SMU3 · AEC-Q200
2 Pad Version
·
11.5 x 4.8 mm
actual size
I
I
I
I
AEC-Q200 qualified
recommended for automotive applications
reflow soldering temperature: 260 °C max.
package height 4.0 mm max.
2002/95/EC
RoHS compliant
Pb free: pins / pads
RoHS
General Data
type
frequency range
SMU3
3.2768 ~ 33.0 MHz
27.0 ~ 60.0 MHz
frequency tolerance at 25 °C
load capacitance C
L
shunt capacitance C
o
storage temperature
shock resistance
drive level max.
aging
(fund. AT-cut)
(3rd OT AT-cut)
ESR (series resistance Rs)
frequency
in MHz
3.276 ~ 3.499
3.579 ~ 3.999
4.000 ~ 5.999
6.000 ~ 6.999
7.000 ~ 8.999
(half sine pulse, 6.0 ms)
(100 µW recommended)
9.000 ~ 13.99
14.00 ~ 33.00
27.00 ~ 60.00
vibration
mode
fund.-AT
fund.-AT
fund.-AT
fund.-AT
fund.-AT
fund.-AT
fund.-AT
3rd OT-AT
ESR max.
in
Ω
200
120
80
70
50
35
30
100
ESR typ.
in
Ω
100
80
60
35
25
15
10
60
± 20 ppm / ± 30 ppm / ± 50 ppm
12 pF ~ 32 pF or series
< 5 pF
-40 °C ~ +125 °C
> 100 g
300 µW
< ± 5 ppm first year
Frequency Stability vs. Temperature
± 20 ppm
-20 °C ~ +70 °C
-40 °C ~ +85 °C
-40 °C ~ +105 °C
-40 °C ~ +125 °C
STD.
T1
T2
T3
O
± 30 ppm
O
± 50 ppm
± 100 ppm
± 150 ppm
Marking
frequency with load capacitance code
company code / date code / internal code
•
O
O
•
O
O
2012
2013
2014
2015
Jan. Febr. Mar. Apr. May June July Aug. Sept. Oct. Nov. Dec.
n
A
N
a
p
B
P
b
q
C
Q
c
r
D
R
d
s
E
S
e
t
F
T
f
u
G
U
g
v
H
w
J
x
K
y
z
•
standard
O
available
L M
Y
l
Z
m
V W X
h
j
k
Dimensions
3.8 max.
0.6
+0.2 /– 0.1
< 3.5°
12.5
±0.3
4.4
±0.1
0.3 max.
max. 0.2
4.8 max.
4.0 max.
max. 0.2
< 3.5°
10.1 max.
11.5
±0.2
Z
Z
3.7
±0.3
5.5
±0.1
5.5
±0.1
top view
side view
side view
bottom view
pad layout
2.0
±0.1
in mm
Order Information
Q
Quartz
frequency
type
load capacitance
stability at
25 °C
20 = ± 20 ppm
30 = ± 30 ppm
50 = ± 50 ppm
stability vs.
temp. range
20
30
50
100
150
=
=
=
=
=
± 20 ppm
± 30 ppm
± 50 ppm
± 100 ppm
± 150 ppm
blank =
T1 =
T2 =
T3 =
FU =
3OT =
AEC =
option
3.2768 ~ 60.0 MHz
SMU3
12 pF ~ 32 pF
S for series
-20 °C ~ +70 °C
-40 °C ~ +85 °C
-40 °C ~ +105 °C
-40 °C ~ +125 °C
for fundamental frequencies
≥
20 MHz
3rd overtone
AEC-Q200 qualified
Example: Q 30.0-SMU3-30-30/50-T2-FU-AEC-LF
(Suffix LF = RoHS compliant / Pb free pins or pads)
Jauch Quartz GmbH
•
e-mail: info@jauch.de
full data can be found under: www.jauch.de / www.jauch.co.uk / www.jauch.fr / www.jauchusa.com
All specifications are subject to change without notice
021112
