SH
CONNECTOR
11
10
9
8
7
6
5
4
3
2
Emboss Tape
1.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 1.0 A AC, DC (AWG #28)
• Voltage rating: 50 V AC, DC
• Temperature range:
-
25˚C to
+
85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 20 mΩ max.
After environmental testing/ 40 mΩ max.
• Insulation resistance: 100 MΩ min.
• Withstanding voltage: 500 VAC/minute
• Applicable wire: Conductor size/ AWG #32 to #28
Insulation O.D./ 0.4 to 0.8 mm
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
The world's first 1.0mm pitch crimp style
connector.
• Compact, low profile design
• Compatible with the SR insulation
displacement connectors
• Housing lances
Top entry type
2.9
0.2
±0.1
Header outline
±0.1
2.65
±0.1
1.8
4.2
±0.1
6.3
5.55
±0.1
0.7
±0.1
1.2
±0.1
Header outline
0.2
±0.1
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05mm for all centers.
3. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
3.9
2
0.5
0.8
1.6
1.55
0.8
1.8
±0.1
0.6
±0.05
1
±0.05
4
±0.1
mm
2
Applicable wire
Insulation O.D. (mm)
AWG#
32∼28
0.4∼0.8
Q'ty /
reel
23,000
SSH-003T-P0.2-H
0.032∼0.08
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
1.35
RoHS compliance
Note: Contact JST for gold-plated products.
0.45
Contact
Crimping
machine Crimp applicator
MKS-L-10-3
*MKS-SC
Applicator
Dies
Crimp applicator with dies
SSH-003T-P0.2-H
AP-K2N
MK/SSH/L-003-02 APLMK SSH/L003-02
SC/SSH/L-003-02 APLSC SSH/L003-02
Note: *Strip-crimp applicator
Contact JST for applicable wires in case that it is not usable due to wire size.
1
2.95
15
14
13
12
Standards ––––––––––––––––––––––
1
Certified LR20812
Side entry type
0.7
±0.1
0.6
±0.05
0
Recognized E60389
1.2
±0.1
1
±0.05
6.25
SH CONNECTOR
Housing
With protrusions
B
A
Circuit No.1
1
2.8
Circuits
2
3
4
5
6
5
Model No.
With protrusions Without protrusions
SHR-02V-S-B SHR-02V-S
SHR-03V-S-B SHR-03V-S
SHR-04V-S-B SHR-04V-S
SHR-05V-S-B SHR-05V-S
SHR-06V-S-B SHR-06V-S
SHR-07V-S-B SHR-07V-S
SHR-08V-S-B SHR-08V-S
SHR-09V-S-B SHR-09V-S
SHR-10V-S-B SHR-10V-S
SHR-11V-S-B SHR-11V-S
SHR-12V-S-B SHR-12V-S
SHR-13V-S-B SHR-13V-S
SHR-14V-S-B SHR-14V-S
SHR-15V-S-B SHR-15V-S
―
SHR-20V-S-B
A
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
19.0
Dimensions (mm)
Q'ty /
B
box
With protrusions Without protrusions
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
16.0
17.0
18.0
23.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
16.0
21.0
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
2,000
1,000
Without protrusions
B
A
Circuit No.1
1
2.8
2.1
Shrouded header
The shrouded headers are interchangeable with those of the SR insulation displacement connectors.
5
Top entry type
Circuit No.1
4.25
1
A
B
0.7
Side entry type
Circuit No.1
2.9
1
A
B
N
N
2.1
3 2
3 2
7
8
9
10
11
12
13
14
15
20
Material
PBT, UL94V-0, natural (white)
RoHS compliance
Circuits
2
3
4
5
6
7
1.5
2.9
Model No.
Top entry type
Side entry type
BM02B-SRSS-TB
BM03B-SRSS-TB
BM04B-SRSS-TB
BM05B-SRSS-TB
BM06B-SRSS-TB
BM07B-SRSS-TB
BM08B-SRSS-TB
BM09B-SRSS-TB
BM10B-SRSS-TB
BM11B-SRSS-TB
BM12B-SRSS-TB
BM13B-SRSS-TB
BM14B-SRSS-TB
BM15B-SRSS-TB
―
Dimensions (mm)
A
B
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
19.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
15.0
16.0
17.0
22.0
Q'ty / reel
Top entry type Side entry type
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
1,500
―
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
SM02B-SRSS-TB
SM03B-SRSS-TB
SM04B-SRSS-TB
SM05B-SRSS-TB
SM06B-SRSS-TB
SM07B-SRSS-TB
SM08B-SRSS-TB
SM09B-SRSS-TB
SM10B-SRSS-TB
SM11B-SRSS-TB
SM12B-SRSS-TB
SM13B-SRSS-TB
SM14B-SRSS-TB
SM15B-SRSS-TB
SM20B-SRSS-TB
8
9
10
11
12
13
14
15
20
Material and Finish
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Housing: PA, UL94V-0, natural (ivory)
Solder tab: Brass, copper-undercoated, tin-plated (reflow treatment)
4.25
0.7
1.5
RoHS compliance
This product displays (LF)(SN) on a label.
Note: 1. The products listed above are supplied on embossed-tape.
2. Contact JST for the headers with gold-plated pins.
3. Contact JST for the top entry type headers with suction cap.
2
