3M
™
Accessories
.100”
×
.100” EMI System
3705/3706 Series
•
Spring latch attachment allows quick, easy connect/
disconnect
•
Fits existing 3M™ connectors
•
Intra-cabinet grounding eliminates pigtails/
drain wires and need for grounding clamps
•
Cast aluminum shell offers excellent ground for
EMI/ ESD
•
RoHS* compliant
D
Shell
Insulation Material:
Flammability Rating:
Ground Plate
Material:
Plating:
Retaining Clip
Material:
Plating:
D
* RoHS = Directive 2002/95/EC, Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment
"RoHS compliant" means that the product or part does not contain any of the following substances in excess of the following maximum concentration values
in any homogeneous material, unless the substance is in an application that is exempt under RoHS: (a) 0.1% (by weight) for lead, mercury, hexavalent
chromium, polybrominated biphenyls or polybrominated diphenyl ethers; or (b) 0.01% (by weight) for cadmium. Unless otherwise stated by 3M in writing,
this information represents 3M's knowledge and belief based upon information provided by third party suppliers to 3M.
IS
C
Material:
Plating:
Latch
Material:
Plating:
Cable Clamp
Material:
Plating:
Stainless Steel
100
”
[ 2.54 m
]
Minimum Nickel
Copper Alloy
75
”
[ 1.91 m
]
Minimum Nickel
Glass Filled Polyester (PBT)
UL 94V-0
Receptacle
Copper Alloy
100
”
[ 2.54 m
]
Minimum Nickel
Stainless Steel
100
”
[ 2.54 m
]
Minimum Nickel
O
N
T
Die Cast Aluminum Alloy
200
”
[ 5.08 m
]
Minimum Nickel
IN
Physical
Interconnect Solutions
http://www.3M.com/interconnects/
U
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
E
Date Modified: July 18, 2008
TS-0098-B
Sheet 1 of 4
3M
™
Accessories
.100″
×
.100″ EMI System
Position
A
20
26
34
40
50
60
1.69 [ 42.9 ]
1.99 [ 50.5 ]
2.39 [ 60.7 ]
2.69 [ 68.3 ]
3.19 [ 81.0 ]
3.69 [ 93.7 ]
B
1.50 [ 38.1 ]
1.80 [ 45.7 ]
2.20 [ 55.9 ]
2.50 [ 63.5 ]
2.80 [ 71.1 ]
3.30 [ 83.8 ]
C
0.39 [ 9.9 ]
0.43 [ 10.9 ]
0.47 [ 11.9 ]
0.51 [ 13.0 ]
0.59 [ 15.0 ]
0.67 [ 17.0 ]
D
1.26 [ 32.0 ]
1.26 [ 32.0 ]
1.32 [ 33.5 ]
1.32 [ 33.5 ]
1.38 [ 35.1 ]
1.38 [ 35.1 ]
E
1.65 [ 41.9 ]
1.65 [ 41.9 ]
1.71 [ 43.4 ]
1.71 [ 43.4 ]
1.77 [ 45.0 ]
1.77 [ 45.0 ]
F
0.35 [ 8.9 ]
0.35 [ 8.9 ]
0.47 [ 11.9 ]
0.47 [ 11.9 ]
0.47 [ 11.9 ]
0.47 [ 11.9 ]
3705/3706 Series
Dimensions
4X R .18
[ 4.6 ]
.43
[ 10.9 ]
C
For 34 position and
higher the shell thickness
increases to the dashed
line (See table Dim F).
See Note 1
A
See Note 2
2X (See Note 4)
IN
U
F
N
2X (See Note 5)
V
V
V
V
V
V
T
D
E
D
IS
C
O
B
.43
[ 10.9 ]
2X (See Note 3)
E
.35
[ 8.9 ]
Notes:
1.Two Shell Halves: Aluminum Alloy Die Casting, Plating-200μ″ [ 5.0
μm
] Nickel Min.
2.One Cable Clamp: Copper Alloy, Plating 75μ″ [ 2.0
μm
] Nickel Min.
3.Two Latches: Stainless Steel, Plating 100μ″ [ 2.54
μm
] Nickel Min.
4.Two Roundhead Screws: M3 x 0.5 mm x 4 mm long.
5.Two Flathead screws: M3 x 0.5 mm x 6 mm Long.
D
In c h
[m m ]
T o le ra n c e U n le s s N o te d
.0
in c h
± .1
.0 0
.0 0 0
± .0 1 ± .0 0 5
[ ] D im e n s io n s fo r R e fe re n c e
O n ly
Ordering Information
Shell Kit
3705-A2XX
Position: See Table
TS-0098-B
Sheet 2 of 4
Note: Wiremount Shell Kit to be used with respective Socket and Cable (Order Separately)
3M
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
Accessories
.100″
×
.100″ EMI System
Position
A
20
26
34
40
50
60
1.53 [ 38.9 ]
1.83 [ 46.5 ]
2.23 [ 56.6 ]
2.53 [ 64.3 ]
3.03 [ 77.0 ]
3.53 [ 89.7 ]
B
1.98 [ 50.3 ]
2.28 [ 57.9 ]
2.69 [ 68.3 ]
2.98 [ 75.7 ]
3.48 [ 88.4 ]
3.98 [ 101.1 ]
C
2.36 [ 59.9 ]
2.66 [ 67.6 ]
3.06 [ 77.7 ]
3.36 [ 85.3 ]
3.86 [ 98.0 ]
4.36 [ 110.7 ]
D
1.41 [ 35.8 ]
1.71 [ 43.4 ]
2.11 [ 53.6 ]
2.41 [ 61.2 ]
2.91 [ 73.9 ]
3.41 [ 86.6 ]
E
1.79 [ 45.5 ]
2.09 [ 53.1 ]
2.49 [ 63.2 ]
2.79 [ 70.9 ]
3.37 [ 85.6 ]
3.87 [ 98.3 ]
3705/3706 Series
Dimensions
C
B
A
2X (See Note 2)
IN
.40 Ref
[ 10.2 ]
(See Note 6)
2X (See Note 3)
U
See Note 1
.71
[ 18.0 ]
2X (See Note 4)
N
O
T
.37
[ 9.4 ]
.70
[ 17.8 ]
.32
[ 8.1 ]
2X (See Note 5)
Position: See Table
2X Stop
D
Notes:
1.One Bracket: PBT, Flammability Rating: UL 94V-0.
2.Two Ground Plates: Copper Alloy, Plating-100
μ″
[ 2.54
μm
] Nickel Min.
3.Two Retaining Clips: Stainless Steel, Plating-100
μ″
[ 2.54
μm
] Nickel Min.
4.Two Roundhead Screws: M3 x 6mm Long.
5.Two Roundhead Screws: M3 x 0.5mm x 10mm Long. (For use with Plug Connector).
6.This is the recommended distance from the inside of the panel to the front face of the Header or Plug.
Ordering Information
IS
C
D
E
Receptacle Kit
3706-50XX
TS-0098-B
Sheet 3 of 4
Note: Panel Mount Receptable Kit to be used with respective Plug or Header (Order Separately).
3M
Interconnect Solutions
http://www.3M.com/interconnects/
E
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
D
4X M3 X 0.5mm
Threaded Inserts
Regulatory Information Appendix
