2. Relay may pull in with less than “Must Operate” value.
3. Specifications subject to change without notice.
4. Allow suitable slack on leads when wiring, and do not subject the
terminals to excessive force.
Max. Solder Time
Weight
12/11/12
AZ2505
AZ
RELAY ORDERING DATA
Nominal Coil
VDC
5
6
9
12
24
COIL SPECIFICATIONS -Single Coil
Set Voltage Reset Voltage Max. Continuous
VDC
VDC
VDC[1]
3.75
4.0
6.5
4.50
4.8
7.8
6.75
7.2
11.7
9.00
9.6
15.6
18.00
19.2
31.2
Coil Resistance
± 10%
25
36
81
144
576
ORDER NUMBER
1 Form A
AZ2505P1–1A–5D
AZ2505P1–1A–6D
AZ2505P1–1A–9D
AZ2505P1–1A–12D
AZ2505P1–1A–24D
1 Form B
AZ2505P1–1B–5D
AZ2505P1–1B–6D
AZ2505P1–1B–9D
AZ2505P1–1B–12D
AZ2505P1–1B–24D
Add suffix ‘E’ after A or B for 80A contacts, ‘H’ for 100A contacts, or ‘T’ for 120A contacts. Add Termination Suffix as seen in Chart below. Note[1]: Max continuous voltage
should not be applied for more than 30 seconds.
COIL SPECIFICATIONS -Dual Coil
Nominal Coil
VDC
5
6
9
12
24
Set Voltage Reset Voltage Max. Continuous
VDC
VDC
VDC[1]
3.75
4.0
6.5
4.50
4.8
7.8
6.75
7.2
11.7
9.00
9.6
15.6
18.00
19.2
31.2
Coil Resistance
± 10%
12.5 + 12.5
18 + 18
40.5 + 40.5
72 + 72
288 + 288
ORDER NUMBER
1 Form A
AZ2505P2–1A–5D
AZ2505P2–1A–6D
AZ2505P2–1A–9D
AZ2505P2–1A–12D
AZ2505P2–1A–24D
1 Form B
AZ2505P2–1B–5D
AZ2505P2–1B–6D
AZ2505P2–1B–9D
AZ2505P2–1B–12D
AZ2505P2–1B–24D
Add suffix ‘E’ after A or B for 80A contacts, ‘H’ for 100A contacts, or ‘T’ for 120A contacts. Add Termination suffix as seen in chart below. Note[1]: Max continuous voltage
