* Specifications will vary with foreign standards certification ratings.
*
1
Measurement at same location as "Initial breakdown voltage" section.
*
2
Detection current: 10mA.
*
3
Nominal voltage applied to the coil, excluding contact bounce time.
*
4
By resistive method, nominal voltage applied to the coil; contact carrying current:
1 A.
*
5
Half-wave pulse of sine wave: 6 ms; detection time: 10
µ
s.
*
6
Half-wave pulse of sine wave: 6 ms.
*
7
Detection time: 10
µ
s.
*
8
Refer to 5. Conditions for operation, transport and storage mentioned in
AMBIENT ENVIRONMENT (Page 61)
f
1 This value can change due to the switching frequency, environmental conditions,
and desired reliability level, therefore it is recommended to check this with the
actual load.
f
2 The upper limit for the ambient temperature is the maximum temperature that
can satisfy the coil temperature rise. Under the packing condition, allowable
temperature range is from –40 to +70
°
C
–40
°
to +158
°
F.
125
GN
TYPICAL APPLICATIONS
• Telephone exchange, transmission
equipment
• Communications devices
• Measurement devices
• Home appliances, and audio/visual
equipment
• Handheld and portable products
ORDERING INFORMATION
Ex. AGN
Contact arrangement Operating function
2: 2 Form C
0: Single side stable
1: 1 coil latching
2
0
0
A
1
H
Z
Coil voltage (DC)
1H: 1.5V
03 : 3V
4H: 4.5V
06 : 6V
09 : 9V
12 : 12V
24 : 24V
Packing style
Nil: Tube packing
Z: Tape and reel packing
(piked from 5/6/7/8
pin side)
Type of operation
0: Standard type
(B.B.M.)
Terminal shape
Nil: Standard PC board terminal
A: Surface-mount terminal A type
S: Surface-mount terminal S type
Note: Tape and reel packing symbol “-Z” is not marked on the relay. “X” type tape and reel packing (picked from 1/2/3/4-pin side) is also available. Suffix “X” instead of “Z”.
TYPES AND COIL DATA (at 20
°
C
68
°
F)
(1) Standard PC board terminal
Part No.
Operating
Function
Standard PC
board terminal
AGN2001H
AGN20003
AGN2004H
Single side
stable
AGN20006
AGN20009
AGN20012
AGN20024
Part No.
Operating
Function
Standard PC
board terminal
AGN2101H
AGN21003
1 coil latching
AGN2104H
AGN21006
AGN21009
AGN21012
AGN21024
Coil Rating,
V DC
1.5
3
4.5
6
9
12
24
Coil Rating,
V DC
1.5
3
4.5
6
9
12
24
Pick-up volt-
age, V DC
(max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Set voltage,
V DC (max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Drop-out
voltage,
V DC (min.)
(initial)
0.15
0.3
0.45
0.6
0.9
1.2
2.4
Reset voltage,
V DC (max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Nominal
operating
current,
mA (
±
10%)
93.8
46.7
31
23.3
15.5
11.7
9.6
Nominal
operating
current,
mA (
±
10%)
66.7
33.3
22.2
16.7
11.1
8.3
5.0
Coil resistance,
Ω
(
±
10%)
16
64.2
145
257
579
1,028
2,504
Coil resistance,
Ω
(
±
10%)
22.5
90
202.5
360
810
1,440
4,800
Nominal
operating
power, mW
140
140
140
140
140
140
230
Nominal
operating
power, mW
100
100
100
100
100
100
120
Max. allowable
voltage,
V DC
2.25
4.5
6.75
9
13.5
18
28.8
Max. allowable
voltage,
V DC
2.25
4.5
6.75
9
13.5
18
36
1) Standard packing: 50 pcs. in an inner package (tube); 1,000 pcs. in an outer package
2) Specified value of pick-up, drop-out, set and reset voltage is with the condition of square wave coil pulse.
(2) Surface-mount terminal
Part No.
Operating
Function
Tube packing
AGN200
r
1H
AGN200
r
03
AGN200
r
4H
AGN200
r
06
AGN200
r
09
AGN200
r
12
AGN200
r
24
Tape and reel
packing
AGN200
r
1HZ
AGN200
r
03Z
AGN200
r
4HZ
AGN200
r
06Z
AGN200
r
09Z
AGN200
r
12Z
AGN200
r
24Z
Coil Rating,
V DC
1.5
3
4.5
6
9
12
24
Pick-up
voltage,
V DC (max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Drop-out
voltage,
V DC (min.)
(initial)
0.15
0.3
0.45
0.6
0.9
1.2
2.4
Nominal
operating
current,
mA (
±
10%)
93.8
46.7
31
23.3
15.5
11.7
9.6
Coil
resistance,
Ω
(
±
10%)
16
64.2
145
257
579
1,028
2,504
Nominal
operating
power,
mW
140
140
140
140
140
140
230
Max.
allowable
voltage,
V DC
2.25
4.5
6.75
9
13.5
18
28.8
Single side
stable
r
: For each surface-mounted terminal variation, input the following letter.
A type: A, S type: S
1) Standard packing: 50 pcs.(tube), 500pcs. (tape and reel)in an inner package; 1,000 pcs. in an outer package
2) Specified value of pick-up, drop-out, set and reset voltage is with the condition of square wave coil pulse.
126
GN
Part No.
Operating
Function
Tube packing
AGN210
r
1H
AGN210
r
03
AGN210
r
4H
AGN210
r
06
AGN210
r
09
AGN210
r
12
AGN210
r
24
Tape and reel
packing
AGN210
r
1HZ
AGN210
r
03Z
AGN210
r
4HZ
AGN210
r
06Z
AGN210
r
09Z
AGN210
r
12Z
AGN210
r
24Z
Coil Rating,
V DC
1.5
3
4.5
6
9
12
24
Set voltage,
V DC (max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Reset
voltage,
V DC (max.)
(initial)
1.13
2.25
3.38
4.5
6.75
9
18
Nominal
operating
current,
mA (
±
10%)
66.7
33.3
22.2
16.7
11.1
8.3
5.0
Coil
resistance,
Ω
(
±
10%)
22.5
90
202.5
360
810
1,440
4,800
Nominal
operating
power,
mW
100
100
100
100
100
100
120
Max.
allowable
voltage,
V DC
2.25
4.5
6.75
9
13.5
18
36
1 coil
latching
r
: For each surface-mounted terminal variation, input the following letter.
A type: A, S type: S
1) Standard packing: 50 pcs.(tube), 500pcs. (tape and reel)in an inner package; 1,000 pcs. in an outer package
2) Specified value of pick-up, drop-out, set and reset voltage is with the condition of square wave coil pulse.
DIMENSIONS
1. PC board terminal
10.60±0.3
.417±.012
5.70±0.3
.224±.012
3.20
.126
mm
inch
PC board pattern
7.60
.299
3.20
.126
Schematic (Bottom view)
Single side stable
(Deenergized condition)
1
2 3 4
1 coil latching
(Reset condition)
1
2 3 4
(0.50) 9.00±0.3
(.020) .354±.012
0.40±0.1
.016±.004
(1.50)
(.059)
3.50±0.3
.138±.012
2.20±0.15
.087±.006
3.20±0.15
.126±.006
0.25±0.1
.010±.004
3.20±0.15
.126±.006
2.20
8-0.85 dia.
.087
8-.033 dia
8
7 6 5
8
7 6 5
Direction indication
Direction indication
Tolerance:
±
0.1
±
.004
2. Surface-mount terminal
Suggested mounting pad
Schematic (Top view)
Single side stable
(Deenergized condition)
8
7 6 5
1) A type
0.25±0.1
.010±.004
0.40±0.1
.016±.004
(1.50)
(.059)
10.60±0.3
.417±.012
5.70±0.3
.224±.012
3.20
.126
3.10
.122
3.20±0.15
.126±.006
2.20
.087
1 coil latcing
(Reset condition)
8
7 6 5
(0.50) 9.00±0.3
(.020) .354±.012
Max. 10.00
.394
5.30
.209
0.80
.031
1
2 3 4
1
2 3 4
2.20±0.15
.087±.006
3.20±0.15
.126±.006
Direction indication
Direction indication
7.40±0.3
.291±.012
Tolerance:
±0.1
±.004
Suggested mounting pad
1) S type
0.25±0.1
.010±.004
0.40±0.1
.016±.004
(1.50)
(.059)
10.60±0.3
.417±.012
5.70±0.3
.224±.012
3.20
.126
2.25
.089
2.20
.087
(0.50) 9.00±0.3
(.020) .354±.012
Max. 10.00
.394
2.20±0.15
.087±.006
3.20±0.15
.126±.006
3.20±0.15
.126±.006
5.70±0.3
.224±.012
4.45
.175
0.80
.031
Tolerance:
±0.1
±.004
REFERENCE DATA
1. Max. switching capacity
DC resistive load
AC resistive load
2. Life curve
100
No. of operations,
×
10
4
Switching current, A
1.0
50
40
30
DC 30V resistive load
20
0.3
10
AC 125V
resistive load
30
100
Contact voltage, V
0
0.2
0.4
0.6
0.8
1.0
1.2
Switching current, A
127
GN
NOTES
1. Coil operating power
1) As a general rule, only a pure DC pow-
er supply should be used for the coil drive.
2) To ensure proper operation, the voltage
applied to both terminals of the coil should
be
±5%
(at 20°C
68°F)
the rated operating
voltage of the coil. Also, be aware that the
pick-up and drop-out voltages will fluctu-
ate depending on the ambient tempera-
ture and operating conditions.
3) The ripple factor for the voltage applied
to the coil should be less than 5%.
4) For set and reset latching relays, the
rated operating voltage should be applied
to the coil for 10 ms or more.
2. Coil connection
When connecting coils, refer to the wiring
diagram to prevent mis-operation or mal-
function.
3. External magnetic field
Since GN relays are highly sensitive po-
larized relays, their characteristics will be
affected by a strong external magnetic
field. Avoid using the relay under that con-
ditions.
4. Cleaning
In automatic cleaning, cleaning with the
boiling method is recommended. Avoid ul-
trasonic cleaning which subjects the relay
to high frequency vibrations. It may cause
the contacts to stick.
lt is recommended that a fluorinated hy-
drocarbon or other alcoholic solvent be
used.
5. Packing style
1) The relay is packed in a tube with the
relay orientation mark on the left side, as
shown in the figure below.
Orientation (indicates PIN No.1)stripe
Please chuck the
portion.
Avoid chucking the center of the relay.
In addition, excessive chucking pressure
to the pinpoint of the relay should be
avoided.
