172x150x38mm
AC AXIAL FAN
Features:
FDA2-17238 Series
Motor: External Rotor Capacitor-Run Induction Motor
Motor Protection: Thermal Protected
Bearing Type: Two Ball
Connection: UL 1015 AWG 22, 300mm Wire Leads or Terminal
Frame Material: Aluminum Alloy
Impeller Material: Plastic UL94V-0, or Steel
IP56M Certified
Operating Temp:
Two Ball: -20°C~70°C
Life Expectancy:
Two Ball: 50,000 Hours
Two Ball: 100,000 Hours (-L)
IP56M
Fan-S Division
Model No.
FDA2-17238NBH
*
**
D
FDA2-17238QBH
*
**
D
#
#
Volt.
(VAC)
Freq.
(Hz)
Current
(A)
Power
(W)
Rated
Speed
(rpm)
Maximum
AirFlow
(CMM)
(CFM)
Maximum Static
Pressure
(InAq)
(mmAq)
Noise
Level
(dB/A)
Weight
(g)
115
230
50/60
50/60
0.25/0.21 27.0/25.0
0.11/0.12 26.0/27.0
2700/3100 5.95/6.80
2700/3100 5.95/6.80
210/240
210/240
0.531/0.571 13.5/14.5
0.531/0.571 13.5/14.5
53.0/59.0
53.0/59.0
820
820
*
Indicates “W” (Wire Leads) or “T” (Terminal)
**
Indicates “3” (Metal Frame, Plastic Impeller) or “4” (Metal Frame and Impeller)
#
Indicates “-L” (100,000 Hours Life Expectancy) or Leave Blank (50,000 Hours Life Expectancy)
Fan Performance Curve
H
Noise is measured at the distance of one (1) meter from the axis of intake.
20
STATIC PRESSURE (mmAq)
16
Air flow
R otation direction
12
8
4
Ø4.3 ± 0.2
0
0
50
100
150
200
250
FLOWRATE (CFM)
M4xP0.7
20
Fan Performance Curve
H
STATIC PRESSURE (mmAq)
16
3
12
38.5
± 0.5
162 ± 0.3
172 ± 0.5
8
4
0
0
50
100
150
200
250
FLOWRATE (CFM)
ISO-9001 Company
Q
ualtek
Electronics Corporation
www.Qualtekusa.com
151 ± 1
