Date:
8-18-09
Ref.#:
TW-700180
9mm Snap-In Audio Potentiometer
317-2080F-1K, 317-2080F-2K, 317-2080F-5K,
317-2080F-10K, 317-2080F-50K, 317-2080F-100K,
317-2080F-500K,317-2080F-1M
20±0.5
(.787±.02)
7.0
(.276)
C0.5 (.02)
ø6.0±
0
0.1
0
(.236±
.004
)
2.0
(.679)
40 Teeth
1
3.5 (.138)
6.8
(.268)
9.8
(.386)
40∞
Shaft shown in full
C.C.W. position
5.5
(.217)
3
2
7.0
(.276)
3.8 (.15)
3 - 0.8
(.031)
0.8 (.031)
11.4
(.449)
5.0
(.197)
100
Term. 1-2 Output Voltage
x100%
Term. 1-3 Input Voltage
10.6
(.417)
2 - 1.8±
0.2
0
(.071±
0.008
)
0
2 - 2.2±
0.2
0
(.083±
0.008
)
0
7.0
(.276)
90
80
70
60
50
40
30
20
10
0
Standard Resistance Taper
15A Taper (JIS A)
3 - ø1.0±
0.2
0
(.039±
0.008
)
0
5.0
(.197)
P.C.B. Mounting Hole Detail
10 20 30 40 50 60 70 80 90 100
Term "3"
Term "1" Rotation Travel (%)
Dimensions mm (in.)
Specifications:
•
Value (Ω): 1K, 2K, 5K, 10K, 50K, 100K, 500K, 1M
•
Mechanical Characteristics:
Total rotational angle: 280°±5°
Rotational torque: 10~100gf
Shaft stop strength: 3 kgf
Starting torque: 10~100gf-cm
•
Electrical Characteristics:
Tolerance: ±30%
Rated wattage: 0.05W
•
Electrical Characteristics:
Maximum working voltage: AC 50V, DC20V
Noise (refer to JIS C6443): > 100 mV
Insulation resistance: 100MΩ min. @ DC250 volts
Taper: Audio
V.R. life: 10,000 Cycles
Click life: 5,000 Cycles
Note: Meet or exceed JISC 6443 Requirements
•
RoHS Compliant
Available from Mouser Electronics
www.mouser.com
(800) 346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
