2SK3077
TOSHIBA FIELD EFFECT TRANSISTOR SILICON N CHANNEL MOS TYPE
2SK3077
900 MHz BAND AMPLIFIER APPLICATIONS (GSM)
(Note)The TOSHIBA products listed in this document are intended for
high frequency Power Amplifier of telecommunications equipment. These
TOSHIBA products are neither intended nor warranted for any other use.
Do not use these TOSHIBA products listed in this document except for
high frequency Power Amplifier of telecommunications equipment.
Output Power
Gain
Drain Efficiency
: P
O
= 15.0 dBmW (Min.)
: G
P
= 15.0 dB (Min.)
:
η
D
= 20% (Typ.)
Unit: mm
MAXIMUM RATINGS
(Ta = 25°C)
CHARACTERISTIC
Drain-Source Voltage
Gate-Source Voltage
Drain Current
Power Dissipation
Channel Temperature
Storage Temperature Range
SYMBOL
V
DSS
V
GSS
I
D
P
D*
T
ch
T
stg
RATING
10
5
0.1
250
150
−45~150
UNIT
V
V
A
mW
°C
°C
*:
Tc = 25°C When mounted on a 1.6 mm glass epoxy PCB
JEDEC
JEITA
TOSHIBA
—
—
2−2K1D
MARKING
1
2007-2-19
2SK3077
RESTRICTIONS ON PRODUCT USE
•
The information contained herein is subject to change without notice.
030619EAA
•
The information contained herein is presented only as a guide for the applications of our products. No
responsibility is assumed by TOSHIBA for any infringements of patents or other rights of the third parties which
may result from its use. No license is granted by implication or otherwise under any patent or patent rights of
TOSHIBA or others.
•
TOSHIBA is continually working to improve the quality and reliability of its products. Nevertheless, semiconductor
devices in general can malfunction or fail due to their inherent electrical sensitivity and vulnerability to physical
stress. It is the responsibility of the buyer, when utilizing TOSHIBA products, to comply with the standards of
safety in making a safe design for the entire system, and to avoid situations in which a malfunction or failure of
such TOSHIBA products could cause loss of human life, bodily injury or damage to property.
In developing your designs, please ensure that TOSHIBA products are used within specified operating ranges as
set forth in the most recent TOSHIBA products specifications. Also, please keep in mind the precautions and
conditions set forth in the “Handling Guide for Semiconductor Devices,” or “TOSHIBA Semiconductor Reliability
Handbook” etc..
•
The TOSHIBA products listed in this document are intended for high frequency Power Amplifier of
telecommunications equipment.These TOSHIBA products are neither intended nor warranted for any other
use.Do not use these TOSHIBA products listed in this document except for high frequency Power Amplifier of
telecommunications equipment.
•
The TOSHIBA products listed in this document are intended for usage in general electronics applications
(computer, personal equipment, office equipment, measuring equipment, industrial robotics, domestic appliances,
etc.). These TOSHIBA products are neither intended nor warranted for usage in equipment that requires
extraordinarily high quality and/or reliability or a malfunction or failure of which may cause loss of human life or
bodily injury (“Unintended Usage”). Unintended Usage include atomic energy control instruments, airplane or
spaceship instruments, transportation instruments, traffic signal instruments, combustion control instruments,
medical instruments, all types of safety devices, etc.. Unintended Usage of TOSHIBA products listed in this
document shall be made at the customer’s own risk.
•
TOSHIBA products should not be embedded to the downstream products which are prohibited to be produced
and sold, under any law and regulations.
4
2007-2-19
