REVISION K
DO NOT
SCALE FROM
THIS PRINT
1.57 (4 PLCS) REF
0.75 (4 PLCS) REF
0.800 .0315 (TYP)
PIN 01
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
"A" REF
C
"E" EQ. SPCS @ 0.8 [.031]= "F"±0.1
2.00 .079 REF (TYP)
"A"
4.00 .157 REF (TYP)
SEAF8-XX-05.0-X-XX-X-X-TR
No OF POSITIONS
-10, -20, -30,*-40,*-50
(PER ROW)
LEAD STYLE
-05.0= 5mm
PLATING SPECIFICATION
-S: .000030" SELECTIVE GOLD
IN CONTACT AREA,
MATTE TIN ON TAIL
PACKAGING
-TR = TAPE & REEL
(SEE NOTES 4, 5 & 7)
OPTIONS
-K = POLYIMIDE PAD
(SEE SHT 3, FIG 2)
SOLDER COMPOSITION
& STYLE
*-1: 63.0% TIN / 37.0% LEAD
CHARGE TAIL
-2: 95.5% TIN / 3.8% SILVER/
0.7% COPPER CHARGE TAIL
"H" REF C
L
(2 PLCS)
"G"
REF
C
'C'
PIN 08
C
L
"B" REF
"A"
ROW
-04: 4 ROWS
-06: 6 ROWS
*-08: 8 ROWS
*-10: 10 ROWS
(* = NOT TOOLED)
2.87 .113
REF
C
4.57 REF
SEAF8-XX-05.0-XX-X
'B'
PATENT NUMBER
7837522,
ADDITIONAL
PATENTS
PENDING
C
L
C
"C" (TYP)
"D" REF
1.32 .052 REF
1.32 .052
REF
1.27 .050 REF.
(2 PLCS)
0.800 .0315
(TYP)
C
L
"J" REF
1.10 .043 REF
(SEAF8-30-05.0-X-XX-X-X-TR SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS [INCHES].
FIG 1
F:\DWG\MISC\MKTG\SEAF8-XX-05.0-X-XX-X-X-TR-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSH OUT FORCE 1.6N [0.36 LBS.]
3. DIMENSION TO BE MEASURED IN ALL FOUR CORNERS TO THE STAND-OFF.
4. TAPE & REEL WILL BE SUPPLIED WHETHER OR NOT -TR IS SPECIFIED.
5.
FOR QUANTITIES UP TO 49 PCS., NO LEADER, TRAILER OR REEL WILL BE SUPPLIED,
FOR QUANTITIES OF 50-124 PCS., NO LEADER OR TRAILER WILL BE SUPPLIED,
SPLICES MAY BE PRESENT.
6. NOTE DELETED.
7. ATTACH LABEL "SEAX-0001" TO EACH TAPE & REEL PACKAGE.
8. MAXIMUM ROW TO ROW VARIATION 0.08 [.003], MEASURED FIRST AND LAST POSITIONS ONLY, ALL ROWS.
TOLERANCES ARE:
DECIMALS
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: LCP, COLOR BLACK
CONTACT: COPPER ALLOY
0.8MM PITCH SOCKET ARRAY ASSY
C
BY:
M MURILLO
SEAF8-XX-05.0-X-XX-X-X-TR
01/09/09
SHEET
1
OF
3
REVISION K
C
0.50
- 0.15
.020
- .006
(TYP)
+0.05
+.002
0.72 .028 REF
0.25 .010 REF
1.00 (4 PLCS)
REF
SUB-C-265-05.0-X-X
C
0.15 [.006]
C
SOLDER
CHARGE
1.20 .047 REF.
C
0.33±0.08 .013±.003
(TYP)
0.80 .031 REF.
0.05 [.002] (TYP) REF
1.33
- 0.08
.052
- .003
(TYP)
+0.15
+.006
C
DETAIL 'B'
SCALE 10 : 1
0.13±0.08 .005±.003 (TYP)
(SEE NOTE 3)
SECTION "A"-"A"
SCALE 8 : 1
(VIEW ROTATED 90 CW)
MEASUREMENTS TAKEN
AT EDGE OF CONTACT
'F'
DETAIL 'F'
SCALE 100 : 1
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
0.1 MAX
(MEASURE FROM BEAM EDGES)
C
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
0.8MM PITCH SOCKET ARRAY ASSY
DETAIL 'C'
SCALE 40 : 1
SEAF8-XX-05.0-X-XX-X-X-TR
01/09/09
SHEET
2
OF
3
BY:
M MURILLO
F:\DWG\MISC\MKTG\SEAF8-XX-05.0-X-XX-X-X-TR-MKT.SLDDRW
REVISION K
"A" REF
0.13 .005 PAD REF
"G"
REF
C
"P"±0.51 [.020]
C
"N" 0.51 [.020]
"M"
4.70 .185
(TOP OF PAD
TO BOTTOM
OF STANDOFF)
-K POLYIMIDE PAD
(SEAF8-XX-05.0-X-XX-X-K-TR SHOWN)
(SOME CENTER FEATURES REMOVED FOR CLARITY)
FIG 2
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
0.8MM PITCH SOCKET ARRAY ASSY
SEAF8-XX-05.0-X-XX-X-X-TR
01/09/09
SHEET
3
OF
3
BY:
M MURILLO
F:\DWG\MISC\MKTG\SEAF8-XX-05.0-X-XX-X-X-TR-MKT.SLDDRW
