Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2006-03-24
749023010
A
Mechanische Abmessungen / dimensions :
A
B
C
D
B
1000 BaseT
17,80 ± 0,25
6,50 max.
16,00 ± 0,25
12,20 ± 0,25
mm
mm
mm
mm
A
WE
D
P/N
YYWW
= Pin 1
B
Elektrische Eigenschaften / electrical properties :
Eigenschaften /
properties
Indukivität /
Inductance
Übersetzungsverhältnis
/ Turns ratio
C
C
Lötpad / soldering spec. :
Wert / value
Einheit / unit
tol.
min.
3%
11 x 1,27
24 x 0,76
12,70
13,97
Version 2
Version 1
Änderung / modification
16,51
Testbedingungen /
test conditions
100kHz / 100mV @ 8mA DC-
Bias
100kHz / 100mV
0,1MHz
100MHz
125MHz
30MHz @ 100
60MHz @ 100
80MHz @ 100
100MHz @ 100
30MHz
60MHz
100MHz
OCL
TR
350
1:1
1:1
µH
Tx
Rx
Insertion Loss
IL
Return Loss
RL
Crosstalk
DCMR
-1.1
-1.0
-2.0
-18
-12
-12
-10
-43
-37
-33
dB
max.
dB
min.
dB
min.
D
Prüfgeräte / test equipment :
HP4395A
E
Testbedingungen / test conditions :
Luftfeuchtigkeit / humidity:
Umgebungstemperatur / temperature:
33%
+25°
C
F
Werkstoffe & Zulassungen / material & approvals :
Basismaterial / base material:
Draht / wire:
Kontaktmaterial/ contact plating
Gehäuse / case
Verguss / potting
Ferrit/ ferrite
4UEW 155°
C
Cu-Ni-Sn
UL94-V0
UL94-V0
G
Eigenschaften / general specifications :
Betriebstemp. / operating temperature: 0° - + 70°
C
C
Hochspannungsprüfung / Hipot test: 1500Vrms 1min.
geeignet für 1000BaseT-Anwendungen gemäß IEEE 802.3ab /
Compliant with IEEE 802.3ab for 1000BaseT
geeignet für Power over Ethernet-Anwendungen /
suitable for Power over Ethernet applications
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
TBr
2006-03-24
2006-01-31
...............................................
..................................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 1 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2006-03-24
749023010
H
Schaltbild / Schematics :
TD1+
2
23
MX1+
TCT1
1
24
MCT1
TD1-
TD2+
3
5
22
20
MX1-
MX2+
TCT2
4
21
MCT2
TD2-
TD3+
6
8
19
17
MX2-
MX3+
TCT3
7
18
MCT3
TD3-
9
16
14
MX3-
MX4+
TD4+ 11
TCT4 10
15
MCT4
TD4- 12
13
MX4-
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
TBr
Version 2
Version 1
Änderung / modification
2006-03-24
2006-01-31
...............................................
..................................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 2 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2006-03-24
749023010
I
Rollenspezifikation / tape and reel specification :
øC
D
E
Gurtspezifikation / Tape specification:
A
B
B1
B2
C
B1 B
B2
16,5
44,0
40,4
20,2
1,50
4,00
2,00
1,50
1,70
24,0
6,5
18,5
± 0,1
± 0,3
± 0,1
± 0,1
+ 0,1
- 0,0
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
F
A
G
H
K
D
E
F
G
H
I
K
+ 0,1
- 0,0
+ 0,15
- 0,05
± 0,1
± 0,1
± 0,1
± 0,1
± 0,1
I
a
b
d
Rollenspezifikation / Reel specification:
a
330,0 ± 2,0
mm
b
21,00 ± 0,8
mm
c
13,50 ± 0,5
mm
d
100,0 ± 1,0
mm
Øc
165 to 180°
The force for tearing off cover tape is
10 to 130 grams in arrow direction
feeding direction
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
TBr
Version 2
Version 1
Änderung / modification
2006-03-24
2006-01-31
...............................................
..................................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
This electronic component has been designed and developed for usage in general electronic equipment. Before incorporating this component into any equipment where higher safety and reliability is especially required or if
there is the possibility of direct damage or injury to human body, for example in the range of aerospace, aviation, nuclear control, submarine, transportation, (automotive control, train control, ship control), transportation signal,
disaster prevention, medical, public information network etc, Würth Elektronik eiSos GmbH must be informed before the design-in stage. In addition, sufficient reliability evaluation checks for safety must be performed on every
electronic component which is used in electrical circuits that require high safety and reliability functions or performance.
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 3 VON 3
