PRELIMINARY DATA SHEET
NEC's 4-PIN SOP
LOW OFF-STATE LEAKAGE CURRENT
PS7200U-1A
1-ch OPTICAL COUPLED MOS FET
FEATURES
• LOW OFF-STATE LEAKAGE CURRENT:
I
Loff
= 0.1 nA TYP.
• BREAK DOWN VOLTAGE:
V
L
= 80 V
• HIGH-SPEED TURN-ON TIME:
t
on
= 0.05 ms TYP
• LOW OUTPUT CAPACITANCE:
C
out
= 2.3 pF TYP.
• C
×
R:
C
×
R = 40 pF •
Ω
• 1 CHANNEL TYPE:
1a Output
• DESIGNED FOR AC/DC SWITCHING LINE CHANGER
• SMALL AND THIN PACKAGE:
4-pin SOP, Height = 2.1 mm
• LOW OFFSET VOLTAGE
• ORDERING NUMBER OF TAPING PRODUCT:
PS7200U-1A-E3, E4, F3, F4
DESCRIPTION
NEC's PS7200U-1A is a low output capacitance solid state
relay containing GaAs LEDs on the light emitting side (input
side) and MOS FETs on the output side.
It is suitable for high-frequency signal control, due to
its extremely low off-state leakage current, low output
capacitance, and high-speed turn-on time.
APPLICATIONS
• Measurement Equipment
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
California Eastern Laboratories
1
PS7200U-1A
ORDERING INFORMATION
PART NUMBER
PS7200U-1A
PS7200U-1A-E3
PS7200U-1A-E4
PS7200U-1A-F3
PS7200U-1A-F4
PS7200U-1A
PS7200U-1A-E3
PS7200U-1A-E4
PS7200U-1A-F3
PS7200U-1A-F4
ORDER NUMBER
PS7200U-1A
PS7200U-1A-E3
PS7200U-1A-E4
PS7200U-1A-F3
PS7200U-1A-F4
PS7200U-1A-A
PS7200U-1A-E3-A
PS7200U-1A-E4-A
PS7200U-1A-F3-A
PS7200U-1A-F4-A
Embossed Tape 3 500 pcs/reel
Pb-Free
Magazine case 100 pcs
Embossed Tape 900 pcs/reel
Embossed Tape 3 500 pcs/reel
SOLDER PLATING
SPECIFICATION
Solder
contains lead
Magazine case 100 pcs
Embossed Tape 900 pcs/reel
PACKING STYLE
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Diode
Forward Current (DC)
Reverse Voltage
Power Dissipation
Peak Forward Current
*1
MOS FET
Break Down Voltage
Continuous Load Current
Pulse Load Current
*2
(AC/DC Connection)
Power Dissipation
Isolation Voltage
*3
Total Power Dissipation
Operating Ambient Temperature
Storage Temperature
P
D
BV
P
T
T
A
T
stg
SYMBOL
I
F
V
R
P
D
I
FP
V
L
I
L
I
LP
(T
A
= 25ºC, unless otherwise specified )
RATINGS
50
5.0
50
1
80
40
80
300
1 500
350
−40
to +85
−40
to +100
UNIT
mA
V
mW
A
V
mA
mA
mW
Vr.m.s.
mW
°C
°C
*1
PW = 100
μs,
Duty Cycle = 1%
*2
PW = 100 ms, 1 shot
*3
AC voltage for 1 minute at T
A
= 25
°C,
RH = 60% between input and output.
Pins 1-2 shorted together, 3-4 shorted together.
3
PS7200U-1A
RECOMMENDED OPERATING CONDITIONS
(T
A
= 25°C)
PARAMETER
LED Operating Current
LED Off Voltage
SYMBOL
I
F
V
F
MIN.
2
0
TYP.
10
MAX.
20
0.5
UNIT
mA
V
ELECTRICAL CHARACTERISTICS
PARAMETER
Diode
Forward Voltage
Reverse Current
MOS FET
Off-state Leakage Current
Output Capacitance
Coupled
LED On-state Current
On-state Resistance
Turn-on Time
*1
Turn-off Time
*1
Isolation Resistance
Isolation Capacitance
SYMBOL
V
F
I
R
I
Loff
C
out
I
Fon
R
on
t
on
t
off
R
I-O
C
I-O
(T
A
= 25ºC)
CONDITIONS
MIN.
TYP.
1.1
0.01
0.1
2.3
MAX.
1.3
5.0
1.0
3.5
2.0
17
0.05
0.15
10
9
0.3
25
0.5
0.5
Ω
pF
UNIT
V
μA
nA
pF
mA
Ω
ms
I
F
= 5 mA
V
R
= 5 V
V
D
= 80 V
V
D
= 0 V, f = 1 MHz
I
L
=
±40
mA
I
F
= 5 mA, I
L
=
±40
mA
I
F
= 5 mA, V
L
= 5 V, R
L
= 500
Ω,
PW
≥
0.5 ms
V
I-O
= 1.0 kV
DC
V = 0 V, f = 1 MHz
*1
Test Circuit for Switching Time
Pulse Input
I
F
V
L
Input
50%
0
Input monitor
R
in
R
L
V
O
monitor
V
O
= 5 V
Output
90%
10%
t
on
t
off
4
