Contact our sales representatives before you use our products for applications including
automotives, medical equipment and aerospace equipment. Malfunction or failure of the
products in such applications may cause loss of human life or serious damage .
Cn
PRODUCT
CODE
1J
STYLE
1H, 1E, 1F
1J, 2B
4
MARKING
FOR 1F8
'Blank': Marking
N: No Marking
NUMBER OF
RESISTORS
2, 4, 8
K
TERMINATION
STYLE
K: convex, square corners
A: convex scalloped corners
N: flat type, square corners
T
TERMINATION
SURFACE MATERIAL
T: Sn
(L: Sn/Pb)
TD
TAPING*
TD, TE, BK
*Please see “PACKAGING”
101
NOMINAL
RESISTANCE
F: 4 digits
J: 3 digits
J
TOLERANCE
F: (±1%)
J: (±5%)
Contact us when you
have control request
for environmental
hazardous material other
than the substance
specified by EU-RoHS
DIMEnSIOnS (mm)
SIZE
0302 (2 x 02015)
0602 (4 x 02015)
0404 (2 x 0402)
0804 (4 x 0402)
1506 (8 x 0602)
0606 (2 x 0603)
1206 (4 x 0603)
1206 (4 x 0603)
2012 (4 x 1206)
NEW
TYPE
Cn 1H 2 n
Cn 1H 4 n
Cn 1E 2 K
Cn 1E 4 K
Cn 1F (n) 8 K
Cn 1J 2 K
Cn 1J 4 a
Cn 1J 4 K
Cn 2B 4 a
0.8
1.4
1.0
2.0
3.8
1.6
3.2
3.2
5.1
L
± 0.1
± 0.1
± 0.1
± 0.1
± 0.1
± 0.15
± 0.15
± 0.15
± 0.2
0.6
0.6
1.0
1.0
1.6
1.6
1.6
1.6
3.1
W
± 0.1
± 0.08
± 0.1
± 0.1
± 0.1
± 0.15
± 0.15
± 0.15
± 0.2
c
d
t ±0.1
0.35
0.35
0.35
0.35
0.45
0.5
0.5
0.5
0.55
a
b
P (ref.)
(0.5)
(0.4)
(0.65)
(0.5)
(0.5)
(0.8)
(0.8)
(0.8)
(1.27)
0.15 ± 0.1
0.15 ± 0.1
0.1 ± 0.08 0.2 ± 0.08
0.15 ± 0.1
0.25 ± 0.1
0.15 ± 0.1
0.25 ± 0.2
0.3 ± 0.1
0.3 ± 0.1
0.3 ± 0.2
0.25 ± 0.1
0.3 ± 0.2
0.25 ± 0.1
0.3 ± 0.2
0.25 ± 0.1
0.5 ± 0.2
0.35 ± 0.15
CN1H2N
CN1E2K
CN1J2K
0.3 ± 0.1
0.2 ± 0.1
0.33 ± 0.1
0.17 ± 0.05
0.3 ± 0.15
0.15 ± 0.1
0.3 ± 0.1 (0.15)
0.6 ± 0.15
0.3 ± 0.1
0.5 ± 0.15
0.3 ± 0.1
0.5 ± 0.15
0.3 ± 0.1
0.8 ± 0.2
0.45 ± 0.1
CN1F8K
CN1FN8K
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order/or use.
■
2, 4 or 8 isolated resistor elements included in one array
■
Less board space than individual chip resistors
■
High cost reduction efficiency by eliminating mounter operations
■
Square corner design (CN-K) or scalloped corner design (CN-A)
■
Precision type ±1% is available
■ CN1J4K parts are tested according to AEC-Q200 requirements
■
Meets or exceeds IEC 60115-1, JIS C 5201-1
■
Rated ambient temperature: +70°C
■
Operating temperature range: -55°C ... +125°C (+155°C on request)
■
Suitable as pull-up/pull-down resistors for digital circuits
■
Suitable for reflow soldering
FEaTURES
CIRCUIT COnSTRUCTIOn
CN1H4N
CN1E4K,CN1J4A
CN1J4K, CN2B4A
R
1
=R
2
MaX.
WORKIng
VOLTagE
12.5 V
R
1
=R
2
=R
3
=R
4
MaX.
OVERLOaD
VOLTagE
25 V
R
1
=R
2
=R
3
=R
4
=R
5
=R
6
=R
7
=R
8
RESISTanCE RangE
RaTIng
SIZE
TYPE
T.C.R.
(ppm/K)
POWER*
RaTIng
(per element)
0.031 W
F(±1%) E24 • E96
–
J(±5%) E24
0302 (2 x 02015)
Cn 1H 2 n
NEW
0602 (4 x 02015)
Cn 1H 4 n
0404 (2 x 0402)
Cn 1E 2 K
0804 (4 x 0402)
Cn 1E 4 K
±200: R610 Ω
1506 (8 x 0602)
Cn 1F (n) 8 K
±400: R
!
10 Ω
0606 (2 x 0603)
Cn 1J 2 K
1206 (4 x 0603)
Cn 1J 4 a
1206 (4 x 0603)
Cn 1J 4 K
2012 (4 x 1206)
Cn 2B 4 a
0.063 W**
0.125 W
25 V
50 V
10 Ω … 100 kΩ
10 Ω … 1 MΩ
50 V
200 V
100 V
400 V
10 Ω … 1 MΩ
–
1 Ω … 1 MΩ
10 Ω … 1 MΩ
* For resistors operated at an ambient temperature of +70°C or above, the power rating shall be derated.
** CN1F8K: max. 0.25 W/Package.
Please note that network resistors generate higher heat rather than single flat chip resistors even under rated power output.
A few cross talks will occur in network resistors. In case of using them for a high frequency circuit, please design circuits taking the effect by the cross talks into consideration.
Rated voltage = Power rating x resistance value or max. working voltage, whichever is lower.
