Crystal unit
Product Number (please contact us
)
X1E000341xxxx00
MHz RANGE CRYSTAL UNIT
For Automotive
FA - 238A
Nominal
frequency range
External
dimensions
Overtone
order
Applications
:
:
:
:
12 MHz to 60 MHz
3.2
×
2.5
×
0.7 mm
Fundamental
Car audio, ECU clock, Clock,
Car navigation system,
Meter, Remote keyless entry
Actual size
Conforms
to AEC-Q200
:
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature range
Operating temperature range
Level of drive
Frequency tolerance
Symbol
f_nom
T_stg
T_use
DL
f_tol
Specifications
For Automotive
12.000 MHz to 60.000 MHz
-40
C
to +125
C
-40
C
to +125
C
200
W
Max.
15
10
-6
to
50
10
-6
30
10
-6
/ -40
C
to +85
C
50
10
-6
/ -40
C
to +125
C
7 pF to
As per table below
5
10
-6
/ year Max.
Conditions / Remarks
Fundamental
Please contact us about available
frequencies.
Storage as single product.
Recommended: 1
W
to 100
W
+25
C
Please contact us for requirements not
listed in this specifications.
Please contact us for requirements not
listed in this specifications.
Please specify.
-40
C
to +125
C,
DL=100
W
+25
C,
First year
Frequency versus temperature
f_tem
characteristics
Load capacitance
CL
Motional resistance (ESR)
R
1
Frequency aging
f_age
Motional resistance (ESR)
Frequency
12.0 MHz
f_nom
13.0 MHz
13.0 MHz < f_nom < 20.0 MHz
20.0 MHz
f_nom < 25.0 MHz
25.0 MHz
f_nom
60.0 MHz
Product name
(Standard form)
Motional resistance
120
Max.
80
Max.
60
Max.
50
Max.
FA-238A 28.636360MHz 18.0 +15.0-15.0
①
②
③
④
-6
①Model
②Frequency
③Load
capacitance(pF)
④Frequency
tolerance(
×
10
,
+25
C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
(Unit:mm)
External dimensions
#4
#3
Footprint (Recommended)
(Unit:mm)
2000P
e39RA
#1
3.2±0.1
2.5±0.1
2.2
#2
0.7 Max.
1.6
Internal connection
(TOP VIEW)
#4
#3
1.4
0.7
#1
#2
1.2
1.2
#1
#2
C 0.3 Min.
#4
0.9
#3
#2 and #4
are connected to the cover.
(Please connect to ground)
0.8
PROMOTION OF ENVIRONMENTAL MANAGEMENT SYSTEM
CONFORMING TO INTERNATIONAL STANDARDS
At Seiko Epson, all environmental initiatives operate under the
Plan-Do-Check-Action (PDCA) cycle designed to achieve continuous
improvements. The environmental management system (EMS)
operates under the ISO 14001 environmental management standard.
All of our major manufacturing and non-manufacturing sites, in
Japan and overseas, completed the acquisition of ISO 14001
certification.
ISO 14000 is an international standard for environmental
management that was established by the International
Standards Organization in 1996 against the background of
growing concern regarding global warming, destruction of
the ozone layer, and global deforestation.
WORKING FOR HIGH QUALITY
In order provide high quality and reliable products and services
than meet customer needs,
Seiko Epson made early efforts towards obtaining ISO9000 series
certification and has acquired ISO9001 for all business
establishments in Japan and abroad. We have also acquired ISO/TS
16949 certification that is requested strongly by major automotive
manufacturers as standard.
►Explanation
of the mark that are using it for the catalog
►Pb
free.
►Complies
with EU RoHS directive.
*About the products without the Pb-free mark.
Contains Pb in products exempted by EU RoHS directive.
(Contains Pb in sealing glass, high melting temperature type solder or other.)
►Designed
for automotive applications such as Car Multimedia, Body Electronics, Remote Keyless Entry etc.
►Designed
for automotive applications related to driving safety (Engine Control Unit, Air Bag, ESC etc ).
ISO/TS16949 is the international standard that added the
sector-specific supplemental requirements for automotive
industry based on ISO9001.
