FMM5709VZ
K / Ka Band Low Noise Amplifier MMIC
FEATURES
・Low
Noise Figure : NF = 3.5dB ( Typ.) @ f=26GHz
・High
Associated Gain : Gas = 21dB ( Typ.) @f=26GHz
・Broad
Band : 17.5~32GHz
・High
Output Power : P1dB = 12dBm ( Typ. ) @f=26GHz
・Ball
Grid Array SMT Package(VZ-pkg)
・Impedance
Matched Zin/Zout = 50Ω
DESCRIPTION
The FMM5709VZ is a LNA MMIC designed for applications in the
17.5~32 GHz frequency range. This product is well suited for fixed
wireless access, radio link, and applications where low noise and
high dynamic range are required.
Eudyna’s stringent Quality Assurance Program assures the highest
reliability and consistent performance.
ABSOLUTE MAXIMUM RATING
Item
Drain Voltage
Input Power
Storage Temperature
Symbol
V
DD
P
in
T
stg
Rating
4
-3
-55 to +125
Unit
V
dBm
℃
RECOMMENDED OPERATING CONDITIONS
Item
Drain Voltage
Operating Case Temperature
Symbol
V
DD
T
c
Condition
3
-40 to +85
Unit
V
℃
ELECTRICAL CHARACTERISTICS (Case Temperature Tc=25
℃
)
Item
Noise Figure
Associated Gain
Drain Current
Output Power at 1dB G.C.P.
Output 3rd order intercept point
Input Return Loss (at P
in
=-20dBm)
Output Return Loss (at P
in
=-20dBm)
Symbol
NF
Gas
I
DD
P
1dB
OIP3
RL
in
RL
out
Test Conditions
Freq.=26GHz
V
DD
=3V
I
DD
=60mA typ.
Z
S
=Z
L
=50
Ω
Limits
Min.
-
19
-
-
-
-
-
Typ.
3.5
21
60
12.0
22.5
-10
-10
Max.
4
24
75
-
-
-
-
Unit
dB
dB
mA
dBm
dBm
dB
dB
G.C.P. : Gain Compression Point
ESD
Class 0
~ 199V
Note : Based on EIAJ ED-4701 C-111A(C=100pF, R=1.5k
Ω
)
VZ
CASE STYLE
Edition 1.2
October 2004
1
FMM5709VZ
K / Ka Band Low Noise Amplifier MMIC
NOISE FIGURE, ASSOCIATED GAIN vs. FREQUENCY
V
DD
=3V
11
10
9
Noise Figure [dB]
8
7
6
5
4
3
2
1
14
16
18
20
22
24
26
28
30
32
34
36
38
Frequency [GHz]
NF
Gas
28
26
Associated Gain [dB]
G1dB [dB]
24
22
20
18
16
14
12
10
8
P
1dB
, G
1dB
vs. FREQUENCY
V
DD
=3V
17
16
15
14
P1dB [dBm]
13
12
11
10
9
8
7
16
18
20
22
24
26
28
30
32
34
36
Frequency [GHz]
P
1dB
G
1dB
26
24
22
20
18
16
14
12
10
8
6
2
FMM5709VZ
K / Ka Band Low Noise Amplifier MMIC
OUTPUT POWER vs. INPUT POWER
V
DD
=3V
16
14
Output Power [dBm]
12
Gain [dB]
10
8
6
4
2
0
-22 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2
Input Power [dBm]
18GHz
22GHz
26GHz
30GHz
32GHz
GAIN vs. INPUT POWER
V
DD
=3V
26
24
22
20
18GHz
18
16
14
22GHz
26GHz
30GHz
32GHz
-22 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2
Input Power [dBm]
IMD PERFORMANCE
vs. TOTAL OUTPUT POWER
V
DD
=3V,Δf=+10MHz
Δ
-10
Intermodulation Distortion [dBc]
-15
-20
-25
-30
-35
-40
-45
-50
-55
-60
-65
-2
0
2
4
6
8
10
12
14
2-Tone Total Output Power [dBm]
IM
5
18GHz
22GHz
26GHz
30GHz
32GHz
IM
3
3
FMM5709VZ
K / Ka Band Low Noise Amplifier MMIC
NOISE FIGURE, ASSOCIATED GAIN vs. FREQUENCY
by Temperature
V
DD
=3V
11
10
9
Noise Figure [dB]
8
7
6
5
4
3
2
1
14
16
18
20
22
24
26
28
30
32
34
36
38
Frequency [GHz]
NF
-40
℃
28
Gas
+25
℃
+85
℃
26
Associated Gain [dB]
24
22
20
18
16
14
12
10
8
P
1dB
vs. FREQUENCY
by Temperature
V
DD
=3V
16
15
14
13
P
1dB
[dBm]
12
11
10
9
8
7
6
16 18 20 22 24 26 28 30 32 34 36
Frequency [GHz]
-40
℃
+25
℃
+85
℃
G
1dB
vs. FREQUENCY
by Temperature
V
DD
=3V
30
28
26
24
G
1dB
[dB]
22
20
18
16
14
12
10
16 18 20 22 24 26 28 30 32 34 36
Frequency [GHz]
-40
℃
+25
℃
+85
℃
4
FMM5709VZ
K / Ka Band Low Noise Amplifier MMIC
NOISE FIGURE, ASSOCIATED GAIN
vs. TEMPERATURE
V
DD
=3V
9
8
Noise Figure [dB]
7
6
5
4
3
2
1
-50
-25
0
25
50
75
Temperature [
℃
]
NF
18GHz
26GHz
32GHz
P
1dB
, G
1dB
vs. TEMPERATURE
V
DD
=3V
28
Gas
26
24
22
20
18
16
14
Associated Gain [dB]
12
100
20
19
18
17
16
15
14
13
12
11
10
9
8
7
-50
-25
G
1dB
P
1dB
0
25
50
30
28
26GHz
26
32GHz
24
22
20
18
16
14
12
10
8
6
4
75
100
18GHz
P
1dB
[dBm]
Temperature [
℃
]
5
G
1dB
[dB]
