REVISION AY
DO NOT
SCALE FROM
THIS PRINT
PATENT NUMBERS
5713755 / 5961339
FTR-1XX-XX-XX-D-XX-XX
No OF POSITIONS
-02 THRU -50
(PER ROW)
LEAD STYLE
SEE TABLE 1
(No OF POS x .050 [1.27]) +.002/-.010
[+.05/-.25]
02
100
SEE NOTE 4
.196 4.98
REF
.100 2.54
REF
01
.050 1.27 REF
99
HTMS-50-D
3 MAX SWAY
(EITHER DIRECTION)
PLATING SPECIFICATION
-G: 10µ" GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-T: MATTE TIN CONTACT AND TAIL
(LEAD STYLES -01, -02, -03, -51, -52 ONLY)
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-F: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-SM: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-TM: MATTE TIN CONTACT AND TAIL
(LEAD STYLES -01, -02, -03, -51, -52 ONLY)
-FM: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-H: 30µ" HEAVY GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
-L: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
BODY SPECIFICATION
-D: DOUBLE (USE HTMS-50-D)
OPTION
-P: PICK & PLACE PAD
(USE PPP-22)
(SEE FIG 3, SHT 2)
[5 POS MIN]
-TR: TAPE AND REEL PACKAGING
(POSITIONS -02 THROUGH -50)
OPTION
-A: ALIGNMENT PIN (5 POS MIN)
( SEE FIG 2, SHT 2)
SAMTEC DISCRETION ON WHICH
-A PIN USED.
-LC: STAKED LOCKING CLIP (USE LC-05-TM)
(SEE FIG 4, SHT 2 & NOTE 10)
-XX: POLARIZING SPECIFICATION
XX INDICATES POS TO BE OMMITED
T-1M6-XX-XX-2
.018 0.46 SQ
REF
2 MAX SWAY
(EITHER DIRECTION)
2 MAX SWAY
(EITHER DIRECTION)
.050 1.27 (TYP)
(SEE NOTE 5)
C
CONTACT
AREA
"B"
90°
- 2°
(TYP)
.100 2.54
REF
C
C
+4°
.004 [.10]
.05 1.3
(SEE NOTE 7)
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MAXIMUM CUT FLASH: .010[.25].
3. MINIMUM PUSHOUT FORCE: 2 LB.
4. MAXIMUM PIN ROTATION IN BODY: 2°.
5. SHEAR TAILS TO DIMENSION SHOWN.
6. MAXIMUM BURR ALLOWANCE: .003[.08]
7. MEASURED AT BEND RADIUS.
8. TUBE POSITIONS -05 AND GREATER; LAYER
PACKAGE POSITIONS -02 THRU -04.
9. -P OPTION: TUBE POSITIONS -07 THRU -50;
ALL OTHERS, TAPE & REEL ONLY.
10. DUE TO HIGH AMOUNT OF INSERTION FORCE
NEEDED, THE -LC OPTION IS NOT COMPATIBLE
WITH AUTO PLACEMENT. SAMTEC RECOMENDS
MANUAL PLACEMENT FOR ALL ASSEMBLIES
WITH THE -LC OPTION.
FTR-1XX-XX-D SHOWN
FIG 1
.2960 7.518 REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.X: .1 [2.5]
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
MATERIAL:
DECIMALS
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: LCP, UL 94 VO, COLOR: BLACK
TERMINAL: PHOS BRONZE
HI-TEMP TERMINAL MICRO-STRIP (DOUBLE ROW)
FTR-1XX-XX-XX-D-XX-XX
12/12/2000
SHEET
1
OF
3
F:\DWG\MISC\MKTG\FTR-1XX-XX-XX-D-XX-XX-MKT.SLDDRW
BY:
DEAN P
REVISION AY
HTMS-50-D-XX
.040 1.02
REF
C
.090 2.29
C
.090 2.29
REF
.040 1.02
REF
(No OF POS - 2) x .0500[1.270]
.0430 1.092 REF
SMA-8H
(No OF POS -2) x .0500[1.270] REF
.0430 1.092
REF
STAKED
(5 POSITIONS MINIMUM)
-A OPTION: ALIGNMENT PIN
(DIFFERENT AS SHOWN, OTHERWISE SEE FIG 1)
FIG 2
MOLDED
(5 POSITIONS MINIMUM)
"N"
C
"Q"
.375 9.53 REF
.390 9.91 REF
.230 5.84
REF
PPP-22
C
.105 2.67
(No OF POS - 2) x .0500[1.270]
.056 1.42 REF
C
L
"N" = USE MEASURED DIM
"Q" = {("N" - .375) / 2} .020
*
LC-05-TM
-P PICK & PLACE
(5 POSITIONS MINIMUM, SEE NOTE 9)
PROPRIETARY NOTE
*
FIG 3
-LC OPTION: STAKED LOCKING CLIP
(6 POSITIONS MINIMUM)
(DIFFERENT AS SHOWN, OTHERWISE SEE FIG 1)
FIG 4
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
HI-TEMP TERMINAL MICRO-STRIP (DOUBLE ROW)
FTR-1XX-XX-XX-D-XX-XX
12/12/2000
SHEET
2
OF
3
F:\DWG\MISC\MKTG\FTR-1XX-XX-XX-D-XX-XX-MKT.SLDDRW
BY:
DEAN P
REVISION AY
PT-1-24-02-44 & TP-03
PT-1-24-02-44 & TP-03
PT-1-24-01-29 & TP-03
PT-1-24-09-29 & TP-03
-01, -02, -03, -51 & -52 LEAD STYLES
-01-P, -02-P, -03-P,
-51-P & -52-P LEAD STYLES
PT-1-24-05-44 & TP-03
-53 & -54 LEAD STYLES
-55, -56 & -57 LEAD STYLES
PT-1-24-03-44 & TP-03
-53-P LEAD STYLE
-54-P, -55-P, -56-P & -57-P LEAD STYLES
PACKAGING VIEWS
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
HI-TEMP TERMINAL MICRO-STRIP (DOUBLE ROW)
FTR-1XX-XX-XX-D-XX-XX
12/12/2000
SHEET
3
OF
3
F:\DWG\MISC\MKTG\FTR-1XX-XX-XX-D-XX-XX-MKT.SLDDRW
BY:
DEAN P
