Minibox Metallized Polyester
Film Capacitors
F
EATURES
•
•
•
•
•
•
Miniature size
Self-healing properties
High moisture resistance
Good solderability
Non-inductive construction
Flame-retardant plastic case and epoxy resin
(In compliance with UL94V-0)
EPEM
(5mm Lead Space)
Series
MERITEK
S
PECIFICATIONS
1. Operating temperature:
2. Capacitance range:
3. Capacitance tolerance:
4. Rated voltage:
5. Dissipation factor:
6. Insulation resistance:
-40
o
C to +85
o
C
0.001μF to 1.5μF
±5%(J), ±10%(K), ±20%(M)
63VDC/50VAC, 100VDC/63VAC
≤
0.8% at 1 KHz and 20
o
C
≥
9000MΩ for C
≤
0.33μF
≥3000M Ω μF
for C > 0.33μF
EPEM
are constructed with a wound polyethylene
terephthalate film dielectric, housed inside a plastic casing,
which is sealed using epoxy resin. The leads are
constructed with oxygen-free tinned copper wires. EPEM
possess self -healing properties and are small in size. They
are ideal for automatic insertion.
J
2A
P
ART
N
UMBERING
S
YSTEM
Meritek Series
Capacitance
CODE
( pF )
( nF )
(
μF
)
102
1,000
1
0.001
103
10,000
10
0.01
104
100,000
100
0.1
105
1000
1
EPEM
103
W 0.1
Tolerance
CODE
Tolerance (%)
J
±5
K
± 10
M
± 20
d
0.6
Rated Voltage
CODE
1J
63VDC
2A
100VDC
Tape & Reel
/
Tape & Ammo available
Please contact factory for part number
Dimensions in millimeters (mm)
RV
DIM.
CAP(
μ
F)
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
63VDC/ 50VAC
W
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
H
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
T
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
P
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
W
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
100VDC/ 63VAC
H
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
T
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
P
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
rev.6a
Specifications are
subject to change without notice.
Minibox Metallized Polyester
Film Capacitors
EPEM
(5mm Lead Space)
Series
MERITEK
Dimensions in millimeters (mm)
RV
DIM.
CAP(
μ
F)
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
63VDC/ 50VAC
W
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
H
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5/8.0
6.5/8.0
6.5/8.0
6.5/8.0
8.0
8.0
8.0
8.0
8.0
8.0/9.6
8.0/9.6
8.0/9.6
T
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5/3.2
2.5/3.2
2.5/3.2
2.5/3.2
3.2/5.0
3.2/5.0
5.0
5.0
5.0
5.0/6.0
5.0/6.0
5.0/6.0
P
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
W
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
7.6
100VDC/ 63VAC
H
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5
6.5/8.0
6.5/8.0
8.0
8.0
8.0
8.0
8.0/12.0
9.6/12.0
9.6/12.0
9.6/12.0
12.0
12.0
T
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5/3.2
2.5/3.2
5.0
5.0
5.0
5.0
5.0/6.0
6.0
6.0
6.0
6.0
6.0
P
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Custom values and tolerances available upon request
