F-219 (Rev 15NOV19)
FFMD–20–T–02.00–01–N–R
(1.27 mm) .050"
EYE
™
IDC
TIGER
™
FFMD–10–S–10.00–01
FFMD SERIES
TIGER EYE FLAT IDC WIRE CABLES
Mates with:
FLE*, SFMC*,
Transfer End Option
Mates with:
FTS, FTSH, EHF,
SHF, ESHF
TYPE
STRIP
NO. PINS
PER ROW
END
OPTION
OVERALL
LENGTH
01
TRANSFER
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?FFMD
Insulator Material:
PBT
Terminal:
Phosphor Bronze
Contact:
BeCu (-T)
Plating:
Sn over 50 µ" (1.27 µm) Ni
Wire:
30 AWG
Current Rating:
2.5 A per pin
(2 pins powered)
Operating Temp Range:
-40 °C to +105 °C
Voltage Rating:
215 VAC
304 VDC
RoHS Compliant:
Yes
= Assembled Length
–“XX.XX”
Assembled Length
in INCHES (± .130")
2 inches minimum
Leave blank for –S
and –D End Options.
= Notch Polarization
on socket (-T end only)
(Not available
with -04 position)
–04, –05, –08, –10,
–13, –17, –20, –25
(Standard sizes)
–N
–S
= Single End
–D
= Double End
–T
= Transfer End
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
Reverse
Daisy
–RW
= Wiring
–D “XX”
= Chain
(50.8 mm)
2.00
min.
–R
= Reverse
3
Outside
–O
= Reverse
Strain
–SR
= Relief
(Mates only with
ESHF Series)
“XX”
±
1/8"
01
FILE NO. E111594
Requires –DXX
3
No. of positions x
(1.27) .050 + (8.00) .315
–M
02
(101.60 mm) 4.00 min.
= Middle
Reverse
ALSO AVAILABLE
(MOQ Required)
• Other sizes
Red wire opposite
position #1.
1
2
Requires –DXX
3
Not available with
–O, –M, –R or –DXX
• Strain relief option
FFMD
= Terminal Strip
01
(3.05)
.120
No. of positions x
(1.27) .050 + (4.19) .165
*Note:
Standard FFMD callout will
not mate with FLE, SFMC.
Must use gold plated callouts.
(See drawing on web.)
When mated with a socket,
Wire 1 mates with Pin 2;
Wire 2 mates with Pin 1, etc.
Note:
This Series is non-standard,
non-returnable.
(0.41) .016 SQ
(5.08)
.200
(3.07)
.121
(1.27)
.050
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
