TBJ Series
CWR11 - MIL-PRF-55365/8
Established Reliability, COTS-Plus & Space Level
Fully qualified to MIL-PRF-55365/8, the
CWR11 is the military version of EIA-
535BAAC, with four case sizes de-
signed for maximum packaging
efficiency on 8mm & 12mm tape for
high volume production (ensuring no
TCE mismatch with any substrate). This
construction is compatible with a wide
range of SMT board assembly
processes including wave or reflow sol-
der, conductive epoxy or compression
bonding techniques. The part also car-
ries full polarity, capacitance / voltage
and JAN brand marking.
The series is qualified to MIL-PRF-
55365 Weibull “B”, “C”, “D” and “T” lev-
els, with all surge options (“A”, “B” &
“C”) available.
For Space Level applications, AVX
SRC9000 qualification is recom-
mended (see ratings table for part
number availability).
There are four termination finishes avail-
able: solder plated, fused solder plated,
hot solder dipped and gold plated
(these
are
“H”,
“K”,
“C”
and “B” termination, respectively, per
MIL-PRF-55365).
The molding compound has been se-
lected to meet the requirements of
UL94V-0 (Flame Retardancy) and out-
gassing requirements of ASTM E-595.
For moisture sensitivity levels please
refer to the High Reliability Tantalum
MSL section located in the back of the
High Reliability Tantalum Catalog.
L
W
H
A
S
A
W
1
CASE DIMENSIONS:
millimeters (inches)
MARKING
(Brown marking on gold body)
Polarity Stripe (+)
“J” for “JAN” Brand
Capacitance Code
Rated Voltage
Manufacturer’s ID
Case
Code
A
B
C
D
EIA
Metric
3216-18
3528-21
6032-28
7343-31
Length (L)
3.20±0.20
(0.126±0.008)
3.50±0.20
(0.138±0.008)
6.00±0.30
(0.236±0.012)
7.30±0.30
(0.287±0.012)
Width (W)
Height (H)
Term. Width (W
1
)
±0.10 (±0.004)
1.20 (0.047)
2.20 (0.087)
2.20 (0.087)
2.40 (0.094)
Term. Length A
±0.30(±0.012)
0.80 (0.031)
0.80 (0.031)
1.30 (0.051)
1.30 (0.051)
S min
1.80 (0.071)
1.40 (0.055)
2.90 (0.114)
4.40 (0.173)
1.60±0.20
1.60±0.20
(0.063±0.008) (0.063±0.008)
2.80±0.20
1.90±0.20
(0.110±0.008) (0.075±0.008)
3.20±0.30
2.50±0.30
(0.126±0.012) (0.098±0.012)
4.30±0.30
2.80±0.30
(0.169±0.012) (0.110±0.012)
CAPACITANCE AND RATED VOLTAGE, V
R
(MIL VOLTAGE CODE) RANGE
CASE SIZE
Capacitance
μF
Code
0.10
104
0.15
154
0.22
224
0.33
334
0.47
474
0.68
684
1.0
105
1.5
155
2.2
225
3.3
335
4.7
475
6.8
685
10
106
15
156
22
226
33
336
47
476
68
686
100
107
4V (C)
6V (D)
10V (F)
Rated voltage DC (V
R
) to 85ºC
15V (H)
20V (J)
25V (K)
35V (M)
A
A
A
A
B
B
B
C
C
C
D
D
50V (N)
A
B
B
B
C
C
C
D
D
D
D
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
C
D
D
A
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
D
D
A
A
A
B
B
B
C
C
D
D
A
A
B
B
B
C
C
C
D
D
D
012918
31
TBJ Series
CWR11 - MIL-PRF-55365/8
Established Reliability, COTS-Plus & Space Level
HOW TO ORDER
COTS-PLUS & MIL QPL (CWR11):
TBJ D
Type
Case
Size
686
*
006
C
#
@
0
^
++
Surge Test
Option
00 = None
23 = 10 Cycles, +25ºC
24 = 10 Cycles,
-55ºC & +85ºC
45 = 10 cycles,
-55ºC & +85ºC
before Weibull
Capacitance Capacitance
Voltage
Standard or Packaging
Code
Tolerance
Code
Low ESR
B = Bulk
pF code:
M = ±20% 004 = 4Vdc
Range
R = 7" T&R
1st two digits
K = ±10% 006 = 6Vdc C = Std ESR S = 13" T&R
represent
J = ±5%
010 = 10Vdc L = Low ESR W = Waffle
significant
015 = 15Vdc
figures 3rd
020 = 20Vdc
See page 8
digit represents
025 = 25Vdc
for additional
multiplier
035 = 35Vdc
(number of
packaging
zeros to follow)
050 = 50Vdc
options.
Inspection Level
Reliability Grade
Qualification Termination Finish
S = Std.
Level
Weibull:
H = Solder Plated
Conformance B = 0.1%/1000 hrs.
0 = N/A
0 = Fused Solder
L = Group A
T = T Level
90% conf.
Plated
M = MIL (JAN) C = 0.01%/1000 hrs. 9 = SRC9000 8 = Hot Solder
CWR11
90% conf.
Dipped
D = 0.001%/1000 hrs.
9 = Gold Plated
90% conf.
7 = Matte Sn
Z = Non-ER
(COTS-Plus
only)
LEAD-FREE COMPATIBLE
COMPONENT
For RoHS compliant products,
please select correct termination style.
CWR11 P/N CROSS REFERENCE:
CWR11
Type
D
Voltage
Code
C = 4Vdc
D = 6Vdc
F = 10Vdc
H = 15Vdc
J = 20Vdc
K = 25Vdc
M = 35Vdc
N = 50Vdc
^
Termination
Finish
H = Solder Plated
K = Solder Fused
C = Hot Solder
Dipped
B = Gold Plated
686
Capacitance
Code
pF code:
1st two digits
represent
significant
figures 3rd digit
represents
multiplier
(number of zeros
to follow)
*
Capacitance
Tolerance
M = ±20%
K = ±10%
J = ±5%
@
Reliability
Grade
Weibull:
B = 0.1%/1000 hrs.
90% conf.
C = 0.01%/1000 hrs.
90% conf.
D = 0.001%/1000
hrs. 90% conf.
T = T Level
A = Non-ER
+
Surge Test
Option
A = 10 cycles, +25°C
B = 10 cycles,
-55°C & +85°C
C = 10 cycles,
-55°C & +85°C
before Weibull
If blank,
None required
Packaging
Bulk = Standard
\TR = 7" T&R
\TR13 = 13" T&R
\W = Waffle
See page 8
for additional
packaging
options.
LEAD-FREE COMPATIBLE
COMPONENT
For RoHS compliant products,
please select correct termination style.
SPACE LEVEL OPTIONS TO SRC9000*:
TBJ D
Type
Case
Size
686
*
006
C
L
@
9
^
++
Surge Test
Option
45 = 10 cycles,
-55ºC & +85ºC
before Weibull
Capacitance Capacitance
Voltage
Standard or Packaging
Code
Tolerance
Code
Low ESR
B = Bulk
pF code:
M = ±20% 004 = 4Vdc
Range
R = 7" T&R
1st two digits
K = ±10% 006 = 6Vdc C = Std ESR S = 13" T&R
represent
J = ±5%
010 = 10Vdc L = Low ESR W = Waffle
significant
015 = 15Vdc
figures 3rd
020 = 20Vdc
See page 8
digit represents
025 = 25Vdc
for additional
multiplier
035 = 35Vdc
(number of
packaging
zeros to follow)
050 = 50Vdc
options.
Inspection Level
Reliability Grade
Qualification Termination Finish
L = Group A
Level
Weibull:
H = Solder Plated
9 = SRC9000 0 = Fused Solder
B = 0.1%/1000 hrs.
90% conf.
Plated
C = 0.01%/1000 hrs.
8 = Hot Solder
90% conf.
Dipped
D = 0.001%/1000 hrs.
9 = Gold Plated
90% conf.
LEAD-FREE COMPATIBLE
COMPONENT
*Contact factory for AVX SRC9000 Space Level SCD details.
For RoHS compliant products,
please select correct termination style.
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage (V
R
)
Category Voltage (V
C
)
Surge Voltage (V
S
)
Surge Voltage (V
S
)
Temperature Range:
Unless otherwise specified, all technical data relate to an ambient temperature of 25°C
0.10 μF to 100 μF
±5%; ±10%; ±20%
85°C:
4
6
10
15
20
25
35
50
125°C:
2.7
4
6.7
10
13.3
16.7
23.3
33.3
85°C:
5.3
8
13.3
20
26.7
33.3
46.7
66.7
125°C:
3.5
5.3
8.7
13.3
17.8
22.2
31.1
44.5
-55°C to +125°C
012918
32
RATING & PART NUMBER REFERENCE
Power
-55ºC
(%)
9
9
9
9
9
9
9
12
9
9
9
9
9
9
9
9
9
9
6
9
9
9
9
9
9
9
9
6
6
9
9
9
9
9
9
9
6
6
6
9
9
9
9
9
9
9
6
6
6
6
9
9
9
9
9
012918
TBJ Series
CWR11 P/N
AVX COTS-Plus P/N
CWR11 - MIL-PRF-55365/8
Established Reliability, COTS-Plus & Space Level
CWR11C^225*@+
CWR11C^475*@+
CWR11C^685*@+
CWR11C^106*@+
CWR11C^156*@+
CWR11C^336*@+
CWR11C^686*@+
CWR11C^107*@+
CWR11D^155*@+
CWR11D^225*@+
CWR11D^335*@+
CWR11D^475*@+
CWR11D^685*@+
CWR11D^106*@+
CWR11D^156*@+
CWR11D^226*@+
CWR11D^476*@+
CWR11D^686*@+
CWR11F^105*@+
CWR11F^155*@+
CWR11F^225*@+
CWR11F^335*@+
CWR11F^475*@+
CWR11F^685*@+
CWR11F^156*@+
CWR11F^336*@+
CWR11F^476*@+
CWR11H^684*@+
CWR11H^105*@+
CWR11H^155*@+
CWR11H^225*@+
CWR11H^335*@+
CWR11H^475*@+
CWR11H^106*@+
CWR11H^226*@+
CWR11H^336*@+
CWR11J^474*@+
CWR11J^684*@+
CWR11J^105*@+
CWR11J^155*@+
CWR11J^225*@+
CWR11J^335*@+
CWR11J^475*@+
CWR11J^685*@+
CWR11J^156*@+
CWR11J^226*@+
CWR11K^334*@+
CWR11K^474*@+
CWR11K^684*@+
CWR11K^105*@+
CWR11K^155*@+
CWR11K^225*@+
CWR11K^335*@+
CWR11K^475*@+
CWR11K^685*@+
TBJA 225 * 004 C # @ 0 ^ ++
TBJ A 475 * 004 C # @ 0 ^ ++
TBJ B 685 * 004 C # @ 0 ^ ++
TBJ B 106 * 004 C # @ 0 ^ ++
TBJ B 156 * 004 C # @ 0 ^ ++
TBJ C 336 * 004 C # @ 0 ^ ++
TBJ D 686 * 004 C # @ 0 ^ ++
TBJ D 107 * 004 C # @ 0 ^ ++
TBJ A 155 * 006 C # @ 0 ^ ++
TBJ A 225 * 006 C # @ 0 ^ ++
TBJ A 335 * 006 C # @ 0 ^ ++
TBJ B 475 * 006 C # @ 0 ^ ++
TBJ B 685 * 006 C # @ 0 ^ ++
TBJ B 106 * 006 C # @ 0 ^ ++
TBJ C 156 * 006 C # @ 0 ^ ++
TBJ C 226 * 006 C # @ 0 ^ ++
TBJ D 476 * 006 C # @ 0 ^ ++
TBJ D 686 * 006 C # @ 0 ^ ++
TBJ A 105 * 010 C # @ 0 ^ ++
TBJ A 155 * 010 C # @ 0 ^ ++
TBJ A 225 * 010 C # @ 0 ^ ++
TBJ B 335 * 010 C # @ 0 ^ ++
TBJ B 475 * 010 C # @ 0 ^ ++
TBJ B 685 * 010 C # @ 0 ^ ++
TBJ C 156 * 010 C # @ 0 ^ ++
TBJ D 336 * 010 C # @ 0 ^ ++
TBJ D 476 * 010 C # @ 0 ^ ++
TBJ A 684 * 015 C # @ 0 ^ ++
TBJ A 105 * 015 C # @ 0 ^ ++
TBJ A 155 * 015 C # @ 0 ^ ++
TBJ B 225 * 015 C # @ 0 ^ ++
TBJ B 335 * 015 C # @ 0 ^ ++
TBJ B 475 * 015 C # @ 0 ^ ++
TBJ C 106 * 015 C # @ 0 ^ ++
TBJ D 226 * 015 C # @ 0 ^ ++
TBJ D 336 * 015 C # @ 0 ^ ++
TBJ A 474 * 020 C # @ 0 ^ ++
TBJ A 684 * 020 C # @ 0 ^ ++
TBJ A 105 * 020 C # @ 0 ^ ++
TBJ B 155 * 020 C # @ 0 ^ ++
TBJ B 225 * 020 C # @ 0 ^ ++
TBJ B 335 * 020 C # @ 0 ^ ++
TBJ C 475 * 020 C # @ 0 ^ ++
TBJ C 685 * 020 C # @ 0 ^ ++
TBJ D 156 * 020 C # @ 0 ^ ++
TBJ D 226 * 020 C # @ 0 ^ ++
TBJ A 334 * 025 C # @ 0 ^ ++
TBJ A 474 * 025 C # @ 0 ^ ++
TBJ B 684 * 025 C # @ 0 ^ ++
TBJ B 105 * 025 C # @ 0 ^ ++
TBJ B 155 * 025 C # @ 0 ^ ++
TBJ C 225 * 025 C # @ 0 ^ ++
TBJ C 335 * 025 C # @ 0 ^ ++
TBJ C 475 * 025 C # @ 0 ^ ++
TBJ D 685 * 025 C # @ 0 ^ ++
Parametric Specifications by Rating per MIL-PRF-55365/8
Cap
DC Rated
ESR
DCL max
DF Max
@ 120Hz Voltage @ 100kHz +25ºC
+85ºC
+125ºC
+25ºC
+(85/125)ºC
μF
V
Ohms
AVX SRC9000 P/N
Case
(μA)
(μA)
(μA)
(%)
(%)
@ 25ºC @ +85ºC @ +25ºC
TBJ A 225 * 004 C L @ 9 ^ ++ A
2.2
4
8
0.5
5
6
6
9
TBJ A 475 * 004 C L @ 9 ^ ++ A
4.7
4
8
0.5
5
6
6
9
TBJ B 685 * 004 C L @ 9 ^ ++ B
6.8
4
5.5
0.5
5
6
6
9
TBJ B 106 * 004 C L @ 9 ^ ++ B
10
4
4
0.5
5
6
6
9
TBJ B 156 * 004 C L @ 9 ^ ++ B
15
4
3.5
0.6
6
7.2
6
9
TBJ C 336 * 004 C L @ 9 ^ ++ C
33
4
2.2
1.3
13
15.6
6
9
TBJ D 686 * 004 C L @ 9 ^ ++ D
68
4
1.1
2.7
27
32.4
6
9
TBJ D 107 * 004 C L @ 9 ^ ++ D
100
4
0.9
4
40
48
8
12
TBJ A 155 * 006 C L @ 9 ^ ++ A
1.5
6
8
0.5
5
6
6
9
TBJ A 225 * 006 C L @ 9 ^ ++ A
2.2
6
8
0.5
5
6
6
6
TBJ A 335 * 006 C L @ 9 ^ ++ A
3.3
6
8
0.5
5
6
6
9
TBJ B 475 * 006 C L @ 9 ^ ++ B
4.7
6
5.5
0.5
5
6
6
9
TBJ B 685 * 006 C L @ 9 ^ ++ B
6.8
6
4.5
0.5
5
6
6
9
TBJ B 106 * 006 C L @ 9 ^ ++ B
10
6
3.5
0.6
6
7.2
6
9
TBJ C 156 * 006 C L @ 9 ^ ++ C
15
6
3
0.9
9
10.8
6
9
TBJ C 226 * 006 C L @ 9 ^ ++ C
22
6
2.2
1.4
14
16.8
6
9
TBJ D 476 * 006 C L @ 9 ^ ++ D
47
6
1.1
2.8
28
33.6
6
9
TBJ D 686 * 006 C L @ 9 ^ ++ D
68
6
0.9
4.3
43
51.6
6
9
TBJ A 105 * 010 C L @ 9 ^ ++ A
1
10
10
0.5
5
6
4
6
TBJ A 155 * 010 C L @ 9 ^ ++ A
1.5
10
8
0.5
5
6
6
6
TBJ A 225 * 010 C L @ 9 ^ ++ A
2.2
10
8
0.5
5
6
6
9
TBJ B 335 * 010 C L @ 9 ^ ++ B
3.3
10
5.5
0.5
5
6
6
9
TBJ B 475 * 010 C L @ 9 ^ ++ B
4.7
10
4.5
0.5
5
6
6
9
TBJ B 685 * 010 C L @ 9 ^ ++ B
6.8
10
3.5
0.7
7
8.4
6
9
TBJ C 156 * 010 C L @ 9 ^ ++ C
15
10
2.5
1.5
15
18
6
6
TBJ D 336 * 010 C L @ 9 ^ ++ D
33
10
1.1
3.3
33
39.6
6
9
TBJ D 476 * 010 C L @ 9 ^ ++ D
47
10
0.9
4.7
47
56.4
6
9
TBJ A 684 * 015 C L @ 9 ^ ++ A
0.68
15
12
0.5
5
6
4
6
TBJ A 105 * 015 C L @ 9 ^ ++ A
1
15
10
0.5
5
6
4
6
TBJ A 155 * 015 C L @ 9 ^ ++ A
1.5
15
8
0.5
5
6
6
9
TBJ B 225 * 015 C L @ 9 ^ ++ B
2.2
15
5.5
0.5
5
6
6
9
TBJ B 335 * 015 C L @ 9 ^ ++ B
3.3
15
5
0.5
5
6
6
8
TBJ B 475 * 015 C L @ 9 ^ ++ B
4.7
15
4
0.7
7
8.4
6
9
TBJ C 106 * 015 C L @ 9 ^ ++ C
10
15
2.5
1.6
16
19.2
6
8
TBJ D 226 * 015 C L @ 9 ^ ++ D
22
15
1.1
3.3
33
39.6
6
8
TBJ D 336 * 015 C L @ 9 ^ ++ D
33
15
0.9
5.3
53
63.6
6
9
TBJ A 474 * 020 C L @ 9 ^ ++ A
0.47
20
14
0.5
5
6
4
6
TBJ A 684 * 020 C L @ 9 ^ ++ A
0.68
20
12
0.5
5
6
4
6
TBJ A 105 * 020 C L @ 9 ^ ++ A
1
20
10
0.5
5
6
4
6
TBJ B 155 * 020 C L @ 9 ^ ++ B
1.5
20
6
0.5
5
6
6
9
TBJ B 225 * 020 C L @ 9 ^ ++ B
2.2
20
5
0.5
5
6
6
8
TBJ B 335 * 020 C L @ 9 ^ ++ B
3.3
20
4
0.7
7
8.4
6
9
TBJ C 475 * 020 C L @ 9 ^ ++ C
4.7
20
3
1
10
12
6
8
TBJ C 685 * 020 C L @ 9 ^ ++ C
6.8
20
2.4
1.4
14
16.8
6
9
TBJ D 156 * 020 C L @ 9 ^ ++ D
15
20
1.1
3
30
36
6
8
TBJ D 226 * 020 C L @ 9 ^ ++ D
22
20
0.9
4.4
44
52.8
6
9
TBJ A 334 * 025 C L @ 9 ^ ++ A
0.33
25
15
0.5
5
6
4
6
TBJ A 474 * 025 C L @ 9 ^ ++ A
0.47
25
14
0.5
5
6
4
6
TBJ B 684 * 025 C L @ 9 ^ ++ B
0.68
25
7.5
0.5
5
6
4
6
TBJ B 105 * 025 C L @ 9 ^ ++ B
1
25
6.5
0.5
5
6
4
6
TBJ B 155 * 025 C L @ 9 ^ ++ B
1.5
25
6.5
0.5
5
6
6
8
TBJ C 225 * 025 C L @ 9 ^ ++ C
2.2
25
3.5
0.6
6
7.2
6
9
TBJ C 335 * 025 C L @ 9 ^ ++ C
3.3
25
3.5
0.9
9
10.8
6
8
TBJ C 475 * 025 C L @ 9 ^ ++ C
4.7
25
2.5
1.2
12
14.4
6
9
TBJ D 685 * 025 C L @ 9 ^ ++ D
6.8
25
1.4
1.7
17
20.4
6
9
Typical RMS Ripple Data by Rating
25ºC
85ºC
125ºC
25ºC
85ºC
125ºC
Dissipation
Ripple
Ripple
Ripple
Ripple
Ripple
Ripple
A
A
A
V
V
V
W
(100kHz) (100kHz) (100kHz) (100kHz) (100kHz) (100kHz)
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.085
0.12
0.11
0.05
0.68
0.62
0.27
0.085
0.15
0.13
0.06
0.58
0.52
0.23
0.085
0.16
0.14
0.06
0.55
0.49
0.22
0.110
0.22
0.20
0.09
0.49
0.44
0.20
0.150
0.37
0.33
0.15
0.41
0.37
0.16
0.150
0.41
0.37
0.16
0.37
0.33
0.15
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.085
0.12
0.11
0.05
0.68
0.62
0.27
0.085
0.14
0.12
0.05
0.62
0.56
0.25
0.085
0.16
0.14
0.06
0.55
0.49
0.22
0.110
0.19
0.17
0.08
0.57
0.52
0.23
0.110
0.22
0.20
0.09
0.49
0.44
0.20
0.150
0.37
0.33
0.15
0.41
0.37
0.16
0.150
0.41
0.37
0.16
0.37
0.33
0.15
0.075
0.09
0.08
0.03
0.87
0.78
0.35
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.085
0.12
0.11
0.05
0.68
0.62
0.27
0.085
0.14
0.12
0.05
0.62
0.56
0.25
0.085
0.16
0.14
0.06
0.55
0.49
0.22
0.110
0.21
0.19
0.08
0.52
0.47
0.21
0.150
0.37
0.33
0.15
0.41
0.37
0.16
0.150
0.41
0.37
0.16
0.37
0.33
0.15
0.075
0.08
0.07
0.03
0.95
0.85
0.38
0.075
0.09
0.08
0.03
0.87
0.78
0.35
0.075
0.10
0.09
0.04
0.77
0.70
0.31
0.085
0.12
0.11
0.05
0.68
0.62
0.27
0.085
0.13
0.12
0.05
0.65
0.59
0.26
0.085
0.15
0.13
0.06
0.58
0.52
0.23
0.110
0.21
0.19
0.08
0.52
0.47
0.21
0.150
0.37
0.33
0.15
0.41
0.37
0.16
0.150
0.41
0.37
0.16
0.37
0.33
0.15
0.075
0.07
0.07
0.03
1.02
0.92
0.41
0.075
0.08
0.07
0.03
0.95
0.85
0.38
0.075
0.09
0.08
0.03
0.87
0.78
0.35
0.085
0.12
0.11
0.05
0.71
0.64
0.29
0.085
0.13
0.12
0.05
0.65
0.59
0.26
0.085
0.15
0.13
0.06
0.58
0.52
0.23
0.110
0.19
0.17
0.08
0.57
0.52
0.23
0.110
0.21
0.19
0.09
0.51
0.46
0.21
0.150
0.37
0.33
0.15
0.41
0.37
0.16
0.150
0.41
0.37
0.16
0.37
0.33
0.15
0.075
0.07
0.06
0.03
1.06
0.95
0.42
0.075
0.07
0.07
0.03
1.02
0.92
0.41
0.085
0.11
0.10
0.04
0.80
0.72
0.32
0.085
0.11
0.10
0.05
0.74
0.67
0.30
0.085
0.11
0.10
0.05
0.74
0.67
0.30
0.110
0.18
0.16
0.07
0.62
0.56
0.25
0.110
0.18
0.16
0.07
0.62
0.56
0.25
0.110
0.21
0.19
0.08
0.52
0.47
0.21
0.150
0.33
0.29
0.13
0.46
0.41
0.18
All technical data relates to an ambient temperature of +25°C. Capacitance and DF are measured at 120Hz, 0.5V RMS with a maximum DC bias of 2.2 volts. DCL is measured at rated voltage after 5 minutes.
33
NOTE: AVX reserves the right to supply a higher voltage rating or tighter tolerance part in the same case size, to the same reliability standards.
34
Power
-55ºC
(%)
9
9
6
6
6
6
6
6
6
9
9
9
9
9
8
6
6
6
6
6
6
9
9
9
9
Parametric Specifications by Rating per MIL-PRF-55365/8
Cap
DC Rated
ESR
DCL max
DF Max
@ 120Hz Voltage @ 100kHz +25ºC
+85ºC
+125ºC
+25ºC
+(85/125)ºC
μF
V
Ohms
AVX SRC9000 P/N
Case
(μA)
(μA)
(μA)
(%)
(%)
@ 25ºC @ +85ºC @ +25ºC
TBJ D 106 * 025 C L @ 9 ^ ++ D
10
25
1.2
2.5
25
30
6
8
TBJ D 156 * 025 C L @ 9 ^ ++ D
15
25
1
3.8
38
45.6
6
9
TBJ A 104 * 035 C L @ 9 ^ ++ A
0.1
35
24
0.5
5
6
4
6
TBJ A 154 * 035 C L @ 9 ^ ++ A
0.15
35
21
0.5
5
6
4
6
TBJ A 224 * 035 C L @ 9 ^ ++ A
0.22
35
18
0.5
5
6
4
6
TBJ A 334 * 035 C L @ 9 ^ ++ A
0.33
35
15
0.5
5
6
4
6
TBJ B 474 * 035 C L @ 9 ^ ++ B
0.47
35
10
0.5
5
6
4
6
TBJ B 684 * 035 C L @ 9 ^ ++ B
0.68
35
8
0.5
5
6
4
6
TBJ B 105 * 035 C L @ 9 ^ ++ B
1
35
6.5
0.5
5
6
4
6
TBJ C 155 * 035 C L @ 9 ^ ++ C
1.5
35
4.5
0.5
5
6
6
8
TBJ C 225 * 035 C L @ 9 ^ ++ C
2.2
35
3.5
0.8
8
9.6
6
8
TBJ C 335 * 035 C L @ 9 ^ ++ C
3.3
35
2.5
1.2
12
14.4
6
8
TBJ D 475 * 035 C L @ 9 ^ ++ D
4.7
35
1.5
1.7
17
20.4
6
8
TBJ D 685 * 035 C L @ 9 ^ ++ D
6.8
35
1.3
2.4
24
28.8
6
9
TBJ A 104 * 050 C L @ 9 ^ ++ A
0.1
50
22
0.5
5
12
6
8
TBJ B 154 * 050 C L @ 9 ^ ++ B
0.15
50
17
0.5
5
6
4
6
TBJ B 224 * 050 C L @ 9 ^ ++ B
0.22
50
14
0.5
5
6
4
6
TBJ B 334 * 050 C L @ 9 ^ ++ B
0.33
50
12
0.5
5
6
4
6
TBJ C 474 * 050 C L @ 9 ^ ++ C
0.47
50
8
0.5
5
6
4
6
TBJ C 684 * 050 C L @ 9 ^ ++ C
0.68
50
7
0.5
5
6
4
6
TBJ C 105 * 050 C L @ 9 ^ ++ C
1
50
6
0.5
5
6
4
6
TBJ D 155 * 050 C L @ 9 ^ ++ D
1.5
50
4
0.8
8
9.6
6
8
TBJ D 225 * 050 C L @ 9 ^ ++ D
2.2
50
2.5
1.1
11
13.2
6
8
TBJ D 335 * 050 C L @ 9 ^ ++ D
3.3
50
2
1.7
17
20.4
6
9
TBJ D 475 * 050 C L @ 9 ^ ++ D
4.7
50
1.5
2.4
24
28.8
6
9
Typical RMS Ripple Data by Rating
25ºC
85ºC
125ºC
25ºC
85ºC
125ºC
Dissipation
Ripple
Ripple
Ripple
Ripple
Ripple
Ripple
A
A
A
V
V
V
W
(100kHz) (100kHz) (100kHz) (100kHz) (100kHz) (100kHz)
0.150
0.35
0.32
0.14
0.42
0.38
0.17
0.150
0.39
0.35
0.15
0.39
0.35
0.15
0.075
0.06
0.05
0.02
1.34
1.21
0.54
0.075
0.06
0.05
0.02
1.25
1.13
0.50
0.075
0.06
0.06
0.03
1.16
1.05
0.46
0.075
0.07
0.06
0.03
1.06
0.95
0.42
0.085
0.09
0.08
0.04
0.92
0.83
0.37
0.085
0.10
0.09
0.04
0.82
0.74
0.33
0.085
0.11
0.10
0.05
0.74
0.67
0.30
0.110
0.16
0.14
0.06
0.70
0.63
0.28
0.110
0.18
0.16
0.07
0.62
0.56
0.25
0.110
0.21
0.19
0.08
0.52
0.47
0.21
0.150
0.32
0.28
0.13
0.47
0.43
0.19
0.150
0.34
0.31
0.14
0.44
0.40
0.18
0.075
0.06
0.05
0.02
1.28
1.16
0.51
0.085
0.07
0.06
0.03
1.20
1.08
0.48
0.085
0.08
0.07
0.03
1.09
0.98
0.44
0.085
0.08
0.08
0.03
1.01
0.91
0.40
0.110
0.12
0.11
0.05
0.94
0.84
0.38
0.110
0.13
0.11
0.05
0.88
0.79
0.35
0.110
0.14
0.12
0.05
0.81
0.73
0.32
0.150
0.19
0.17
0.08
0.77
0.70
0.31
0.150
0.24
0.22
0.10
0.61
0.55
0.24
0.150
0.27
0.25
0.11
0.55
0.49
0.22
0.150
0.32
0.28
0.13
0.47
0.43
0.19
RATING & PART NUMBER REFERENCE
TBJ Series
CWR11 P/N
AVX COTS-Plus P/N
CWR11K^106*@+
CWR11K^156*@+
CWR11M^104*@+
CWR11M^154*@+
CWR11M^224*@+
CWR11M^334*@+
CWR11M^474*@+
CWR11M^684*@+
CWR11M^105*@+
CWR11M^155*@+
CWR11M^225*@+
CWR11M^335*@+
CWR11M^475*@+
CWR11M^685*@+
CWR11N^104*@+
CWR11N^154*@+
CWR11N^224*@+
CWR11N^334*@+
CWR11N^474*@+
CWR11N^684*@+
CWR11N^105*@+
CWR11N^155*@+
CWR11N^225*@+
CWR11N^335*@+
CWR11N^475*@+
TBJ D 106 * 025 C
TBJ D 156 * 025 C
TBJ A 104 * 035 C
TBJ A 154 * 035 C
TBJ A 224 * 035 C
TBJ A 334 * 035 C
TBJ B 474 * 035 C
TBJ B 684 * 035 C
TBJ B 105 * 035 C
TBJ C 155 * 035 C
TBJ C 225 * 035 C
TBJ C 335 * 035 C
TBJ D 475 * 035 C
TBJ D 685 * 035 C
TBJ A 104 * 050 C
TBJ B 154 * 050 C
TBJ B 224 * 050 C
TBJ B 334 * 050 C
TBJ C 474 * 050 C
TBJ C 684 * 050 C
TBJ C 105 * 050 C
TBJ D 155 * 050 C
TBJ D 225 * 050 C
TBJ D 335 * 050 C
TBJ D 475 * 050 C
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
# @ 0 ^ ++
All technical data relates to an ambient temperature of +25°C. Capacitance and DF are measured at 120Hz, 0.5V RMS with a maximum DC bias of 2.2 volts. DCL is measured at rated voltage after 5 minutes.
CWR11 - MIL-PRF-55365/8
Established Reliability, COTS-Plus & Space Level
NOTE: AVX reserves the right to supply a higher voltage rating or tighter tolerance part in the same case size, to the same reliability standards.
012918
Embedded System
京公网安备 11010802033920号
EEWORLD
