W83627HF/F

W83627HG/G

Winbond LPC I/O

Date： 2006/06/09

Revision： 2.27

W83627HF/ F/ HG/ G

Table of Content-

GENERAL DESCRIPTION ......................................................................................................... 1

FEATURES ................................................................................................................................. 3

BLOCK DIAGRAM FOR W83627F............................................................................................. 6

BLOCK DIAGRAM FOR W83627HF .......................................................................................... 7

PIN CONFIGURATION ............................................................................................................... 8

PIN DESCRIPTION................................................................................................................... 12

6.1

6.2

6.3

6.4

6.5

6.6

6.7

6.8

6.9

LPC Interface ............................................................................................................... 13

FDC Interface............................................................................................................... 14

Multi-Mode Parallel Port............................................................................................... 15

Serial Port Interface ..................................................................................................... 21

KBC Interface............................................................................................................... 22

ACPI Interface.............................................................................................................. 22

Hardware Monitor Interface ......................................................................................... 23

Game Port & MIDI Port ................................................................................................ 24

General Purpose I/O Port ............................................................................................ 25

6.9.1

6.9.2

6.9.3

General Purpose I/O Port 1

（Power

source is Vcc）....................................................25

General Purpose I/O Port 2

（Power

source is Vcc）....................................................25

General Purpose I/O Port 3

（Power

souce is VSB）....................................................26

6.10

7.1

7.2

POWER PINS .............................................................................................................. 26

General Description ..................................................................................................... 27

Access Interface........................................................................................................... 27

7.2.1

7.2.2

LPC interface..................................................................................................................27

C interface....................................................................................................................29

Monitor over 4.096V voltage： .......................................................................................32

Monitor negative voltage：.............................................................................................33

Temperature Measurement Machine..............................................................................34

Fan speed count.............................................................................................................35

Fan speed control...........................................................................................................37

Voltage SMI# mode： ....................................................................................................38

Fan SMI# mode： ..........................................................................................................38

Temperature 1 SMI# modes...........................................................................................39

Temperature 2, 3 SMI# modes： ...................................................................................40

HARDWARE MONITOR ........................................................................................................... 27

7.3

Analog Inputs ............................................................................................................... 32

7.3.1

7.3.2

7.3.3

7.4

FAN Speed Count and FAN Speed Control ................................................................ 35

7.4.1

7.4.2

7.5

SMI# interrupt mode..................................................................................................... 38

7.5.1

7.5.2

7.5.3

7.5.4

7.6

OVT# interrupt mode ................................................................................................... 41

- ii -

W83627HF/ F/ HG/ G

7.7

8.1

8.2

8.3

9.1

REGISTERS AND RAM............................................................................................... 42

Start Frame .................................................................................................................. 76

IRQ/Data Frame........................................................................................................... 76

Stop Frame .................................................................................................................. 77

Plug and Play Configuration ........................................................................................ 78

9.1.1

9.1.2

Compatible PnP..............................................................................................................78

Configuration Sequence .................................................................................................79

SERIAL IRQ .............................................................................................................................. 76

CONFIGURATION REGISTER ................................................................................................ 78

9.2

9.3

9.4

9.5

9.6

9.7

9.8

9.9

9.10

9.11

9.12

9.13

10.

10.1

10.2

11.

11.1

11.2

11.3

12.

13.

14.

15.

Chip（Global）Control Register .................................................................................. 81

Logical Device 0

（FDC）

........................................................................................... 87

Logical Device 1

（Parallel

Port）............................................................................... 91

Logical Device 2

（UART

A） ..................................................................................... 93

Logical Device 3

（UART

B） ..................................................................................... 94

Logical Device 5

（KBC）

........................................................................................... 96

Logical Device 6

（CIR）

............................................................................................ 97

Logical Device 7

（Game

Port, MIDI Port and GPIO Port 1）.................................... 97

Logical Device 8

（GPIO

Port 2 and Watch Dog Timer） ......................................... 98

Logical Device 9

（GPIO

Port 3, VSB powered）..................................................... 100

Logical Device A

（ACPI）........................................................................................

101

Logical Device B

（Hardware

Monitor） ................................................................... 108

Absolute Maximum Ratings ....................................................................................... 110

DC CHARACTERISTICS........................................................................................... 110

Parallel Port Extension FDD ...................................................................................... 118

Parallel Port Extension 2FDD .................................................................................... 118

Four FDD Mode ......................................................................................................... 119

SPECIFICATIONS .................................................................................................................. 110

APPLICATION CIRCUITS ...................................................................................................... 118

ORDERING INSTRUCTION ................................................................................................... 120

HOW TO READ THE TOP MARKING.................................................................................... 120

PACKAGE DIMENSIONS ....................................................................................................... 121

APPENDIX A

：

DEMO CIRCUIT .......................................................................................... 122

- iii -

Publication Release Date: June 09, 2006

Revision 2.27

W83627HF/ F/ HG/ G

1. GENERAL DESCRIPTION

The W83627HF and W83627F are evolving product from Winbond's most popular I/O family. They

feature a whole new interface, namely LPC（Low Pin Count）interface, which will be supported in the

next generation Intel chip-set. This interface as its name suggests is to provide an economical imple-

mentation of I/O's interface with lower pin count and still maintains equivalent performance as its ISA

interface counterpart. Approximately 40 pin counts are saved in LPC I/O comparing to ISA implemen-

tation. With this additional freedom, we can implement more devices on a single chip as demonstrated

in W83627F/HF's integration of Game Port and MIDI Port.It is fully transparent in terms of software

which means no BIOS or device driver update is needed except chip-specific configuration.

The disk drive adapter functions of W83627F/HF include a floppy disk drive controller compatible with

the industry standard 82077/ 765, data separator, write pre-compensation circuit, decode logic, data

rate selection, clock generator, drive interface control logic, and interrupt and DMA logic. The wide

range of functions integrated onto the W83627F/HF greatly reduces the number of components re-

quired for interfacing with floppy disk drives. The W83627F/HF supports four 360K, 720K, 1.2M,

1.44M, or 2.88M disk drives and data transfer rates of 250 Kb/s, 300 Kb/s, 500 Kb/s,1 Mb/s, and 2

Mb/s.

The W83627F/HF provides two high-speed serial communication ports（UARTs）, one of which sup-

ports serial Infrared communication. Each UART includes a 16-byte send/receive FIFO, a program-

mable baud rate generator, complete modem control capability, and a processor interrupt system.

Both UARTs provide legacy speed with baud rate up to 115.2k bps and also advanced speed with

baud rates of 230k, 460k, or 921k bps which support higher speed modems. In addition, the

W83627F/HF provides IR functions： IrDA 1.0

（SIR

for 1.152K bps）and TV remote IR

（Consumer

IR, supporting NEC, RC-5, extended RC-5, and RECS-80 protocols）.

The W83627F/HF supports one PC-compatible printer port

（

SPP

）

, Bi-directional Printer port

（BPP）

and also Enhanced Parallel Port

（EPP）

and Extended Capabilities Port（ECP）. Through

the printer port interface pins, also available are： Extension FDD Mode and Extension 2FDD Mode

allowing one or two external floppy disk drives to be connected.

The configuration registers support mode selection, function enable/disable, and power down function

selection. Furthermore, the configurable PnP features are compatible with the plug-and-play feature

demand of Windows 95/98 , which makes system resource allocation more efficient than ever.

The W83627F/HF provides functions that complies with ACPI

（Advanced

Configuration and Power

Interface

）

, which includes support of legacy and ACPI power management through PME# or

PSOUT# function pins. For OnNow keyboard Wake-Up, OnNow mouse Wake-Up, and OnNow CIR

Wake-Up. The W83627F/HF also has auto power management to reduce the power consumption.

The keyboard controller is based on 8042 compatible instruction set with a 2K Byte programmable

ROM and a 256-Byte RAM bank. Keyboard BIOS firmware are available with optional AMIKEY

Phoenix MultiKey/42

, or customer code.

The W83627F/HF provides a set of flexible I/O control functions to the system designer through a set

of General Purpose I/O ports. These GPIO ports may serve as simple I/O or may be individually con-

figured to provide a predefined alternate function. General Purpose Port 1 is designed to be functional

even in power down mode（VCC is off）.

The W83627F/HF is made to fully comply with Microsoft PC98 and PC99 Hardware Design Guide.

Moreover W83627F/HF is made to meet the specification of PC98/PC99's requirement in the power

management： ACPI and DPM

（Device

Power Management）.

Publication Release Date: June 09, 2006

Revision 2.27

-1-

W83627HG Related Products

	W83627HG	W83627G-AW	W83627HG-AW
Description	winbond lpc I/O	winbond lpc I/O	winbond lpc I/O
Is it Rohs certified?	-	conform to	conform to
Maker	-	Winbond Electronics Corporation	Winbond Electronics Corporation
Parts packaging code	-	QFP	QFP
package instruction	-	PLASTIC, QFP-128	FQFP, QFP128,.67X.93,20
Contacts	-	128	128
Reach Compliance Code	-	unknow	compliant
Address bus width	-	4	4
boundary scan	-	NO	NO
Bus compatibility	-	LPC	LPC
maximum clock frequency	-	48 MHz	48 MHz
External data bus width	-	4	4
JESD-30 code	-	R-PQFP-G128	R-PQFP-G128
JESD-609 code	-	e3	e3
length	-	20 mm	20 mm
Humidity sensitivity level	-	3	3
Number of I/O lines	-	30	30
Number of terminals	-	128	128
Maximum operating temperature	-	70 °C	70 °C
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	FQFP	FQFP
Encapsulate equivalent code	-	QFP128,.67X.93,20	QFP128,.67X.93,20
Package shape	-	RECTANGULAR	RECTANGULAR
Package form	-	FLATPACK, FINE PITCH	FLATPACK, FINE PITCH
Peak Reflow Temperature (Celsius)	-	260	260
power supply	-	5 V	5 V
Certification status	-	Not Qualified	Not Qualified
RAM (number of words)	-	256	256
Maximum seat height	-	3.32 mm	3.32 mm
Maximum supply voltage	-	5.5 V	5.5 V
Minimum supply voltage	-	4.5 V	4.5 V
Nominal supply voltage	-	5 V	5 V
surface mount	-	YES	YES
technology	-	CMOS	CMOS
Temperature level	-	COMMERCIAL	COMMERCIAL
Terminal surface	-	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	-	GULL WING	GULL WING
Terminal pitch	-	0.5 mm	0.5 mm
Terminal location	-	QUAD	QUAD
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED
width	-	14 mm	14 mm

Recommended Resources

PCF8591 hardware interface (circuit diagram pin diagram)

Electric bicycle odometer schematic diagram

Gas smoke detector circuit.gif

Stabilized power supply with overvoltage protection circuit diagram

Simple multiharmonic generator circuit

DMA input circuit

Realization of non-stop synchronous motion: [b]Introduction[/b] At present, motion controllers are increasingly used in industry, mainly involving the processing, assembly, and later assembly of some products, such as plastic molding machines (...; 锐特0087 Industrial Control Electronics

Software Design for CPU Card Programming: [backcolor=white][size=4][color=#000000] The data transmission mode of CPU card is different from that of memory card. It adopts serial asynchronous half-duplex mode. Therefore, when designing the rea...; Aguilera Microcontroller MCU

【MSP430 Sharing】 JTAG Simulation Downloader: The content of JTAG emulation downloader is more detailed than , you can download it if you need it...; hangsky Microcontroller MCU

Design of Phase Detection Broadband Frequency Measurement System Based on FPGA: In electronic measurement technology, frequency measurement is one of the most basic measurements. The commonly used frequency measurement method and period measurement method have great limitations i...; songrisi FPGA/CPLD

Can the UART and SPI in the F1491 USART module be used simultaneously?: Can the UART and SPI in the MSP430F1491 USART module be used simultaneously?...; tobycheng Microcontroller MCU

eZ430-Learning Experience (IV)-Official Routine Analysis: After intermittent time to understand the programming method and architecture of MSP430 , I have a certain foundation. Today I will analyze the official routines. There is a proverb that I will modify...; 0212009623 Microcontroller MCU

Shortcut: 00 01 02 03 04 05 06 07 08 09 0A 0C 0F 0J 0L 0M 0R 0S 0T 0Z 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 1H 1K 1M 1N 1P 1S 1T 1V 1X 1Z 20 21 22 23 24 25 26 27 28 29 2A 2B 2C 2D 2E 2F 2G 2K 2M 2N 2P 2Q 2R 2S 2T 2W 2Z 30 31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F 3G 3H 3J 3K 3L 3M 3N 3P 3R 3S 3T 3V 40 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4M 4N 4P 4S 4T 50 51 52 53 54 55 56 57 58 59 5A 5B 5C 5E 5G 5H 5K 5M 5N 5P 5S 5T 5V 60 61 62 63 64 65 66 67 68 69 6A 6C 6E 6F 6M 6N 6P 6R 6S 6T 70 71 72 73 74 75 76 77 78 79 7A 7B 7C 7M 7N 7P 7Q 7V 7W 7X 80 81 82 83 84 85 86 87 88 89 8A 8D 8E 8L 8N 8P 8S 8T 8W 8Y 8Z 90 91 92 93 94 95 96 97 98 99 9A 9B 9C 9D 9F 9G 9H 9L 9S 9T 9W

Popular Components
