Part Number:
Status:
Overview:
Description:
0855055013
Obsolete
modular_plugs_jacks
Modular Jack, Right Angle, Low Profile, Fully Shielded, 8/8, Cat5e, Through Hole,
Version A, Tape and Reel
Documents:
Drawing (PDF)
Agency Certification
UL
E107635
Series
image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Halogen-Free
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
General
Product Family
Series
Comments
Component Type
Magnetic
Overview
Performance Category
Power over Ethernet (PoE)
Product Name
Modular Jacks/Plugs
85505
External Shield
PCB Jack
No
modular_plugs_jacks
5e
N/A
RJ45
Physical
Color - Resin
Durability (mating cycles max)
Flammability
Inverted / Top Latch
Lightpipes/LEDs
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Plating min - Mating
Plating min - Termination
Ports
Positions / Loaded Contacts
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
Wire/Cable Type
Black
500
94V-0
No
None
Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
Right Angle (Side Entry)
Yes
Yes
1.57mm (.062")
Embossed Tape on Reel
0.040 In
1.02 mm
0.050 In
1.27 mm
1.270µm (50µ")
1.905µm (75µ")
1
8/8
No
-40°C to +80°C
Through Hole
No
N/A
Search Parts in this Series
85505Series
Mates With
FCC 68 Plugs
Electrical
Current - Maximum per Contact
Shielded
Voltage - Maximum
1.5A
Yes
125V
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
45
Wave Capable (TH only)
1
260
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-85505-101
SD-85505-106
