36MB140APBF

Description
Bridge Rectifier Diode, 1 Phase, 35A, 1400V V(RRM), Silicon, MODULE-4
CategoryDiscrete semiconductor    diode
File Size46KB,6 Pages
ManufacturerInternational Rectifier ( Infineon )
Websitehttp://www.irf.com/
Environmental Compliance
Download Datasheet Parametric View All

36MB140APBF Overview

Bridge Rectifier Diode, 1 Phase, 35A, 1400V V(RRM), Silicon, MODULE-4

36MB140APBF Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerInternational Rectifier ( Infineon )
Parts packaging codeMODULE
package instructionR-PUFM-D4
Contacts4
Reach Compliance Codecompliant
Other featuresUL RECOGNIZED
Shell connectionISOLATED
ConfigurationBRIDGE, 4 ELEMENTS
Diode component materialsSILICON
Diode typeBRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)1.14 V
JESD-30 codeR-PUFM-D4
Maximum non-repetitive peak forward current500 A
Number of components4
Phase1
Number of terminals4
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current35 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum repetitive peak reverse voltage1400 V
Maximum reverse current10 µA
surface mountNO
Terminal formSOLDER LUG
Terminal locationUPPER
Maximum time at peak reflow temperature40
Base Number Matches1
Bulletin I27177 03/03
MB High Voltage SERIES
SINGLE PHASE BRIDGE
Features
Universal, 3 way terminals:
push-on, wrap around or solder
High thermal conductivity package,
electrically insulated case
Center hole fixing
Excellent power/volume ratio
UL E 62320 approved
Nickel plated terminals solderable as per MIL-STD-202 Method
208; solder: Sn/Pb (60/40); solder temperature: 235-260°C
max. time: 8-10 secs
Power Modules
25 A
35 A
Description
A range of extremely compact, encapsulated
single phase bridge rectifiers offering efficient and
reliable operation. They are intended for use in
general purpose and instrumentation applica-
tions.
Major Ratings and Characteristics
Parameters 26MB-A
I
O
@ T
C
I
FSM
@ 50Hz
@ 60Hz
I
2
t
@ 50Hz
@ 60Hz
V
RRM
range
T
J
25
70
400
420
790
725
36MB-A
35
55
475
500
1130
1030
Units
A
o
C
A
A
A
2
s
A
2
s
V
o
1400 to 1600
- 55 to 150
C
www.irf.com
1
