HZC Series
Silicon Epitaxial Planar Zener Diode for Surge Absorb
ADE-208-1436A (Z)
Rev.1
Jan. 2002
Features
•
These diodes are delivered taped.
•
Ultra small Flat Package (UFP) is suitable for surface mount design.
Ordering Information
Type No.
HZC Series
Laser Mark
Let to Mark Code
Package Code
UFP
Pin Arrangement
Cathode mark
Mark
1
51
2
1. Cathode
2. Anode
HZC Series
Absolute Maximum Ratings
(Ta = 25°C)
Item
Power dissipation
Junction temperature
Storage temperature
Note:
1. See Fig2.
Symbol
Pd
*
Tj
Tstg
1
Value
150
150
–55 to +150
Unit
mW
°C
°C
Electrical Characteristics
(Ta = 25°C)
Zener voltage
V
Z
(V)
*
Type
HZC2.0
HZC2.2
HZC2.4
HZC2.7
HZC3.0
HZC3.3
HZC3.6
HZC3.9
HZC4.3
HZC4.7
HZC5.1
HZC5.6
HZC6.2
HZC6.8
HZC7.5
HZC8.2
HZC9.1
HZC10
HZC11
Min
1.90
2.10
2.30
2.50
2.80
3.10
3.40
3.70
4.01
4.42
4.84
5.31
5.86
6.47
7.06
7.76
8.56
9.45
10.44
1
Reverse current
Test
Condition
Dynamic resistance
Test
Condition
ESD-Capability
*
— (kV)
*
Min
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
2
2
I
R
(µA)
µ
Max
120.0
120.0
120.0
120.0
50.0
20.0
10.0
10.0
10.0
10.0
5.0
5.0
2.0
1.0
1.0
0.5
0.5
0.5
0.5
Test
Condition
r
d
(Ω)
Ω
Max
2.20
2.40
2.60
2.90
3.20
3.50
3.80
4.10
4.48
4.90
5.37
5.92
6.53
7.14
7.84
8.64
9.55
10.55
11.56
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
V
R
(V)
0.5
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.5
3.0
3.5
4.0
5.0
6.0
7.0
8.0
Max
100
100
100
110
120
130
130
130
130
130
130
80
50
30
30
30
30
30
30
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Notes: 1. Tested with pulse (Pw = 40 ms).
2. C =150 pF, R = 330
Ω,
Both forward and reverse direction 10 pulse
Failure criterion ; According to IR spec
Rev.1, Jan. 2002, page 2 of 6
HZC Series
Zener voltage
V
Z
(V)
*
Type
HZC12
HZC13
HZC15
HZC16
HZC18
HZC20
HZC22
HZC24
HZC27
HZC30
HZC33
HZC36
Min
11.42
12.47
13.84
15.37
16.94
18.86
20.88
22.93
25.10
28.00
31.00
34.00
1
Reverse current
Test
Condition
Dynamic resistance
Test
Condition
ESD-Capability
*
— (kV)
*
Min
30
30
30
30
30
30
30
30
30
30
25
20
2
2
I
R
(µA)
µ
Max
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Test
Condition
r
d
(Ω)
Ω
Max
12.60
13.96
15.52
17.09
19.03
21.08
23.17
25.57
28.90
32.00
35.00
38.00
I
Z
(mA)
5
5
5
5
5
5
5
5
2
2
2
2
V
R
(V)
9.0
10.0
11.0
12.0
13.0
15.0
17.0
19.0
21.0
23.0
25.0
27.0
Max
35
35
40
40
45
50
55
60
70
80
80
90
I
Z
(mA)
5
5
5
5
5
5
5
5
2
2
2
2
Notes: 1. Tested with pulse (Pw = 40 ms).
2. C =150 pF, R = 330
Ω,
Both forward and reverse direction 10 pulse
Failure criterion ; According to IR spec
Mark Code
Type
HZC2.0
HZC2.2
HZC2.4
HZC2.7
HZC3.0
HZC3.3
HZC3.6
HZC3.9
HZC4.3
HZC4.7
HZC5.1
Note:
Mark No.
20
22
24
27
30
33
36
39
43
47
51
1. HZC10 To HZC36 has
s,
on the right of Laser Mark.
Type
HZC5.6
HZC6.2
HZC6.8
HZC7.5
HZC8.2
HZC9.1
HZC10
HZC11
HZC12
HZC13
Mark No.
56
62
68
75
82
91
10
*
11
*
12
*
13
*
Type
HZC15
HZC16
HZC18
HZC20
HZC22
HZC24
HZC27
HZC30
HZC33
HZC36
Mark No.
15
*
16
*
18
*
20
*
22
*
24
*
27
*
30
*
33
*
36
*
Rev.1, Jan. 2002, page 3 of 6
HZC Series
Main Characteristic
HZC2.4
HZC3.0
HZC3.6
HZC4.3
HZC5.1
HZC6.2
HZC7.5
HZC8.2
HZC9.1
HZC10
HZC11
HZC13
HZC16
10
8
Zener Current I
Z
(mA)
6
HZC2.0
HZC18
HZC15
HZC20
HZC22
HZC30
HZC24
HZC33
4
0
0
4
HZC6.8
2
8
HZC12
12
16
20
24
HZC27
28
32
36
HZC36
40
Zener Voltage V
Z
(V)
Fig.1 Zener current vs. Zener voltage
Zener Voltage Temperature Coefficient
γ
Z
(mV/°C)
Zener Voltage Temperature Coefficient
γ
Z
(%/°C)
0.10
0.09
0.08
0.07
0.06
0.05
0.04
0.03
0.02
0.01
0
−0.01
−0.02
−0.03
−0.04
−0.05
−0.06
0
250
Polyimide board
20h×15w×0.8t
%/°C
mV/°C
40
35
30
25
20
15
10
5
0
−5
−10
−15
−20
−25
Power Dissipation Pd (mW)
200
3.0
1.5
150
1.5
unit: mm
100
50
5 10 15 20 25 30 35 40 45
Zener Voltage V
Z
(V)
0
0
50
100
150
Ambient Temperature Ta (°C)
Fig.2 Power Dissipation vs. Ambient Temperature
Fig.2 Temperature Coefficient vs. Zener voltage
Rev.1, Jan. 2002, page 4 of 6
0.8
200
HZC Series
Package Dimensions
As of July, 2001
Unit: mm
1.2 ± 0.10
1.6 ± 0.10
0.13 ± 0.05
0.6 ± 0.10
0.3 ± 0.05
0.8 ± 0.10
Hitachi Code
JEDEC
JEITA
Mass (reference value)
UFP
—
Conforms
0.0016 g
Rev.1, Jan. 2002, page 5 of 6
