Hook-Up Wire
T
he broad range of hook-up
wire from Alpha means you
will find the product exactly
suited to your application—whether
it’s as straightforward as a control
cabinet in a protected environment
or as specialized as a machine
tool on the factory floor, a high-
temperature oven, or off-road
construction equipment.
Our hook-up wire is available in a
variety of insulations to meet your
needs for temperature, ability to
withstand wear and abrasion, elec-
trical performance, or resistance to
oil, solvents, and chemicals.
• Stranded and solid copper
conductors, bare or tinned, with
other platings available for
special application needs
• Broad range of insulations
• Color-coded insulation for easy
circuit identification
• UL, CSA, and Mil-spec
compliance
• Convenient put-ups as short as
100 feet
• Excellent uniformity and
low-fray design for easy handling,
stripping, and termination
Choice of Insulations to Meet Temperature Range and Mechanical and Environmental Requirements
Insulation
PVC
Material
Polyvinyl chloride
Temperature Range
-55°C to +105°C
Features
General-purpose insulation
Good abrasion resistance
Excellent flame resistance
Better abrasion and cut-through resistance than standard PVC
Improved temperature and solder iron resistance over standard PVC
Used in high-density wiring
Excellent recyclability
Excellent abrasion and cut-through resistance
Superior dielectric properties for thinner walls than PVC—allows wires
45% smaller in diameter and 40% light in weight
High temperature
Chemically inert: excellent chemical and solvent resistance
Excellent electrical properties
Higher temperature rating than PVC
High-voltage material
Excellent flexibility
Excellent dielectric strength and resistance to radiation, corona, and ozone
Widely used in wire wrap applications
High-temperature applications
Chemically inert: excellent chemical and solvent resistance
Moisture resistant
Withstands mechanical abuse and repeated flexing
High-temperature applications, such as heat-treating furnaces,
kilns, and food service equipment
Excellent thermal stability
XL-PVC
Cross-linked PVC
-55°C to +105°C
mPPE
Modified polyphenylene ether
-40°C to +105°C
PTFE
XLPE
Silicone
PDVF
ETFE
TGGT
Polytetrafluoroethylene
Cross-linked polyethylene
Silicone
Polyvinylidene fluoride
Ethylene tetrafluoroethylene
Teflon glass glass Teflon
-55°C to +200°C
-55°C to +125°C
-40°C to +150°C
-40°C to +125°C
-70°C to +150°C
+250°C
MG
Mica glass
+450°C
378
Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
Wire > Hook-Up Wire > 300 V
Hook-Up Wire
300 V, PVC
Insulation
Thickness
Inch
mm
0.016 0.41
0.016 0.41
0.016 0.41
0.016 0.41
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.016
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
0.41
Nominal
Diameter
Inch
mm
0.044
1.12
0.047
1.19
0.051
1.30
0.052 1.32
0.056
0.056
0.057
0.057
0.062
0.062
0.064
0.069
0.069
0.064
0.070
0.072
0.079
0.079
0.072
0.082
0.083
0.092
0.106
0.125
0.150
1.42
1.42
1.45
1.45
1.57
1.57
1.63
1.75
1.75
1.63
1.78
1.83
2.01
2.01
1.83
2.08
2.11
2.34
2.69
3.18
3.81
Part No.
3047
3048
3049
3050/1
3050
Wire Size
AWG
30
28
26
24
24
24
24
22
22
22
22
20
20
20
20
20
18
18
18
18
16
16
14
12
10
mm
2
0.06
0.09
0.14
0.20
0.23
0.23
0.24
0.32
0.35
0.35
0.38
0.51
0.51
0.52
0.56
0.62
0.81
0.81
0.82
0.96
1.31
1.32
2.08
3.30
5.32
Stranding
AWG
7/38
7/36
7/34
Solid
7/32
7/32
19/36
Solid
7/30
7/30
19/34
10/30
10/30
Solid
7/28
19/32
16/30
16/30
Solid
19/30
Solid
26/30
mm
7 x 0.10
7 x 0.13
7 x 0.16
1 x 0.51
7 x 0.20
7 x 0.20
19 x 0.13
1 x 0.64
7 x 0.25
7 x 0.25
19 x 0.16
10 x 0.25
10 x 0.25
1 x 0.81
7 x 0.32
19 x 0.20
16 x 0.25
16 x 0.25
1 x 1.02
19 x 0.25
1 x 1.29
26 x 0.25
Colors
Z1, 1 - 10
Z1, 1 - 10
Z1, 1 - 10
Z1, 1 - 10
Z1, 1 – 19, 28,
30
Z2, 0 - 9
Z2, 0 - 9
Z1, 1 - 10
Z1, 1 – 19, 28,
30
Z2, 0 - 9
Z2, 0 - 9
Z1, 1 – 19, 28,
30
Z2, 0 - 9
Z1, 1 - 10
Z2, 0 - 9
Z2, 0 - 9
Z1, 1 – 19, 28,
30
Z2, 0 - 9
Z1, 1 - 10
Z2, 0 - 9
Z1, 1 - 10
Z1, 1 – 19, 28,
30
Z2, 0 - 9
Z2, 0 - 9
Z2, 0 - 9
UL AWM 1007, 1581, 1569
VW-1
CSA AWM I A/B FT1
CSA TR-64 FT1
Operating Temperature
• -40°C to +105°C (AWM 1569,
CSA AWM)
• -40°C to +90°C (CSA TR-64)
• -40°C to +80°C (AWM 1007,
1581)
Materials
• Stranded or solid tinned
copper conductor
• PVC insulation
Availability
100 ft (30.5 m)
1000 ft (305 m)
892407T†
892419†
3051/1
3051
892207T†
892219†
3053
892010T†
3053/1
892007†
892019†
3055
891816T†
3055/1
891819†
3057/1
3057
891441†
891265*†
891000*†
41/30 41 x 0.25
65/30 65 x 0.25
105/30 105 x 0.25
*UL AWM 1581 and 1569. All others UL AWM 1007 and 1569.
†CSA AWM I A/B FT-1.
“T” indicates topcoat conductors.
Insulation Colors Z1
1 White
2 Black
3 Red
4 Green
5 Yellow
6 Blue
7 Brown
8 Orange
9 Slate
10 Violet
11 White/Black
12 White/Red
13 White/Green
14 White/Yellow
15 White/Blue
16 White/Brown
17 White/
Orange
18 White/
Slate
19 White/
Violet
28 Green/
Yellow
29 Yellow/Green
30 Pink
Insulation Colors Z2
0 Black
1 Brown
2 Red
3 Orange
4 Yellow
5 Green
6 Blue
7 Violet
8 Slate
9 White
These wires also available in 500 ft (152 m) put-ups.
380
Alpha Wire | www.alphawire.com | 1-800-52 ALPHA
Specifications subject to change. For complete specifications and availability, visit www.alphawire.com.
