301AEN122U6R3B3 datasheet, PDF

Datasheet> All Categories > Passive components> 301AEN122U6R3B3

301AEN122U6R3B3: DescriptionAluminum electrolytic capacitor - with lead 1200uf 6.3V -10+75%; CategoryPassive components; File Size380KB，11 Pages; ManufacturerAll Sensors; Environmental Compliance

Download Datasheet Parametric Compare View All

301AEN122U6R3B3 Overview

Aluminum electrolytic capacitor - with lead 1200uf 6.3V -10+75%

301AEN122U6R3B3 Parametric

Parameter Name	Attribute value
Maker	All Sensors
Product Category	Aluminum Electrolytic Capacitors - Leaded
RoHS	yes
capacitance	1200 uF
Tolerance	- 10 % to 75 %
Voltage rating	6.3 Volts
range of working temperature	- 55 C to + 105 C
Termination type	Radial
size	13 mm Dia. x 35 mm L
product	High Temp Electrolytic Capacitors
Lead spacing	5 mm
Encapsulation	Bulk

Preview

Download Datasheet

View All

Type 300/301

–55

ºC to 105 ºC Long-Life, Switching Power Grade Radial

High Capacitance and Ultra-Low ESR

The Types 300 and 301 are the wide-temperature, low-ESR

capacitors for power-supply outputs and UPS battery stiffening.

The exceptionally low ESRs enable high ripple-current capability.

With series inductance of 12 to 16 nH and ripple currents to 16

amps one of these capacitors can save by replacing three or four

of the 12.5 mm diameter capacitors routinely at the output of

switching power supplies. Type 300 has three leads for rugged,

reverse-proof mounting, and Type 301 has two leads. Types

300R and 301R deliver even lower ESR and higher ripple.

Please click here to see notice regarding “Longer life non RoHS parts”

Highlights

4000 hour load life

Ripple Current to 16 amps

ESRs to 6 mΩ

> 90% capacitance at –40 °C

Replaces multiple capacitors

Specifications

Temperature Range

Rated Voltage Range

Capacitance Range

Capacitance Tolerance

Leakage Current

Ripple Current Multipliers

–55 °C to +105 °C

6.3 to 250 Vdc

8.2 µF to 33,000 µF

6.3 to 100 Vdc; –10 + 75%, 160 to 250 Vdc; –10 +50%

≤0.5 √CV µA, 4 mA max, 5 minutes

Ambient Temperature

45 ºC

55 ºC

65 ºC

1.66

1.52

Frequency

1.37

75 ºC

1.20

120

1.00

85 ºC

1.00

95 ºC

0.75

105 ºC

0.36

50 Hz 60 Hz

Less than .77” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

.77” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

.895” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

1.02” Diameter

6.3 & 7.5 V

10 to 40 V

50V

63 & 75 V

100 to 250 V

0.84

0.81

0.76

0.77

0.76

0.88

0.86

0.81

0.82

0.80

0.75

0.76

0.86

0.84

0.80

0.81

0.82

0.78

0.76

0.74

0.76

0.86

0.83

0.81

0.80

0.81

0.76

0.74

0.72

0.71

0.68

0.81

0.79

0.78

0.76

0.74

360

10 kHz

1 kHz 5 kHz

& up

1.23

1.29

1.33

1.38

1.51

1.15

1.20

1.25

1.28

1.24

1.14

1.17

1.27

1.26

1.25

1.12

1.15

1.23

1.24

1.35

1.46

1.54

1.64

2.00

1.21

1.30

1.38

1.43

1.37

1.20

1.25

1.42

1.40

1.38

1.17

1.22

1.35

1.37

1.41

1.55

1.67

1.82

2.51

1.24

1.35

1.45

1.52

1.44

1.23

1.29

1.50

1.48

1.46

1.19

1.25

1.42

1.44

1.43

1.57

1.69

1.86

2.67

1.25

1.36

1.47

1.54

1.46

1.24

1.30

1.52

1.50

1.48

1.20

1.26

1.44

1.46

CDM Cornell Dubilier

•

140 Technology Place

•

Liberty, SC 29657

•

Phone: (864)843-2277

•

Fax: (864)843-3800
