JMD
CONNECTOR
0.5mm
pitch
Emboss Tape
Board-to-board connectors
Features––––––––––––––––––––––––
• Smooth connection
Thanks to the cantilever type contacts, mating is very smooth.
• Distortion preventive construction
Box-shaped plug housing has the guide ribs on both ends,
which prevents distortion, and offsetting the rib from the center
axis provides the mating directionality.
• Wide range of circuits
No. of circuits available are from 20 to 100, every 10 circuiits.
• Embossed taping for automatic mounting
This connector is supplied in embossed tape packaging, for
mounting by automatic placement machines.
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/50m
Ω
max.
After environmental testing/100m
Ω
max.
• Insulation resistance: 50M
Ω
min.
• Withstanding voltage: 100V AC/minute
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
1
JMD
CONNECTOR
Plug ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
C
Side entry type
B
A
0.5
2.3
0.2
0.2
C
0.5
2.3
A
B
1.15
1.3
Model No.
Circuits
Circuits
20
30
40
50
60
70
80
100
Dimensions (mm)
Side entry type
Side entry type
20PS-JMDSS-G-1-TF
30PS-JMDSS-G-1-TF
40PS-JMDSS-G-1-TF
50PS-JMDSS-G-1-TF
60PS-JMDSS-G-1-TF
70PS-JMDSS-G-1-TF
80PS-JMDSS-G-1-TF
100PS-JMDSS-G-1-TF
Dimensions mm(in.)
C
A
B
A
B
C
4.5
7.0
9.5
12.0
14.5
17.0
19.5
24.5
9.1
11.6
14.1
16.6
19.1
21.6
24.1
29.1
5.7
8.2
10.7
13.2
15.7
18.2
20.7
25.7
4.8
ModelTop entry type
No.
Top entry type
4.5mm
20P-JMDSS-G-1-TF
–
40P-JMDSS-G-1-TF
50P-JMDSS-G-1-TF
60P-JMDSS-G-1-TF
70P-JMDSS-G-1-TF
80P-JMDSS-G-1-TF
100P-JMDSS-G-1-TF
5.0mm
–
30P5.0-JMDSS-G-1-TF
40P5.0-JMDSS-G-1-TF
–
–
–
–
–
6.0mm
–
–
–
50P6.0-JMDSS-G-1-TF
60P6.0-JMDSS-G-1-TF
70P6.0-JMDSS-G-1-TF
–
–
Material and Finish
Q'ty /
Q´ty /
reel
reel
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
Contact: Phosphor bronze, nickel-undercoated, gold-plated
Housing: PA 6T, UL94V-0
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed-tape.
Receptacle –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Cir-
cuits
20
30
40
50
0.2
Model No.
20R-JMDSS-G-1-TF(S)
30R-JMDSS-G-1-TF(S)
40R-JMDSS-G-1-TF(S)
50R-JMDSS-G-1-TF(S)
60R-JMDSS-G-1-TF(S)
70R-JMDSS-G-1-TF(S)
80R-JMDSS-G-1-TF(S)
100R-JMDSS-G-1-TF(S)
Dimensions (mm)
A
4.5
7.0
9.5
12.0
14.5
17.0
19.5
24.5
B
9.1
11.6
14.1
16.6
19.1
21.6
24.1
29.1
C
5.7
8.2
10.7
13.2
15.7
18.2
20.7
25.7
Q'ty /
reel
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
60
C
70
80
100
3.1
Material and Finish
Contact: Phosphor bronze, nickel-undercoated, gold-plated
Housing: PA 6T, UL94V-0
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
0.5
2.3
A
B
1.7
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed-tape.
2
JMD
CONNECTOR
Plug with polarizing key ––––––––––––––––––––––––––––––––––––––––––––––––––––
Cir-
cuits
Circuit No.1 mark
C
Circuit No.1
Model No.
Stacking height /4.5mm
60P-JMDHS-GAN-1A-TF (A)
A
14.5
Dimensions (mm)
B
19.1
C
15.7
Q'ty /
reel
1,500
60
Material and Finish
Contact: Phosphor bronze, nickel-underplated, gold-plated (nickel-stripe)
Housing: PA6T, UL94V-0, gray
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
RoHS compliance
This product displays (LF)(SN) on a label.
This products listed above are supplied on embossed-tape.
0.2
0.5
2.3
A
B
Receptacle with polarizing key ––––––––––––––––––––––––––––––––––––––––––––––
C
Circuit No.1
Circuit No.1 mark
Cir-
cuits
60
Model No.
Stacking height /4.5mm
60R-JMDHS-GAN-1A-TF (SA)
A
14.5
Dimensions (mm)
B
19.1
C
15.7
Q'ty /
reel
1,500
Material and Finish
Contact: Phosphor bronze, nickel-underplated, gold-plated (nickel-stripe)
Housing: PA6T, UL94V-0, gray
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
0.2
C
RoHS compliance
This product displays (LF)(SN) on a label.
This products listed above are supplied on embossed-tape.
0.5
2.3
A
B
1.7
3.1
3
JMD
CONNECTOR
PC board layout
(viewed from component side)
and Assembly layout––––––––––––––––––
Plug: top entry type
Receptacle
Top entry type
0.5±0.03
0.3±0.05
1.55 0.85
0.5
4.3
( )P-JMDSS-G-1-TF : 4.5
( )P5.0-JMDSS-G-1-TF : 5.0
( )P6.0-JMDSS-G-1-TF : 6.0
5.8 Receptacle (5.6)
Plug: side entry type
0.85 1.55
0.5±0.03
0.3±0.05
2.9
1.4
Side entry type
4.8
2.6
1.4
1.35
3.05
Note: 1. Tolerances are non-cumulative: ±0.03mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
PC board layout
(viewed from component side)
and Assembly layout / with polarizing key––––
Plug
0.5±0.03
0.3±0.05
1.55±0.1
0.85±0.1
1.35
1.4±0.1
5.8
2.9
Top entny type
0.5
4.3
Receptacle
4.5
0.5±0.03
0.3±0.05
1.55±0.1
0.85±0.1
Note: 1. Tolerances are non-cumulative: ±0.03mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
4
1.4±0.1
5.6
2.9
5.6
