Hz
V
DC
Vpk
GW
pF
μArms
Rated Load, Nominal V
IN
BW = DC to 10MHz
BW =10Hz to 2MHz
I
L
=10mA, V
OUT
= 5V
I
L
=10mA, V
OUT
= ±12V
I
L
=10mA, V
OUT
= ±15V
5
±3
±0.05
50
5
5.75
13.10
16.25
W
%
%/Deg C
mVp-p
mVrms
V
DC
V
DC
V
DC
REGULATION
Line Regulation
Load Regulation (5V out only)
Load Regulation (All other Models)
GENERAL
Switching Frequency
Package Weight
MTTF per MIL-HDBK-217, Rev. E
Ground Benign
TEMPERATURE
Specification
Operation
Storage
High Line to Low Line
Rated Load to No Load
Rated Load to No Load
1.2
15
10
%/%Vin
%
%
170
7
Circuit Stress Method
T
A
= +25°C
2000
kHz
g
kHr
-25
-40
-40
+25
+70
+85
+110
°C
°C
°C
ABSOLUTE MAXIMUM RATINGS
Internal Power Dissipation.......................................................................1.7W
Short Circuit Protection..................................................................Momentary
Lead Temperature (soldering, 10 seconds max)................................+300°C
ORDERING INFORMATION
HPR
Device Family
HPR indicates DC/DC converter
Model Number
RoHS Compliant
7XX
C
Page 2
HPR7XXC
REV. B (MPS)
12/2008
TYPICAL PERFORMANCE CURVES
Specifications typical at T
A
= +25°C, rated input voltage, rated output current unless otherwise specified.
V
OUT
VS LOAD
5.6
5.4
Vout
5.2
5.0
4.8
10
250
500
750
Output Current (mA)
V
OUT
VS LOAD
12.6
12.4
Vout
Vout
12.2
12.0
11.8
10
250
500
750
Output Current (mA)
1000
(+12V
OUT
Models)
15.6
15.4
15.2
15.0
14.8
10
1000
Vout
(5V
OUT
Models)
5.6
5.4
5.2
5.0
4.8
10
V
OUT
VS LOAD
(+5V
OUT
Models)
250
500
750
Output Current (mA)
V
OUT
VS LOAD
(+15V
OUT
Models)
1000
250
500
750
Output Current (mA)
1000
THROUGH-HOLE SOLDERING INFORMATION
These devices are intended for wave soldering or manual soldering.
They are not intended to be subject to surface mount processes under any circumstances.
The normal wave soldering process can be used with these devices where the device is subjected to a maximum wave temperature
of 260°C for a period of no more than 10 seconds. Within this time and temperature range, the integrity of the device’s plastic body
will not be compromised and internal temperatures within the converter will not exceed 175°C. Care should be taken to control manual
soldering limits identical to that of wave soldering.
The information provided herein is believed to be reliable; however, MuraTA POWER SOLUTIONS assumes no responsibility for inaccuracies or omissions. MuraTA POWER SOLUTIONS assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change without notice. No patent rights
or licenses to any of the circuits described herein are implied or granted to any third party. MuraTA POWER SOLUTIONS does not authorize or warrant any MuraTA POWER SOLUTIONS product for
use in life support devices/systems or in aircraft control applications.
USA:
Canada:
UK:
Mansfield (MA), Tel: (508) 339 3000, email: sales@murata-ps.com
Toronto, Tel: (866) 740 1232, email: toronto@murata-ps.com
Milton Keynes, Tel: +44 (0)1908 615232, email: mk@murata-ps.com
Montigny Le Bretonneux, Tel: +33 (0)1 34 60 01 01, email: france@murata-ps.com
Tokyo, Tel: 3-3779-1031, email: sales_tokyo@murata-ps.com
Osaka, Tel: 6-6354-2025, email: sales_osaka@murata-ps.com
Shanghai, Tel: +86 215 027 3678, email: shanghai@murata-ps.com
Guangzhou, Tel: +86 208 221 8066, email: guangzhou@murata-ps.com
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
Tel: (508) 339-3000 (800) 233-2765 Fax: (508) 339-6356
www.murata-ps.com email: sales@murata-ps.com ISO 9001 & ISO 14001 REGISTERED
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2008 Murata Power Solutions, Inc.
France:
Japan:
China:
Germany:
München, Tel: +49 (0)89-544334-0, email: ped.munich@murata-ps.com
Singapore:
Parkway Centre, Tel: +65 6348 9096, email: singapore@murata-ps.com
HPR7XXC
REV. B (MPS)
12/2008
Page 3
