2-1622820-3: DescriptionRESISTOR, METAL GLAZE/THICK FILM, 1W, 5%, 200ppm, 20000ohm, SURFACE MOUNT, 2512, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size123KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

2-1622820-3 Overview

RESISTOR, METAL GLAZE/THICK FILM, 1W, 5%, 200ppm, 20000ohm, SURFACE MOUNT, 2512, CHIP, ROHS COMPLIANT

2-1622820-3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1645686738
package instruction	, 2512
Reach Compliance Code	unknown
ECCN code	EAR99
Manufacturer's serial number	3520
Installation features	SURFACE MOUNT
Number of terminals	2
Package shape	RECTANGULAR PACKAGE
method of packing	TR
Rated power dissipation(P)	1 W
resistance	20000 Ω
Resistor type	FIXED RESISTOR
size code	2512
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	200 ppm/°C
Terminal shape	WRAPAROUND
Tolerance	5%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

352020KJT Product Details

Live Product Chat

Fixed Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

352020KJT

(2-1622820-3)

T E I nternal N umber: 2 - 1 6 2 2 8 2 0 - 3

Product Highlights:

Resistor Type = Power Resistor

Resistance Selection = K ?

Resistance = 20K ?

Power Rating = 1.00 W

Tolerance = 5 %

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SMD POWER RESISTOR SERIES 3520

(PDF, English)

Catalog Pages/Data Sheets:

SMD Power Resistors - Type 3520 Series - Tyco Electr...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Resistor Type = Power Resistor

Resistance (?)

= 20K

Element

= Thick Film

Termination Type = Solder

Electrical Characteristics:

Resistance Selection (?)

= K

Power Rating (W)

= 1.00

Tolerance (%)

= 5

Package Type

= Taped and Reeled

Body Related Features:

Series

= 3520

Mount Style

= Surface Mount

Packaging Style

= 2512

Package, C omponent Size

= 6.4 x 3.2

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C ,

Reflow solder capable to 260?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= ?200

Operation/Application:

Application

= Power

Other:

Brand = C GS

Additional Information:

Product Line Information
