CDLL4565E3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> CDLL4565E3

CDLL4565E3: DescriptionZener Diode, 6.4V V(Z), 5%, 0.5W, Silicon, DO-213AA, HERMETIC SEALED, GLASS, LL34, MELF-2; CategoryDiscrete semiconductor diode; File Size254KB，2 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric View All

CDLL4565E3 Overview

Zener Diode, 6.4V V(Z), 5%, 0.5W, Silicon, DO-213AA, HERMETIC SEALED, GLASS, LL34, MELF-2

CDLL4565E3 Parametric

Parameter Name	Attribute value
Maker	Microsemi
package instruction	O-LELF-R2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-213AA
JESD-30 code	O-LELF-R2
Number of components	1
Number of terminals	2
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Maximum power dissipation	0.5 W
Nominal reference voltage	6.4 V
surface mount	YES
technology	ZENER
Terminal form	WRAP AROUND
Terminal location	END
Voltage temperatureCoeff-Max	0.64 mV/°C
Maximum voltage tolerance	5%
Base Number Matches	1

Preview

Download Datasheet

View All

• 1N4565AUR-1 THRU 1N4584AUR-1 AVAILABLE IN

JAN, JANTX, JANTXV AND JANS 1N4565AUR-1 thru 1N4584AUR-1

PER MIL-PRF-19500/452

and

• TEMPERATURE COMPENSATED ZENER REFERENCE DIODES

• LEADLESS PACKAGE FOR SURFACE MOUNT

• LOW CURRENT OPERATING RANGE: 0.5 TO 4.0 mA

• METALLURGICALLY BONDED, DOUBLE PLUG CONSTRUCTION

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

DC Power Dissipation: 500mW @ +50°C

Power Derating: 4 mW / °C above +50°C

CDLL4565 thru CDLL4584A

REVERSE LEAKAGE CURRENT

lR = 2

A @ 25°C & VR = 3Vdc

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise speci½ed.

CDI

TYPE

NUMBER

ZENER

TEST

CURRENT

l ZT

EFFECTIVE

TEMPERATURE

COEFFICIENT

VOLTAGE

TEMPERATURE

STABILITY

³VZT MAX

-55° to + 100°

(Note 1)

100

2.5

100

2.5

100

2.5

100

2.5

TEMPERATURE

RANGE

MAX.DYNAMIC

ZENER

IMPEDANCE

ZZT

(Note 2)

°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

OHMS

200

100

CDLL4565

CDLL4565A

CDLL4566

CDLL4566A

CDLL4567

CDLL4567A

CDLL4568

CDLL4568A

CDLL4569

CDLL4569A

CDLL4570

CDLL4570A

CDLL4571

CDLL4571A

CDLL4572

CDLL4572A

CDLL4573

CDLL4573A

CDLL4574

CDLL4574A

CDLL4575

CDLL4575A

CDLL4576

CDLL4576A

CDLL4577

CDLL4577A

CDLL4578

CDLL4578A

CDLL4579

CDLL4579A

CDLL4580

CDLL4580A

CDLL4581

CDLL4581A

CDLL4582

CDLL4582A

CDLL4583

CDLL4583A

CDLL4584

CDLL4584A

1.0

2.0

4.0

%/°C

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

DIM

MILLIMETERS

INCHES

MIN MAX MIN MAX

1.60

1.70 0.063 0.067

0.41

0.55 0.016 0.022

3.30

3.70 .130 .146

2.54 REF.

.100 REF.

0.03 MIN.

.001 MIN.

FIGURE 1

DESIGN DATA

CASE:

DO-213AA, Hermetically sealed

glass case. (MELF, SOD-80, LL34)

LEAD FINISH:

Tin / Lead

POLARITY:

Diode to be operated with

the banded (cathode) end positive.

MOUNTING POSITION:

Any.

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) Of this Device is Approximately

+6PPM/°C. The COE of the Mounting

Surface System Should Be Selected To

Provide A Suitable Match With This

Device.

NOTE 1

The maximum allowable change observed over the entire temperature range

i.e.,the diode voltage will not exceed the speci½ed mV at any discrete

temperature between the established limits, per JEDEC standard No.5.

NOTE 2

Zener impedance is derived by superimposing on l ZT A 60Hz rms a.c. current

equal to 10% of l ZT.

6 LAKE STREET, LAWRENCE, MASSACHUSETTS 01841

PHONE (978) 620-2600

FAX (978) 689-0803

WEBSITE: http://www.microsemi.com
