SR732AGTER205D: DescriptionFixed Resistor, Metal Glaze/thick Film, 0.33W, 0.205ohm, 0.2601V, 0.5% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP; CategoryPassive components The resistor; File Size348KB，3 Pages; ManufacturerKOA; Environmental Compliance

Download Datasheet Parametric View All

SR732AGTER205D Overview

Fixed Resistor, Metal Glaze/thick Film, 0.33W, 0.205ohm, 0.2601V, 0.5% +/-Tol, 100ppm/Cel, Surface Mount, 0805, CHIP

SR732AGTER205D Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	7009683140
package instruction	CHIP
Reach Compliance Code	compliant
Country Of Origin	Japan
ECCN code	EAR99
YTEOL	8.2
structure	Rectangular
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package height	0.5 mm
Package length	2 mm
Package form	SMT
Package width	1.25 mm
method of packing	TR, EMBOSSED PLASTIC, 7 INCH
Rated power dissipation(P)	0.33 W
Rated temperature	70 °C
Guideline	AEC-Q200
resistance	0.205 Ω
Resistor type	FIXED RESISTOR
size code	0805
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	100 ppm/°C
Terminal surface	Gold (Au) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Tolerance	0.5%
Operating Voltage	0.2601 V

Preview

Download Datasheet

View All

SR73

lo-ohm 0.5%, 1%, 2%, 5% tolerance thick film

current sense resistor

features

•

Current detecting resistors for power

supply, motor circuits, etc.

•

High reliability and performance with resistance

tolerance ±0.5%, T.C.R. ±100 x 10

-6

•

Suitable for both reflow and flow solderings

•

Products with lead-free terminations meet EU RoHS

requirements. EU RoHS regulation is not intended for

Pb-glass contained in electrode, resistor element and glass.

•

AEC-Q200 Tested: 0402 (1E), 0603 (1J), 0805 (2A),

1206 (2B), 1210 (2E), 2010 (2H/W2H), 2512 (3A/W3A)

dimensions and construction

current

sense

Type

(Inch Size Code)

.024±.001

(0.6±0.03)

.039

(1.0

+.004

-.002

+0.1

)

-0.05

Dimensions

inches

(mm)

.012±.001

(0.3±0.03)

.02

(0.5

+.004

-.002

+0.1

)

-0.05

+.006

-.004

+0.15

)

-0.1

.009±.001

(0.23±0.03)

.014±.002

(0.35±0.05)

.018±.004

(0.45±0.1)

.02±.004

(0.5±0.1)

1H (0201)

Plating

Protective

Coating

Resistive Inner

Film

Electrode

Plating

.004±.002

(0.1±0.05)

.01±.004

(0.25±0.1)

.014±.004

(0.35±0.1)

.016±.008

(0.4±0.2)

.006±.002

(0.15±0.05)

.01±.004

(0.25±0.1)

.014±.004

(0.35±0.1)

.012

(0.3

+.008

-.004

+0.2

)

-0.1

1E (0402)

1J (0603)

2A (0805)

.063±.008

(1.6±0.2)

.079±.008

(2.0±0.2)

.126±.008

(3.2±0.2)

.031

(0.8

.049±.004

(1.25±0.1)

.063±.008

(1.6±0.2)

.102±.008

(2.6±0.2)

.098±.008

(2.5±0.2)

Ceramic

Substrate

2B (1206)

2E (1210)

2H (2010)

W2H (2010)

3A (2512)

W3A (2512)

.016

(0.4

.02±.012

(0.5±0.3)

+.008

-.004

+0.2

)

-0.1

.197±.008

(5.0±0.2)

.026±.006

(0.65±0.15)

.016

(0.4

+.008

-.004

+0.2

-0.1

)

.024±.004

(0.6±0.1)

.248±.008

(6.3±0.2)

.122±.008

(3.1±0.2)

.026±.006

(0.65±0.15)

ordering information

SR73

Type

Size

W2H

W3A

Termination

Material

T: Sn

L: SnPb (1E,

1J, 2A, 2B, 2E)

G: Au (1J, 2A,

2B: 0.1Ω - 10Ω,

F: ±1%, J: ±5% -

contact factory)

Packaging

TC: 0201 only: 7" 2mm pitch pressed

paper (TC: 10,000 pcs/reel,

TCM: 15,000 pcs/reel)

TPL: 0402 only: 2mm pitch punch paper

TP: 0402, 0603, 0805: 7" 2mm pitch

punch paper

TD: 0603, 0805, 1206, 1210: 7" 4mm

pitch punched paper

TE: 0805, 1206, 1210, 2010 & 2512:

7" 4mm embossed plastic

For further information on packaging, please

refer to Appendix A

1R00

Nominal

Resistance

±2%, ±5%: 2 significant figures

+ 1 multiplier “R” indicates

decimal on value <10Ω

±1%: 3 significant figures

+ 1 multiplier “R” indicates

decimal on value <100Ω

All values less than 0.1Ω

(100mΩ) are expressed in

mΩ with “L” as decimal

Example: 20mΩ = 20L

(3-digit)

Tolerance

D: ±0.5%

F: ±1%

G: ±2%

J: ±5%

Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.

11/3/20

124

KOA Speer Electronics, Inc.

• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
