PMB2304R Overview

PLL-FREQUENCY SYNTHESIZER

PMB2304R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Infineon
Parts packaging code	TSSOP
package instruction	TSSOP, TSSOP16,.25
Contacts	16
Reach Compliance Code	compli
Analog Integrated Circuits - Other Types	PLL FREQUENCY SYNTHESIZER
JESD-30 code	R-PDSO-G16
length	5 mm
Humidity sensitivity level	3
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Encapsulate equivalent code	TSSOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
power supply	3/5 V
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2.7 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
width	4.4 mm

Preview

Download Datasheet

View All

Wireless Components

PLL-Frequency Synthesizer

PMB 2304R Version 2.1

Specification June 2002

preliminary

Table of Contents

2.1

2.2

2.3

2.4

3.1

3.2

3.3

3.4

3.5

3.6

4.1

4.2

4.3

5.1

5.1.1

5.1.2

5.1.3

5.1.4

5.2

5.3

5.4

5.5

5.6

5.7

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Product Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Package Outlines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Functional Description.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Pin Definition and Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Functional Block Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Data acquisition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

Applications

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

PCB Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Application Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Bill of material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Reference

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Electrical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Absolute Maximum Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Operating Ratings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Typical Supply Current I

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

AC/DC Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Phase detector outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Serial Control Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8

Programming Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10

Pulse Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11

Serial Control Data Input Timing. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12

Diagram Input Sensitivity FI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
