OMRON’s highly operable connectors are
“Easy-to-use”
OMRON connectors
Excellent operatability and workability
Improves Workability in “PCB-to-Wire” Connection.
XG4M-U MIL Connectors with lock
Easy
to Connect and Disconnect with One Hand
Up
to 24% Less Mounting Area
84.5
XG4A
Approx.
24%
reduction
XG4M-U
64.3
(
Compared to 40-pole model
)
unit:
mm
Improves
Lock Lever Operatability.
Approx.
24% reduction of Mounting Height.
Approx.
24%
reduction
27
20.2
XG4M-T
Designs a Metal Spring
Structure which will be unlocked
by grasping connector directly
XG4M-U
unit:
mm
Easy Connectors Most Suitable for Sensor Connection.
XN2 Easy Connector for Industrial Application
Easy
Wire Connection
Requires No Special Tools.
Repeat
Wire Connection
(Repair) Possible
A
Piece Connector Accepts
a Variety of Wire Size.
3
designed considering on-site work throughly
XF Series FPC Connectors
Improvement 1
Rotary slider independent of the FPC socket
Slider does not disconnect if the FPC is lifted.
High reliability-A mounted FPC will not come off
if excess force is applied to it.
Improvement 2
Four-sided FPC housing
Construction prevents FPC displacement.
Mounting reliability is enhanced because the FPC is held in
a four-sided housing and is unaffected by the slider operation.
Rotary Slider
Traditional Rotary Connector
XF Series
1
. Mount the connector.
FPC Socket
Upper Contact
Lower Contact
1
. Mount the connector.
2
. Release the rotary slider.
2
. Insert the FPC.
3
. Insert the FPC.
Upper Contact
Lower Contact
3
. Lock the rotary slider.
4
. Lock the rotary slider.
Improvement 3
Dual contact
Note: Except the XF3A, XF2C Series and XF2B-61 pin.
Improvement 4
Delivered with the rotary slider open.
Reduces the labor required to mount FPCs.
Assembly speed is improved over the conventional rotary
locking type because the rotary slider does not need to be released.
No need to discriminate between the upper
and lower FPC contacts.
Connectors are the same, so it's not necessary to
distinguish between the upper and lower contacts
when connecting upper and lower PCBs.
Natural Color Connector helps you to Improve Circuit Recognition.
XJ8A Jump Sockets (natural color)
Easy
to Recognize in Inspection Process, or by Circuits.
Remains
the structure of “Easy-to-connect”
and “Hard-to-disconnect”.
4
MCU
