Part Number

Search

PNA3602L

Description
PIN Photodiode
CategoryLED optoelectronic/LED    photoelectric
File Size28KB,2 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Download Datasheet Parametric View All

PNA3602L Overview

PIN Photodiode

PNA3602L Parametric

Parameter NameAttribute value
MakerPanasonic
package instructionROHS COMPLIANT PACKAGE-2
Reach Compliance Codeunknow
Other featuresSIDE VIEW
ConfigurationSINGLE
Maximum dark power10 nA
Infrared rangeYES
Nominal photocurrent0.016 mA
Installation featuresTHROUGH HOLE MOUNT
Number of functions1
Maximum operating temperature85 °C
Minimum operating temperature-25 °C
Optoelectronic device typesPIN PHOTODIODE
peak wavelength850 nm
Minimum reverse breakdown voltage30 V
Maximum reverse voltage30 V
shapeROUND
size2.4 mm
surface mountNO
PIN Photodiodes
PNA3602L
PIN Photodiode
Unit : mm
For optical control systems
4.5±0.3
1.2
Not soldered
2.9±0.25
ø2.4
3.9±0.3
2.4 1.5
Features
High quantum efficiency
High-speed response
Small size, thin side-view type package
12.8 min.
0.9
1.7±0.2
0.8
2.8
2-1.2±0.3
2-0.45±0.15
1
2.54
2
0.45±0.15
R1.2
R0.6
Absolute Maximum Ratings
(Ta = 25˚C)
Parameter
Reverse voltage (DC)
Power dissipation
Operating ambient temperature
Storage temperature
Symbol
V
R
P
D
T
opr
T
stg
Ratings
30
100
–25 to +85
–30 to +100
Unit
V
mW
˚C
˚C
1: Anode
2: Cathode
Electro-Optical Characteristics
(Ta = 25˚C)
Parameter
Dark current
Photo current
Peak sensitivity wavelength
Response time
Capacitance between pins
Acceptance half angle
*1
Symbol
I
D
I
L
λ
P
t
r
, t
f*2
C
t
θ
V
R
= 10V
Conditions
V
R
= 10V, L = 1000 lx
*1
V
R
= 10V
V
R
= 10V, R
L
= 50Ω
V
R
= 10V, f = 1MHz
Measured from the optical axis to the half power point
min
16
typ
0.1
850
2
6
45
max
10
Unit
nA
µA
nm
ns
pF
deg.
Measurements were made using a tungsten lamp (color temperature T = 2856K) as a light source.
*2
Switching time measurement circuit
Sig.IN
λ
P
= 800nm
50Ω
R
L
V
R
= 10V
(Input pulse)
Sig.OUT
(Output pulse)
t
d
t
r
t
f
90%
10%
t
d
: Delay time
t
r
: Rise time (Time required for the collector photo current
to increase from 10% to 90% of its final value)
t
f
: Fall time (Time required for the collector photo current
to decrease from 90% to 10% of its initial value)
,,,
,
,,,
,
1
