GSM LO1 VCO
PMB 2100
Version 1.1
Product Info
General Description
s
The PMB 2100 is a VCO designed to
be used as L01 in Dualband GSM
applications with Infineon´s SMARTi /
SMARTi+ chipset.
P-TSSOP-10-1
Features
s
s
s
Fully integrated, monolithic solution
Very small outline and low profile
P-TSSOP10 package
Balanced outputs
s
s
s
Power down function
Supply voltage range from 2.65 - 2.95V
-20°C to +75°C operational
temperature range
Application
s
L01 for GSM transceiver SMARTi/
SMARTi+
Type
PMB 2100
Specification
Ordering Code
Q67034-H0003
5
Package
P-TSSOP-10
2001-07-30
