MINIMUM INSERTION LOSS, 50
D
LINE TO GROUND (COMMON MODE)
CURRENT
RATING
3 AMP
6 AMP
10 AMP
FREQUENCY, MHz
.15 .5
1
3 10 30
50 60 60 49 40 30
34 58 58 47 37 30
6 35 45 45 38 30
LINE AND LOAD IMPEDANCES
LINE TO LINE (DIFFERENTIAL MODE)
CURRENT
RATING
3 AMP
6 AMP
10 AMP
FREQUENCY, MHz
.15 .5
1
3 10 30
R .06
.135
2.201
+.008
-.000
*
25 60 60 53 45 40
9 50 62 54 46 40
10 20 59 54 48 40
1.575
PE VERSIONS
+.008
1.120
-.000
FOR PS VERSIONS THE SHORT EDGES MUST
HAVE R.02 ON INSERTION SIDE.
* FOR PANEL THICKNESS 0.031-0.079 USE 2.201
FOR PANEL THICKNESS 0.083-0.114 USE 2.213.
PANEL CUT-OUT
D
2.496
PM VERSIONS
ALLOW .15
FOR SWITCHED
VERSIONS
C
1.22
.21
2.73
2.45
1.95
.23
2.71
2.43
.13
.23
.23
2.71
2.43
.340
.206
.55
C
.28
2.29
.13
.23
2.88
2.12
PS
SNAP-IN
MOUNTING
B
P
MOUNTING STYLE
S = SEE ABOVE
E = SEE ABOVE
M = SEE ABOVE
S
2.75
PS
PE
SHOWN
WITHOUT SWITCH
2.73
PE
PM
SHOWN WITH
SWITCH
2.73
PM
PS
1.14
PART NUMBER SYSTEM
0
S
0
S
M
6
E
CURRENT
3 = 3 AMP
6 = 6 AMP
X = 10 AMP
PS0S0SM6E EXAMPLE:
SNAP-IN MOUNTING
WITH SWITCH
SINGLE FUSING
6 AMP
0'S ARE ZEROS.
HIPOT RATING (ONE MINUTE)
LINE TO GROUND:
1500 VAC
LINE TO LINE:
1450 VDC
OPERATING FREQUENCY:
50/60 Hz
RATED VOLTAGE:
120/250 VAC
FUSING:
ACCEPTS 3AG
1/4" X 1-1/4"
OR
METRIC
5 mm X 20 mm
OPERATING AMBIENT TEMP: -10°C TO 40°C
STORAGE TEMPERATURE:
-40°C TO 85°C
THIS DRAWING IS A CONTROLLED DOCUMENT.
DWN
CHK
DIMENSIONS:
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
APVD
PRODUCT SPEC
MAX LEAKAGE CURRENT .25mA
PER LINE TO GROUND: .50mA
HUMIDITY:
21 DAYS, 40°C
CURRENT OVERLOAD: 6X RATED FOR
SWITCH:
10K CYCLES
@ 51
TERMINALS: 0.187" X .032 FASTON
SAFETY AGENCIES: UL RECOGNIZED,
CSA CERTIFIED,
VDE APPROVED.
@ 120V 60Hz
@ 250V 60Hz
@ 95%RH
8 SEC
AMP INRUSH
TABS
B
SWITCH OPTIONS
0 = NONE
S = DOUBLE POLE,
SINGLE THROW
A
TE Connectivity
NAME
FUSE LOCATIONS
D = DUAL FUSING
S = SINGLE FUSING
INCLUDES CONVERSION CLIP
