59C11E/SM: Description128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.207 INCH, PLASTIC, SOIC-8; Categorystorage storage; File Size132KB，8 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com

Download Datasheet Parametric Compare View All

59C11E/SM Overview

128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.207 INCH, PLASTIC, SOIC-8

59C11E/SM Parametric

Parameter Name	Attribute value
Parts packaging code	SOIC
package instruction	0.207 INCH, PLASTIC, SOIC-8
Contacts	8
Reach Compliance Code	unknow
Spare memory width	16
Maximum clock frequency (fCLK)	1 MHz
JESD-30 code	R-PDSO-G8
length	5.28 mm
memory density	1024 bi
Memory IC Type	EEPROM
memory width	8
Number of functions	1
Number of terminals	8
word count	128 words
character code	128
Operating mode	SYNCHRONOUS
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
organize	128X8
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Parallel/Serial	SERIAL
Certification status	Not Qualified
Maximum seat height	2.03 mm
Serial bus type	4-WIRE
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	5.2 mm
Maximum write cycle time (tWC)	1 ms
Base Number Matches	1

Preview

Download Datasheet

View All

59C11

1K 5.0V CMOS Serial EEPROM

FEATURES

• Low power CMOS technology

• Pin selectable memory organization

- 128 x 8 or 64 x 16 bit organization

• Single 5 volt only operation

• Self timed WRITE, ERAL and WRAL cycles

• Automatic erase before WRITE

• RDY/BSY status information during WRITE

• Power on/off data protection circuitry

• 1,000,000 ERASE/WRITE cycles guaranteed

• Data Retention > 200 Years

• 8-pin DIP or SOIC package

• Available for extended temperature ranges:

- Commercial: 0˚C to +70˚C

- Industrial: -40˚C to +85˚C

- Automotive: -40˚C to +125˚C

PACKAGE TYPE

DIP

CLK

RDY/BSY

ORG

59C11

SOIC

CLK

RDY/BSY

ORG

DESCRIPTION

59C11

The Microchip Technology Inc. 59C11 is a 1K bit Elec-

trically Erasable PROM. The device is conﬁgured as

128 x 8 or 64 x 16, selectable externally by means of

the control pin ORG. Advanced CMOS technology

makes this device ideal for low power nonvolatile mem-

ory applications. The 59C11 is available in the stan-

dard 8-pin DIP and a surface mount SOIC package.

BLOCK DIAGRAM

ORG

MEMORY

ARRAY

128 x 8 or

64 x 16

ADDRESS

DECODER

DATA REGISTER

MODE

DECODE

LOGIC

OUTPUT

BUFFER

RDY/BSY

CLK

CLOCK

GENERATOR

1995 Microchip Technology Inc.

DS20040I-page 1

59C11E/SM Related Products

	59C11E/SM	59C11/SM	59C11/SN	59C11E/SN	59C11I/SM	59C11I/SN	59C11E/P	59C11I/P
Description	128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.207 INCH, PLASTIC, SOIC-8	64 X 16 4-WIRE SERIAL EEPROM, PDSO8, 0.207 INCH, PLASTIC, SOIC-8	64 X 16 4-WIRE SERIAL EEPROM, PDSO8, 0.150 INCH, PLASTIC, SOIC-8	128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.150 INCH, PLASTIC, SOIC-8	128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.207 INCH, PLASTIC, SOIC-8	128 X 8 4-WIRE SERIAL EEPROM, PDSO8, 0.150 INCH, PLASTIC, SOIC-8	128 X 8 4-WIRE SERIAL EEPROM, PDIP8, 0.300 INCH, PLASTIC, DIP-8	128 X 8 4-WIRE SERIAL EEPROM, PDIP8, 0.300 INCH, PLASTIC, DIP-8
Parts packaging code	SOIC	SOIC	SOIC	SOIC	SOIC	SOIC	DIP	DIP
package instruction	0.207 INCH, PLASTIC, SOIC-8	0.207 INCH, PLASTIC, SOIC-8	0.150 INCH, PLASTIC, SOIC-8	SOP,	SOP,	SOP,	0.300 INCH, PLASTIC, DIP-8	0.300 INCH, PLASTIC, DIP-8
Contacts	8	8	8	8	8	8	8	8
Reach Compliance Code	unknow	_compli	compliant	unknown	unknown	compliant	unknown	compliant
Spare memory width	16	8	8	16	16	16	16	16
Maximum clock frequency (fCLK)	1 MHz	1 MHz	1 MHz	1 MHz	1 MHz	1 MHz	1 MHz	1 MHz
JESD-30 code	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDSO-G8	R-PDIP-T8	R-PDIP-T8
length	5.28 mm	5.28 mm	4.9 mm	4.9 mm	5.28 mm	4.9 mm	9.9695 mm	9.9695 mm
memory density	1024 bi	1024 bi	1024 bit	1024 bit	1024 bit	1024 bit	1024 bit	1024 bit
Memory IC Type	EEPROM	EEPROM	EEPROM	EEPROM	EEPROM	EEPROM	EEPROM	EEPROM
memory width	8	16	16	8	8	8	8	8
Number of functions	1	1	1	1	1	1	1	1
Number of terminals	8	8	8	8	8	8	8	8
word count	128 words	64 words	64 words	128 words	128 words	128 words	128 words	128 words
character code	128	64	64	128	128	128	128	128
Operating mode	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS
Maximum operating temperature	125 °C	70 °C	70 °C	125 °C	85 °C	85 °C	125 °C	85 °C
Minimum operating temperature	-40 °C	-	-	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
organize	128X8	64X16	64X16	128X8	128X8	128X8	128X8	128X8
Output characteristics	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE	3-STATE
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	SOP	SOP	SOP	SOP	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	IN-LINE
Parallel/Serial	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL	SERIAL
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	2.03 mm	2.03 mm	1.75 mm	1.75 mm	2.03 mm	1.75 mm	4.064 mm	4.064 mm
Serial bus type	4-WIRE	4-WIRE	4-WIRE	4-WIRE	4-WIRE	4-WIRE	4-WIRE	4-WIRE
Maximum supply voltage (Vsup)	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	YES	YES	NO	NO
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	AUTOMOTIVE	COMMERCIAL	COMMERCIAL	AUTOMOTIVE	INDUSTRIAL	INDUSTRIAL	AUTOMOTIVE	INDUSTRIAL
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	5.2 mm	5.2 mm	3.9 mm	3.9 mm	5.2 mm	3.9 mm	7.62 mm	7.62 mm
Maximum write cycle time (tWC)	1 ms	15 ms	15 ms	1 ms	1 ms	1 ms	1 ms	1 ms
Base Number Matches	1	1	1	1	1	1	1	1
