Series 181 Thru 184
Flat Pin Staked Flex Jumpers
FEATURES:
• Aries 90° Pin Staked Flex Jumpers combine thin, flexible, solid
E
IM
Copper conductors embedded between layers of tough, flexible,
T
flame-retardant insulation.
IS
TH
• Consult factory for cable lengths under 2.000 [50.80].
T
GENERAL SPECIFICATIONS:
EA
L
• Standard cable insulation is white UL VW-1, Style 2643 flame
AB
IL
retardant Polyester (Mylar) adhesive.
VA
• High temperature flame retardant cable insulation is Polyimide
EA
(Kapton) insulation with acrylic adhesive.
R
TU
• Cable conductors are solid Copper with a cross-sectional area
PIC
equivalent to that of 26 gauge AWG.
• Female housing is black UL 94V-0 Glass-filled Thermoplastic
NO
Polyester.
• Female and male “crimp-on” pins are spring-tempered Copper
Note: Aries specializes in custom design and production. In addition to the
Alloy 510.
standard products shown on this page, special materials, platings, sizes, and
• Female and male pin plating is 100µ [2.54µm] min. Tin per MIL-T-
configurations can be furnished, depending on quantities. Aries reserves the
10727 over 50µ [1.27µm] min. Nickel per QQ-N-290. Female pin
right to change product specifications without notice.
also available with 30µ [.76µm] min. Gold per MIL-G-45204 in
ORDERING INFORMATION
contact area.
• Cable current rating=3 Amps
X X - X X X X - 1 8 X X X X
Optional Suffix:
No. of
• Cable voltage rating=300 Volts
HT-High temp.
• Cable dielectric strength=2500 Volts/mil, minimum (standard)
Conductors
cable insula-
=4000 Volts/mil, minimum (high temp)
(4 thru 40)
tion
• Cable insulation resistance=1000 MOhms minimum (standard)
Cable Length
=100,000 MOhms (high temp)
Jumper Series:
“L” in inches
Operating temperature=67 to 257°F [-55 to 105°C].
181: male Tin both ends
(min. Length
• Female housing accepts leads .024-.030 [.61-.76] square,
182: male Tin/female Tin
=2.00 [50.80]
.150 [3.81] long minimum.
183: female Tin both ends
MOUNTING CONSIDERATIONS:
184: male Tin/female Gold
• Suggested PCB hole size=.032+ .002 [.81 + .05] dia.
185: female Gold both ends
“A”=NO. OF CONDUCTORS X .100 [2.54]
“B”=(NO. OF CONDUCTORS -1) X .100 [2.54]
Kapton is a registered trademark for DuPont
**Aries reserves the right to shop with
or without a polarization stripe nless
otherwise specified by customer
A
LL
DIMENSIONS
:
INCHES
[
MILLIMETERS
]
All tolerances ± .005 [.13]
unless otherwise specified
REV. A
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
http://www.arieselec.com • info@arieselec.com
NORTH AMERICA
Frenchtown, NJ USA
TEL: (908) 996-6841
FAX: (908) 996-3891
UK/IRELAND/GB
TEL: +44 870 240 0249
FAX: +44 1653 600493
uking@arieselec.com
EUROPE/MAINLAND/HOLLAND
TEL: +31 78 615 94 65
FAX: +31 78 615 43 11
11019
