54002215: DescriptionAutomotive connectorfemale 1.5mm term 22 awg tin; CategoryThe connector; File Size261KB，2 Pages; ManufacturerFCI [First Components International]

Download Datasheet Parametric View All

54002215 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	54002215	-	-	View	Buy Now

54002215 Overview

Automotive connectorfemale 1.5mm term 22 awg tin

54002215 Parametric

Parameter Name	Attribute value
Maker	FCI [First Components International]
Product Category	automotive connector
series connection	APEX 150 Series
product	Terminals
Number of locations	1
Type	Female
Contact plating	Ti
Contact material	Copper Alloy
Contact type	Terminal
drawing	h
series	APEX
Installation style	Wire
Number of locations/contacts	1
Number of rows	1
Pitch	3.5 mm
Termination type	Crim
Minimum wire gauge (AWG)	22
Wire diameter (AWG)	22

Preview

Download Datasheet

View All

Terminal Systems

Apex

1.5 mm female and male terminals

Features

•

APEX technology

•

High current carrying capacity

•

4.0 mm pitch single wire seal 3.5 mm

pitch mat-seal or unsealed

•

Design compatible with a large

range of connector sealing

technologies (single wire sealing,

mat-seal)

•

Suitable for secondary lock

•

Selective gold-plated versions

available on male terminals

a. 7.0 mm length for coupling (in-

line) applications

b. 11.1 mm length for shorting bar

applications

•

180° terminal orientation

Performance characteristics

•

Contact resistance:

•

Contact mating force:

< 0.5 mΩ

<5N

Tooling

•

Current carrying capacity

at 23°C up to approx.:

at 85°C up to approx.:

at 100°C up to approx.:

at 125°C up to approx.:

•

Manual crimping tool:

Consult us

•

Mini applicator:

•

Contact unmating force: < 1 N

Part Numbers

Type

Wire size range

(in AWG)

Min.

Max.

Insulation Ø

(in mm)

Max.

Material

Plating

54002214 (SWS)

54001826 (SWS)

54001417 (SWS)

54002215

54001823

54001414

54002226 (SWS)

54001837 (SWS)

54001428 (SWS)

54002220

54001831

54001422

54002232

54001841

54001433

54002233 (SWS)

54001842 (SWS)

54001434 (SWS)

Female

Male

1.75

2.13

2.77

1.75

2.13

2.77

1.75

2.13

2.77

1.75

2.13

2.77

1.75

1.93

2.41

1.75

1.93

2.41

CuFeP/CuBe

CuFeP

SWS: Single Wire Seal

1.23

Rev 01/04
